Function Keys

Power Momentarily press the "Power" button to turn the unit on. Press the "Power" button for 2 seconds to
turn the unit off. Pressing the "Power" button momentarily, while the unit is on will turn the IR Light
On and Off.
Snap/Delete In standby mode mode press the Snap Button to take a picture, in playback mode press this button
Key delete a file when a thumbnail is highlighted.
Up / Down Use this button to select different options in the menu or switch in-between thumbnails you want to
Button play or view.
In recording mode press the Up button momentarily to turn the LCD on or off.
Press the Down button momentarily to then the Mic on or off. (When Mic is off you will notice a red
line go through the microphone icon in the left side of the LCD Screen.)
REC /OK Button Press this button to stop or start recording video.
While using the menu press the REC Ok button to confirm the selected option.
In playback mode press the REC / OK button to select the video you want to play or photo you want
to view.
Mode Button Use the Mode button to switch between the Recoding Mode, Playback Mode and Menu Mode. While
recording use the Mode button to lock or unlock a video so it will not be overwritten when the
memory is full.
LED Indicator The LED will flash Red while recoding, while charging the LED will glow Green and turn off when
battery is full.

Charging:

Full Half
This device can be charged using the provided DC car charging cable or the provided USB/data cable connected to
a USB terminal on a PC or laptop computer. When being used as a driving recorder, it is recommended to turn on
the "Record Overwrite" (5 minutes is recommended). Connect the DC car charger to the Dash Camera. When the
vehicle is turned on, the Dash Camera will automatically start video recording. When the vehicle engine is turned
off, the data will be saved, and the device will shut down automatically.
Caution:
Only the provided DC car charger, with the output of 5V 2A, can be used for this GPS DASH CAMERA. Using any other
charger, aside from the one provided, may damage the camera.
Zetronix.Com
Low Empty
