Page 1: User Manual
1080P SDI PTZ Camera User Manual 1080P SDI PTZ Camera User Manual... -
Page 2: Regulatory Information
1080P SDI PTZ Camera User Manual Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 3: Safety Instruction
If smoke, odors or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the Swann Tech Support team. If the product does not work properly, please contact Swann Tech Support. Never attempt to disassemble the camera yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.) - Page 4 1080P SDI PTZ Camera User Manual Please use the provided glove when open up the dome cover, avoid direct contact with the dome cover, because the acidic sweat of the fingers may erode the surface coating of the dome cover.
-
Page 5: Preparation For Installation
Please keep all wrappers and protective packing. Please keep all wrappers after unpacking them for future use. In case any failure occurs and you need to return the speed dome to Swann, you must ship with the original wrapper. Note: Transportation without the original wrapper and packing may result in damage on the speed dome and may void the warranty. -
Page 6: Table Of Contents
1080P SDI PTZ Camera User Manual Table of Contents Chapter 1 Installation............................7 Installation and Cabling ............................7 1.1.1 Installing the Speed Dome ..........................7 1.1.2 Connecting the Cables ........................... 13 DIP Switch Settings ............................. 14 1.2.1 Address Settings ............................. 15 1.2.2... -
Page 7: Chapter 1 Installation
1080P SDI PTZ Camera User Manual Chapter 1 Installation Before you start: Check the package contents and make sure that the device in the package is in good condition and all the required parts are included. 1.1 Installation and Cabling 1.1.1 Installing the Speed Dome... - Page 8 1080P SDI PTZ Camera User Manual Protective sticker protective foam Disassemble the Speed Dome Figure 1-2 6. Drill four M8 screw holes (based on using the supplied wall anchor bolts) on the wall according to the screw holes of the wall mount. If you are not using the supplied bolts, drill holes appropriate to the mounting hardware you are using.
- Page 9 1080P SDI PTZ Camera User Manual Install the Pendant Adapter Figure 1-3 ② ① Install the Pendant Adapter Figure 1-4 9. Hook the two ends of the safety cable from the tab on the back of the speed dome to the loop on the underside of the wall mount respectively.
- Page 10 1080P SDI PTZ Camera User Manual 11. Carefully feed the cables through the pendant adapter and down through the stand until they poke out the end where the mounting holes are as shown in Figure 1-6. 12. Connect the cables as shown in Section 1.1.2 Connecting the Cables to the SDI coaxial cable supplied in the kit, making sure that all connectors are secure and not under strain.
- Page 11 1080P SDI PTZ Camera User Manual 14. Align the direction label of the pendant adapter with the marking on the top of the housing to install the speed dome as shown below then push the dome up into the pendant feeding the last bit of cable through.
- Page 12 1080P SDI PTZ Camera User Manual 15. Rotate the top casing counterclockwise or clockwise firmly to lock it in. Secure the casing to the pendant adapter with the two lock screws as shown below. ⑤ Tighten the Lock Screws Figure 1-8...
-
Page 13: Connecting The Cables
1080P SDI PTZ Camera User Manual 1.1.2 Connecting the Cables Before you start: Please make sure to turn off the power of the dome before connecting the cables. The cable interfaces of the SDI speed dome are shown in Figure 1-9. The cables of RS-485, power supply, etc. -
Page 14: Dip Switch Settings
1080P SDI PTZ Camera User Manual 1.2 DIP Switch Settings When you first power up the dome camera, the CURRENT PTZ address and baudrate settings are displayed in the On Screen Display on your monitor. Note: This section is only required if you need to change the default settings for the SDI speed dome. -
Page 15: Address Settings
1080P SDI PTZ Camera User Manual 1.2.1 Address Settings The SW1-switches from 1 to 8 are used for setting the address of speed dome. You can refer to Table 1-1 for details of setting the speed dome address to a specific number. -
Page 16: Baudrate Settings
1080P SDI PTZ Camera User Manual 1.2.2 Baudrate Settings The number 1 and 2 SW2-switches are used for setting the baudrate of the speed dome. The baudrate can be 2400bps, 4800bps, 9600bps and 19200bps. The baudrate will be set as 2400bps by default if it is out of this range. -
Page 17: Appendix
1080P SDI PTZ Camera User Manual Appendix Appendix 1 Lightning & Surge Protection This product adopts TVS plate lightning protection technology to avoid damage caused by a pulse signal that is below 3000W, like instantaneous lighting strike, power surge, etc. According to the actual outdoor situation necessary protection measures must be taken, additional to ensuring the electrical safety. -
Page 18: Appendix 2 Rs485 Bus Connection
1080P SDI PTZ Camera User Manual Appendix 2 RS485 Bus Connection General Property of RS485 Bus According to RS485 industry bus standard, RS485 is a half-duplex communication bus which has 120Ω characteristic impedence, the maximum load ability is 32 payloads (including controller device and controlled device). - Page 19 1080P SDI PTZ Camera User Manual faraway. At this time, the dome will be uncontrollable, or self-running, etc. Controller Device Star Shape Connection Figure A-4 For such case, the best way is adding a RS485 distributor. This product can effectively change the star-shape connection to which satisfies the requirement of RS485 industry standard, in order to avoid those problems and improve the communication reliability.
- Page 20 1080P SDI PTZ Camera User Manual 1. Reconnect the RS485 wire 1. The connection is loose. tightly. The speed dome can 2. RS485+ or RS485-wire is 2. Change RS485 wire. broken. controlled 3. The speed dome is too far away 3.
-
Page 21: Appendix 3 24Vac Wire Gauge & Transmission Distance
1080P SDI PTZ Camera User Manual Appendix 3 24VAC Wire Gauge & Transmission Distance The following table describes the recommended max. distance adopted for the certain wire gauge when the loss rate of 24VAC voltage is less than 10%. For the AC driven device, the maximum allowable voltage loss rate is 10%. -
Page 22: Appendix 4 Wire Gauge Standards
2.500 4.9080 3.000 7.0683 Helpdesk / Technical Support Details Swann Technical Support All Countries E-mail: tech@swann.com Telephone Helpdesk USA Toll Free1-800-627-2799 USA Exchange & Repairs 1-800-627-2799 (Option 1) (M-F, 9am-5pm US PT) AUSTRALIA 1300 138 324 NEW ZEALAND Toll Free 0800 479 266...
