- Page 1 Film-Tech The information contained in this Adobe Acrobat pdf file is provided at your own risk and good judgment. These manuals are designed to facilitate the exchange of information related to cinema projection and film handling, with no warranties nor obligations from the authors, for qualified field service engineers.
- Page 2 CM-680 181 Bonetti Drive San Luis Obispo, CA 93401 ph: 805-549-0161 fax: 805-549-0163 e-mail:usl@uslinc.com...
-
Page 3: One Year Limited Warranty
One Year Limited Warranty USL, Inc. warrants that each product manufactured by it will be free from defects in material and workmanship under normal usage for a period of one (1) year after its purchase new from an authorized dealer. Our obligation under this warranty is limited to repairing... - Page 4 Introduction ............3 Front & Rear Panel Description......5 Installation............7 Crossover Setup...........11...
-
Page 5: Tools Required
Please read this entire manual before commencing your installation. TOOLS REQUIRED... - Page 6 You will need to supply the following materials: FEATURES The CM-680 monitor has the following standard features:...
- Page 9 NOTE: you must select “EX” or NORMAL (non “EX”) channel routing using the DIP switches on the rear panel of the CM-680. 3. Crossover Outputs to Power Amplifier Inputs: 4. Monitor Inputs From Power Amplifier Outputs: When VGA cables are NOT being used, the amplifier outputs must be connected to...
- Page 10 OPTION CARD I/O MAIN AUDIO OUTPUTS Note: MONITOR INPUTS FROM CROSSOVER OUTPUTS TO POWER AMPLIFIER INPUTS OPTIONAL INPUTS FROM PROCESSOR OUTPUTS SWITCHES 5-8 “EX” CHANNELS CM-680 Ls/Rs/Bsl/Bsr MONITOR/CROSSOVER BARGRAPH LEVEL 1 2 3 4 5 6 7 8 WARNING: TO REDUCE THE...
-
Page 11: Terminal Wiring Diagram
Figure 4 OPTION CARD I/O MAIN AUDIO OUTPUTS MONITOR INPUTS FROM CROSSOVER OUTPUTS TO POWER AMPLIFIER INPUTS OPTIONAL INPUTS FROM PROCESSOR OUTPUTS SWITCHES 5-8 “EX” CHANNELS CM-680 Ls/Rs/Bsl/Bsr MONITOR/CROSSOVER BARGRAPH LEVEL 1 2 3 4 5 6 7 8 WARNING:... -
Page 12: Connector Pinout
Ch - Bsr + Rh - LS + Ls + RS + Rs + SW + Lh + CM-680 HD 15 pin outs Typical per connector Pin # Name Pin # Name Pin # Name Band A (1), - Chassis Gnd... - Page 13 Analog Crossover Card XTA-680: Never turn on both rows of time Delay switches! Never turn on more than one row of DIP switches.
- Page 14 Figure 6 Llo Lhi Clo Chi Rlo Rhi...
- Page 15 Figure 7 1. Bypass Card XTB-680:...
- Page 16 Figure 8 BYPASS FOR PASSIVE OR EXTERNAL CROSSOVER SWITCHES A-C ON ** SWITCH A SWITCH B SWITCH C SWITCH D SWITCH E SWITCH F TO USE DOLBY CP650 CROSSOVERS SWITCHES D-F ON ** NOTE: TO FEED ONLY CHANNEL “1” OF THE HD15 CABLE IN THE “BYPASS”...
-
Page 17: Power Amplifiers
Inputs Processor: Power Amplifiers: Controls Rear Panel: Power Requirements Construction CM-680 181 Bonetti Drive, San Luis Obispo, CA 93401 ph: 805-549-0161 fax: 805-549-0163 e-mail:usl@uslinc.com ...
