- Page 1 English 1080p SDI Video / Dome Camera for use with 1080p Swann SDI DVRs M871_876CAM250313E...
- Page 2 Any unit which proves defective during the stated period will be repaired without charge for parts or labour or replaced at the sole discretion of Swann. The end user is responsible for all freight charges incurred to send the product to Swann’s repair centres. The end user is responsible for all shipping costs incurred when shipping from and to any country other than the country of origin.
- Page 3 Introduction Congratulations on your purchase of this Swann SDI Video / Dome Camera! This installation and setup guide will walk you through the basics of: • Mounting your camera Choosing a location, Aiming the camera, Suitable mounting surfaces • Connecting the camera Where to connect power, How to run cables for improved weather-resistance •...
- Page 4 Connection Diagram For a single camera: Connect the camera’s DC and BNC socket cable to the extension Connect the extension cable’s DC and BNC plugs. Then cable’s DC socket to the connect the BNC extension cable DC plug on the power to an open channel on the back of adapter.
- Page 5 Choosing a Location for Your Camera(s) There are a number of factors you will need to consider when choosing where to mount your camera - not least of which is what you will want to see. Weather & Tampering The camera’s casing is resistant to water, different weather conditions and tampering. It would take an overwhelming event of this kind to damage the housing of the camera (severe weather such as hurricanes or someone intentionally damaging the lens would be enough).
- Page 6 Adjusting the Camera Settings Aiming the Video Camera Loosening the locking ring will allow you to rotate the barrel of the camera, so no matter what direction it faces, you can spin the camera so that your images are correctly oriented. Aiming the Dome Camera 1.
- Page 7 There are many options available in the OSD menus - many more than we can talk about here, and we’re constantly adding or tweaking options to ensure you have the best experience possible. Download a guide to the advanced OSD features of this camera from www.swann.com/osdpro if you want to know more. Notes ______________________________________________________________...
- Page 8 Helpdesk / Technical Support Details Swann Technical Support All Countries E-mail: tech@swann.com Telephone Helpdesk USA toll free AUSTRALIA toll free 1-800-627-2799 1300 138 324 USA Exchange & Repairs NEW ZEALAND toll free 1-800-627-2799 (Option 1) 0800 479 266 (M-F, 9am-5pm US PT) 0203 027 0979 ©...
