Thank You
Congratulations on the purchase of your new
Matrix loudspeaker. Matrix products are the
result of a collaboration between Designers,
Engineers and Musicians with many decades
of experience in the design and practical in
field application of exceptionally robust,
reliable and ergonomic audio equipment.
This manual will help you to get the most
from your loudspeaker. For maximum
benefit, it is recommended that all
instructions and warnings are carefully read.
Where unsure about anything, please
consult a qualified technician.
For warranty service, please retain your
receipt and all packaging that comes with
the loudspeaker, as it has been specifically
designed to transport the cabinet safely.
Unpacking
Please unpack and inspect your new
loudspeaker for any damage that may have
occurred during transit. If damage is found,
notify the carrier immediately.
PLEASE RETAIN ALL FACTORY PACKAGING
FOR ANY FUTURE POSTAL TRANSIT.
THIS PRODUCT IS CAPABLE OF PRODUCING
SOUND PRESSURE LEVELS WHICH MAY
DAMAGE HEARING. THE USER IS
RESPONSIBLE FOR EXPOSURE LEVELS AND
USE OF HEARING PROTECTION.
REV.1.22
CONTENTS:

Thank You

AMPLIFIED Cabinet Sections:
1. Features and Specifications
2. Amplifier Feature Overview
3. Connecting to a Slave Cabinet
PASSIVE Cabinet Sections:
4. Features and Specifications
5. Mono Loudspeaker Usage
6. Stereo Loudspeaker Usage
7. Recommended Amplification
8. Warranty
9. Declaration of CE Conformity
CAUTION:
OBSERVE ALL SAFETY AND USAGE
INSTRUCTIONS TO AVOID POSSIBLE DAMAGE
TO EQUIPMENT AND EXPOSURE TO HAZARDS
(THIS SYMBOL UNIVERSALLY FLAGS CAUTION
LETHAL VOLTAGES PRESENT AT SPEAKER,
CABLE AND AMPLIFIER TERMINALS; ENSURE
ALL WIRING IS SAFE AND CORRECT BEFORE
(THIS SYMBOL ALSO UNIVERSALLY FLAGS
ELECTRICAL HAZARDS)
DO NOT OPEN LOUDSPEAKER; LEAVE ALL
INTERNAL SERVICE OPERATIONS TO A
QUALIFIED TECHNICIAN.
