Yes, You Can.®
Invacare® Typhoon II
Electric wheelchair
Operating manual

Advertisement

Table of Contents
loading

Related Manuals for Invacare Typhoon II

Summary of Contents for Invacare Typhoon II

  • Page 1 Yes, You Can.® Invacare® Typhoon II Electric wheelchair Operating manual...
  • Page 2 How can you get in touch with Invacare®? If you have any questions or need support, please contact your authorised Invacare® Dealer, who has the necessary know-how and equipment plus the special knowledge concerning your Invacare® product, and can offer you all-round satisfactory service. Should you wish to contact Invacare® directly, you can reach us in Europe at the following addresses and phone numbers.
  • Page 3 Bridgend Industrial Estate uk@invacare.com Mid Glamorgan - CF31-3PY eire@invacare.com United Kingdom WWW: www.invacare.co.uk Invacare Mecc San s.r.l. +39 - 0445 - 38 00 59 Via Dei Pini, 62 Fax: +39 - 0445 - 38 00 34 I - 36016 Thiene (VI) italia@invacare.com...
  • Page 4 +31 - (0)318 - 69 57 57 Celsiusstraat 46 Fax: +31 - (0)318 - 69 57 58 NL-6716 BZ Ede csede@invacare.com The Netherlands WWW: www.invacare.nl Invacare® PORTUGAL Lda +351-225105946 Rua Senhora de Campanhã 105 Fax: +351-225105739 P-4369-001 Porto portugal@invacare.com PORTUGAL WWW: www.invacare.pt...

  • Page 5: Table Of Contents

    Table of Contents Chapter Page Introduction Important symbols in this manual ..................12 Important symbols found on the vehicle ................13 1.2.1 Explanation of symbols on lifter warning sticker............13 Type classification and permissible use................14 Guarantee ..........................14 Indications..........................15 Life expectancy........................15 Safety Notes General Safety Notes ......................16 Safety information with regard to care and maintenance ...........19 Safety Information on Electromagnetic Interference............20 Safety Information on Driving and Freewheel Mode............21...
  • Page 6 Parking and stationary......................30 Taking Obstacles........................30 5.3.1 The ”SureStep“ System ....................30 5.3.2 Maximum obstacle height .....................30 5.3.3 Safety information when ascending obstacles .............31 5.3.4 The correct way to overcome obstacles ...............32 Driving up and down gradients....................33 Pushing the wheelchair by hand Electrically disengaging gearless motors ................34 Manually disengaging gearless motors (emergency disengaging) ........36 The REM 24 SD Remote...
  • Page 7 8.1.3 Setting the height of the armrests.................55 8.1.4 Setting the height of the parallel sliding armrests............56 8.1.5 Adjusting the angle of the armpad on the parallel sliding armrests......57 8.1.6 Setting the width of the side sections ................58 Manually adjusting the seat tilt ....................60 Manually adjusting the backrest ....................62 8.3.1 Adjusting the backrest using the gas pressure spring..........62...
  • Page 8 9.2.2.5 Adjusting the depth of the calf plate ................87 9.2.2.6 Adjusting the height of the calf plate ...............88 9.2.2.7 Unlocking and swivelling the calf plate backward when alighting ......89 9.2.2.8 Adjusting the angle adjustable foot plate..............90 9.2.2.9 Adjusting the angle and depth adjustable foot plate ..........91 9.2.3 Manually height adjustable legrest 80°...
  • Page 9 10.2.3.1 Removing the batteries..................116 10.2.3.2 How to handle damaged batteries correctly ............126 11 Care and maintenance 12 Maintenance- and repair work 12.1 Repairing a flat tyre .......................130 12.1.1 Repairing punctures (drive wheel with GB motor and pneumatic tyres) ....131 13 Transport 13.1 Transferring the wheelchair to another vehicle ..............134 13.2...

  • Page 10: Introduction

    The decision whether the model is suitable for the user may only be taken by medical specialists with appropriate expertise. Invacare® or their statutory representatives can accept no liability in cases in which the wheelchair has not been adapted to suit the users’ handicaps.
  • Page 11 This manual contains copyrighted information. This manual may not be reproduced or reprinted either partly or completely without previous written consent from Invacare® or its statutory representatives. We reserve the right to make any necessary alterations on the grounds of...

  • Page 12: Important Symbols In This Manual

    Important symbols in this manual WARNING! This symbol warns you of danger! • Always follow these instructions to avoid injury to the user or damage to the product! EXPLOSION HAZARD! This symbol warns you of an explosion hazard, an example of which can be caused by excessive tyre pressure in a pneumatic tyre! •...

  • Page 13: Important Symbols Found On The Vehicle

    Important symbols found on the vehicle This product has been supplied from an environmentally aware manufacturer that complies with the Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/CE. This product may contain substances that could be harmful to the environment if disposed of in places (landfills) that are not appropriate according to legislation.

  • Page 14: Type Classification And Permissible Use

    Type classification and permissible use This vehicle was designed for persons whose ability to walk is impaired, but who are still physically and mentally able to operate an electric vehicle. It has been classified according to EN 12184 as a class B mobility product (for indoor and outdoor areas).

  • Page 15: Indications

    Indications The use of this mobility product is recommended for the following indications: The inability or a greatly restricted ability to walk within the scope of the basic requirement to be able to move within one’s own four walls. The need to leave the dwelling place in order to get some fresh air during a short walk or to reach those places generally to be found at close distance to the dwelling and where everyday business is carried out.

  • Page 16: Safety Notes

    Safety Notes • READ WELL BEFORE OPERATION! General Safety Notes Danger of injury if wheelchair is used in any other way than the purpose described in this manual! • Only ever use the wheelchair in accordance with the instructions in this User's Manual! •...
  • Page 17 Danger of injury if the wheelchair is switched off while driving, for example by pressing the On/Off Button or disconnecting a cable, due to it coming to an abrupt, sharp stop! • If you have to brake in an emergency, simply release the joystick which will bring you to a halt! Danger of injury when transferring wheelchair to a vehicle for transport with the occupant seated in it! •...
  • Page 18 Danger of fire or breaking down due to electric devices being connected! • Do not connect any electric devices to your wheelchair that are not expressly certified by Invacare® for this purpose! Have all electrical installations done by your authorised Invacare® Dealer!

  • Page 19: Safety Information With Regard To Care And Maintenance

    Safety information with regard to care and maintenance Danger of accident and loss of guarantee if maintenance is insufficient! • For reasons of safety and in order to avoid accidents which result from unnoticed wear, it is important that this electric vehicle undergoes an inspection once every year under normal operating conditions (see inspection plan contained in service instructions)! •...

  • Page 20: Safety Information On Electromagnetic Interference

    Safety Information on Electromagnetic Interference This electric vehicle was successfully tested in accordance with International standards as to its compliance with Electromagnetic Interference (EMI) Regulations. However, electromagnetic fields, such as those generated by radio and television transmitters, and cellular phones, can influence the functions of electric vehicles.

  • Page 21: Safety Information On Driving And Freewheel Mode

    Safety Information on Driving and Freewheel Mode Danger of injury if the wheelchair tips over! • Only ever negotiate gradients up to the maximum tilt-resistant gradient (see Technical Specifications) and only with the backrest and seat tilt (if fitted) in an upright position! •...
  • Page 22 Danger of breaking down in adverse weather conditions, i.e. extreme cold, in an isolated area! • If you are a user with severely limited mobility, we advise that in the case of adverse weather conditions DO NOT attempt a journey without an accompanying attendant! Danger of injury if your foot slides off the footrest and gets caught underneath the wheelchair when it is in motion! •...

  • Page 23: Safety Information On Wheelchairs With A Lifter

    Safety Information on Wheelchairs with a Lifter IMPORTANT - IF YOUR WHEELCHAIR IS EQUIPPED WITH A LIFTER: Danger of injury if the wheelchair tips over! • Never exceed the maximum permissible load (see Technical Specifications)! • Avoid dangerous driving situations when the lifter is in a raised position, such as trying to overcome obstacles like kerbs or driving up or down steep gradients! •...

  • Page 24: Safety Information On Maintenance Work And Alterations To The Wheelchair

    Safety information on maintenance work and alterations to the wheelchair WARNING: Danger of injuries and damage to the wheelchair, in case the suspension is adjusted without the immobilisation mechanism of the front anti-tippers being re- adjusted! • When the hardness of the suspension is adjusted, the immobilisation mechanism of the front anti-tippers must without fail be checked and, if necessary, also re-adjusted!

  • Page 25: Key Features

    Key features 1) Button for disengaging drive (on push handle) 2) Armrest 3) Lever for disengaging a motor (only visible on right-hand side of picture) 4) Drive wheel 5) Remote 6) Legrests...

  • Page 26: Getting In And Out Of The Wheelchair

    Getting in and out of the wheelchair Important information when side transferring in and out of the wheelchair In order to side transfer it is necessary for the armrest to either be raised or removed completely depending on the model. A skirtguard can be installed as an option in connection with the parallel sliding armrest.

  • Page 27: Raise The Parallel Sliding Armrest / Remove The Skirtguard (Optional)

    Raise the parallel sliding armrest / remove the skirtguard (optional) Swivelling the armrest up • Swivel the armrest up to access from the side. Remove the clothes guard (option) for access • Disengage the release handle (1). • Pull the skirt guard out of the holder.
  • Page 28 Getting into the wheelchair: • Position your wheelchair as close as possible to your seat. This might have to be done by an attendant. • Switch your wheelchair off. • Apply the hand brake of your wheelchair (if existing). • Detach the side part of your wheelchair or swivel it up. •...

  • Page 29: Driving

    Driving Before driving for the first time... Before you take your first trip, you should familiarise yourself well with the operation of the vehicle and with all operating elements. Take your time to test all functions and driving modes. NOTE: If installed, make sure to properly adjust and use the posture belt each time you use the wheelchair.

  • Page 30: Parking And Stationary

    Parking and stationary When parking your vehicle or if your vehicle is stationary for a prolonged period: • Switch the vehicle's power system off (ON-/OFF key). • Activate your anti-theft lock, if existing. Taking Obstacles 5.3.1 The ”SureStep“ System This electric wheelchair is fitted with "SureStep" technology. When climbing over obstacles, the front steering wheels are raised using the torque generated by the drive wheels.

  • Page 31: Safety Information When Ascending Obstacles

    5.3.3 Safety information when ascending obstacles CAUTION: Danger of Tipping Over! • Never approach obstacles at an angle! • Put your backrest into an upright position before climbing an obstacle! CAUTION: The wheelchair can be damaged if an obstacle is approached at excessive speed.

  • Page 32: The Correct Way To Overcome Obstacles

    5.3.4 The correct way to overcome obstacles Ascending and descending Right The same approach applies to both ascending and descending obstacles: • Approach the obstacle or the kerb slowly and at a right angle. • Stop shortly before the front wheels come into contact with the obstacle. Wrong •...

  • Page 33: Driving Up And Down Gradients

    Driving up and down gradients For information concerning the maximum safe slope, please see chapter "Technical Specifications" starting on page 144. WARNING: Danger of tipping over! • Only ever drive downhill at a maximum of 2/3 of the top speed! Avoid sudden changes of direction or abrupt braking when driving on slopes! •...

  • Page 34: Pushing The Wheelchair By Hand

    Pushing the wheelchair by hand The motors of the wheelchair are equipped with automatic brakes, preventing that the wheelchair starts rolling out of control when the joystick box is switched off. When pushing the wheelchair, the magnetic brakes must be disengaged. Electrically disengaging gearless motors CAUTION! Danger of the wheelchair rolling away! •...
  • Page 35 Disengaging motors: • Press key (1). A peep tone will sound for about one second. The motors remain disengaged until a key is pressed (if you cannot hear the peep tone, or the peep tone stops after around one second, there is an error.

  • Page 36: Manually Disengaging Gearless Motors (Emergency Disengaging)

    Manually disengaging gearless motors (emergency disengaging) Danger of the vehicle running away! • When the motors are disengaged (for push operation), the electromagnetic motor brakes are deactivated! When the vehicle is parked, the levers for engaging and disengaging the motors must without fail be locked firmly into the "DRIVE"...

  • Page 37: The Rem 24 Sd Remote

    The REM 24 SD Remote Layout of the remote Upper side Controls Immobilizer "Activate / scroll through drive mode" button Horn Left-hand indicator Joystick "Activate adjustment mode" button ON/OFF button Light Right-hand indicator 10) Hazard warning signal flasher...
  • Page 38 Upper side Displays 11) Battery charger display 12) Status display (in key symbol) 13) Drive mode display 14) Left-hand indicator display 15) Hazard warning signal flasher display 16) Light display 17) Right-hand indicator display...
  • Page 39 Underside 1) Charger socket 2) Programming socket Rear panel Socket for Buddy button 1 (corresponds to "Activate / scroll through drive mode" button). Socket for Buddy button 2 (corresponds to "ON/OFF" button) Socket for Buddy button 3 (corresponds to "Activate / scroll through adjustment mode"...

  • Page 40: On/Off Diode (Status Display)

    ON/OFF diode (status display) INFORMATION The ON/OFF diode (in key symbol) also serves as status or error message display. For error codes please see chapter "Error codes and diagnostic codes" on page 49. Battery charger display • Battery charger display All diodes illuminated: Full range •...

  • Page 41: Activating / Deactivating The Immobilizer

    Immobilizer • Switch on the remote. • Use the end of the magnetic key (Invacare® Logo) to move over the sensor area (1) on the remote (key symbol). The horn will sound briefly once. The remote shuts down automatically. The immobilizer is activated.

  • Page 42: Using The Buddy Buttons With The Remote

    Using the Buddy buttons with the remote What is a Buddy button? A Buddy button is an additional sensing device that can be used to activate a remote function. The sockets for Buddy buttons are to be found at the rear of the remote. Socket 1 (corresponds to the ""Activate / scroll through drive mode""...

  • Page 43: Controlling The Wheelchair Using The Remote

    • Invacare® supplies all electric vehicles from the factory with a standard drive programme. Invacare® can only assume a warranty for the safe vehicle handling of the electric vehicle – in particular tipping stability - for this standard drive programme! Will the wheelchair not drive after switching on? Check the drive-away lock (see chapter "Activating / deactivating the immobilizer "...

  • Page 44: How A Wheelchair With "Indirect Steering" Reacts To Joystick Movements

    7.6.1 How a wheelchair with "Indirect Steering" reacts to joystick movements. "Indirect Steering" occurs by individually applying power to the drive wheels, and is found on wheelchairs with front, rear and middle wheel drive. Travel direction The further the joystick is moved in a particular direction, the more dynamically the wheelchair reacts.

  • Page 45: Operating The Electric Adjustment Options

    Operating the electric adjustment options Electric adjustment options, like electric legrests or an electric backrest, are operated by using the joystick. 7.7.1 Activating adjustment mode • Press the "activate adjustment mode" button (A). The remote switches to the adjustment mode last used. The driving mode display (B) switches to the appropriate symbol (one of the symbols shown below).

  • Page 46: Selecting And Operating The Adjustment Option

    ECU mode (environment control unit). The standard REM 24 SD programming only supports the adjustment function. Please speak to your Invacare dealer if you have any questions in this respect. 7.7.2 Selecting and operating the adjustment option •...

  • Page 47: Changing Back To Driving Mode

    7.7.3 Changing back to driving mode • Briefly press the "Activate / scroll through driving mode" button (A). The remote switches back to the driving mode last used. The driving mode display indicates the drive level (B).

  • Page 48: Error Diagnosis

    Error diagnosis In the event that the electronics should show signs of failure, please consult the following troubleshooting guide in order to locate the error. INFORMATION Before beginning with the diagnosis, please ensure that the drive electronics are switched on. If the status display is OFF: Please check whether the drive electronics are SWITCHED ON.

  • Page 49: Error Codes And Diagnostic Codes

    7.8.1 Error codes and diagnostic codes The drive electronics are capable of rectifying some errors automatically. In this case the status display will cease to flash. Please switch the remote on and off several times. Wait approx. 5 seconds each time before switching the remote on again. If this does not rectify the error, locate the error using the flash codes shown below.
  • Page 50 FLASH FAULT IMMEDIATE MEASURE FURTHER HELP CODE Right motor defective. • • Check/replace motor Contact your dealer or wheelchair provider. Fault/brake fault on • • Check plug-in Contact your dealer or left-hand motor. connections. wheelchair provider. Connection loose/defective or motor defective. Left motor disengaged •...
  • Page 51 FLASH FAULT IMMEDIATE MEASURE FURTHER HELP CODE Motors overstressed. • • Switch remote off and on again Compatibility • Contact your dealer or problems between the wheelchair provider. modules.

  • Page 52: Adjusting The Wheelchair To The User's Seating Posture

    Adjusting the wheelchair to the user's seating posture WARNING: Danger of damage to the wheelchair and of accidents! With some combinations of adjustment options, collisions can occur between the legrest and the chassis or between the foot plates and the ground!This occurs in particular on wheelchairs with a lifter! •...

  • Page 53: Adjusting The Armrests And The Joystick Box

    Adjusting the armrests and the joystick box 8.1.1 Adapting the remote to the length of the user’s arm Requirements: • Allen key 3 mm • Loosen the socket head screw (1). • Set remote to the desired length by pushing forward or backward.

  • Page 54: Setting The Height Of The Remote

    8.1.2 Setting the height of the remote • Loosen one or both of the wing screws (1 and 2) that allow height adjustment of the joystick box. • Adjust the joystick box to the desired height. • Re-tighten the screw(s).

  • Page 55: Setting The Height Of The Armrests

    8.1.3 Setting the height of the armrests • Loosen the release handle (1). • Set the armrest at the desired height. • Tighten the release handle.

  • Page 56: Setting The Height Of The Parallel Sliding Armrests

    8.1.4 Setting the height of the parallel sliding armrests Requirements: • Allen key 2 mm • Loosen the screws (1) with the 2 mm Allen key on both sides of the spindle. • Turn the spindle clockwise (A). The armrest is raised.

  • Page 57: Adjusting The Angle Of The Armpad On The Parallel Sliding Armrests

    8.1.5 Adjusting the angle of the armpad on the parallel sliding armrests Requirements: • Allen key 4 mm • Open-end spanner 10 mm • Loosen the screw (1, on the inner side of the armrest), which allows adjustment of the angle of the armpad, while countering the nut (2, outer side of the armrest) with the...

  • Page 58: Setting The Width Of The Side Sections

    8.1.6 Setting the width of the side sections The distance between the side sections can be adjusted by 5.5 cm on both sides (11 cm in total). Requirements: • Allen key 8 mm Where to find the adjustment screws The figure below shows the position of the screws (1) which allow armrest width adjustment (only the left side is shown in the illustration).
  • Page 59 Doing the adjustment • Loosen screw (1) • Adjust armrest to required position. • Retighten the screw. • Repeat this procedure for the second armrest.

  • Page 60: Manually Adjusting The Seat Tilt

    Manually adjusting the seat tilt The manual seat angle adjustment has an adjustable range of 0° to 15°. The seat angle is adjusted by means of a spindle, which is to be found at the front underneath the seat frame. When adjusting the seat angle it should be ensured that at least 1cm of the threaded bolt always remains inside the spindle and is not completely unscrewed from the spindle.
  • Page 61 • Loosen the counter nut (1) of spindle. • Adjust the seat angle by turning the spindle (2). • Re-tighten the counter nut...

  • Page 62: Manually Adjusting The Backrest

    Manually adjusting the backrest 8.3.1 Adjusting the backrest using the gas pressure spring The lever for adjusting the backrest is located on the opposite side from the Joystick Box under the armrest. The angle can be adjusted continuously between 0° and 30°. Adjusting angle of the backrest •...

  • Page 63: Adjust The Backrest Using The Perforated Plate

    8.3.1.1 Adjust the backrest using the perforated plate The angle of the backrest has six positions, from -10° to +30°. • Unscrew the hand screws (1) on both sides. • The backrest is adjusted by choosing a combination of one of the two bore holes in the backrest frame and one of the six bore holes in the fixing plate.

  • Page 64: Flex And Contour Seats

    8.3.2 Flex and Contour Seats • Set the angle by turning the hand wheel (1).

  • Page 65: The Lifter

    The Lifter The electric lifter is operated via the remote. Please see chapter "Operating the electric adjustment options" on page 45. Information regarding operation of the lifter at temperatures of less than 0 °C Our wheelchairs are fitted with safety mechanisms that prevent capacity overload of the electronic components.

  • Page 66: Adjusting Footrests And Legrests

    Adjusting footrests and legrests Centre-mounted legrests 9.1.1 Electric legrest The electric legrest is operated via the remote. Please see chapter "Operating the electric adjustment options" on page 45. The electric legrest can be lowered completely to assist getting out of the wheelchair. To do so, move your seat into the correct position by lowering the lifter or by means of a negative seat angle (tilted slightly to the front).

  • Page 67: Lowering The Electric Legrest Completely To Assist Getting Out Of The Wheelchair

    9.1.1.1 Lowering the electric legrest completely to assist getting out of the wheelchair Warning! Misuse may destroy the legrest. • Please read and carefully follow the instructions below. Getting in/out of the wheelchair • Set the lifter and tilt to a comfortable position. •...
  • Page 68 Lifting up the footplates • You are sitting in the wheelchair. • Put your feet beside the footplates. • Pull the lever (1). The footplates rise up automatically. • Let go the lever (1) and put your feet on the footplates.
  • Page 69 Warning! Danger of damage to the legrest! • Always make sure that the footplates are fully raised to the uppermost position before adjusting the angle of the legrest! • Disregarding this advice will cause damage to your legrest. Adjusting the legrest •...

  • Page 70: Adjustable Legrest

    9.1.2 Adjustable legrest 9.1.2.1 Adjusting the angle Prerequisites: • 1x 10 mm open-ended spanner • Use the open-ended spanner to loosen the counternut (1). • Move the legrest to the desired position by turning the spindle (2). • Tighten the counternut.

  • Page 71: Adjusting The Length Of The Legrest

    9.1.2.2 Adjusting the length of the legrest Prerequisites: • 1x 5 mm socket head spanner • Use the socket head spanner to loosen the fastening screws (1). • Slide the foot support to the desired height. • Tighten the fastening screws.

  • Page 72: Adjusting The Calf Plate To The Calf Width Of The User

    9.1.2.3 Adjusting the calf plate to the calf width of the user The calf plate of the legrest can be adapted to the user’s calf width by bending apart or together. • Bending the calf plate to the desired width.

  • Page 73: Adjusting The Angle Of The Foot Plate

    9.1.2.4 Adjusting the angle of the foot plate Prerequisites: • 1x 5 mm socket head spanner • Fold up the foot plates in order to access the adjusting screws. • Use the socket head spanner to adjust the adjusting screws (1). •...

  • Page 74: Laterally Mounted Legrests

    Laterally mounted legrests 9.2.1 Standard footrest with pre-set angle 9.2.1.1 Swivelling the footrest outward and/or removing The small unlocking button is located on the upper section of the footrest. When the footrest is unlocked, it can be swivelled inward or outward when getting into the wheelchair as well as being removed completely.

  • Page 75: Setting The Angle

    9.2.1.2 Setting the angle PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that there is an adequate distance between the legrests and the steering wheels or the ground! Pre-requisites: •...
  • Page 76 • Loosen the screw (1) using the Allen key. • Set the desired angle. • Re-tighten the screw.

  • Page 77: Setting The End Stop Of The Footrest

    9.2.1.3 Setting the end stop of the footrest Pre-requisites: • 1x 6 mm Allen key • 1x 10 mm open-ended spanner The end position of the footrest is determined by means of a rubber stop (1). The rubber stop can be screwed in or out (A) or pushed up or down (B).
  • Page 78 • Use the Allen key to loosen the screw (1) and swivel the footrest upward in order to access the rubber stop. • Use the open-ended spanner to loosen the counternut (1).
  • Page 79 • Move the rubber stop to the desired position • Re-tighten the counternut • Move the footrest to the desired position. • Re-tighten the screw.

  • Page 80: Adjusting The Length Of The Footrest

    9.2.1.4 Adjusting the length of the footrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that there is an adequate distance between the legrests and the steering wheels or the ground! Pre-requisites: •...

  • Page 81: Manually Height Adjustable Legrest 90° - 0

    9.2.2 Manually height adjustable legrest 90° - 0° 9.2.2.1 Swivelling the legrest outward and/or removing The small unlocking button is located on the upper section of the legrest. When the legrest is unlocked, it can be swivelled inward or outward when getting into wheelchair as well as being removed completely.

  • Page 82: Setting The Angle

    9.2.2.2 Setting the angle PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that there is an adequate distance between the legrests and the steering wheels or the ground! •...

  • Page 83: Setting The End Stop Of The Legrest

    9.2.2.3 Setting the end stop of the legrest Pre-requisites: • 1x 10 mm open-ended spanner The end position of the legrest is determined by means of a rubber stop (A). The rubber stop can be screwed in or out (A) or pushed up or down (B).
  • Page 84 • Disengage the release handle (1) and swivel the legrest upward in order to access the rubber stop. • Use the open-ended spanner to loosen the counternut (1).
  • Page 85 • Move the rubber stop to the desired position • Re-tighten the counternut • Move the footrest to the desired position. • Re-tighten the release handle.

  • Page 86: Adjusting The Length Of The Legrest

    9.2.2.4 Adjusting the length of the legrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that there is an adequate distance between the legrests and the steering wheels or the ground! Pre-requisites: •...

  • Page 87: Adjusting The Depth Of The Calf Plate

    9.2.2.5 Adjusting the depth of the calf plate The depth of the calf plate can be adjusted via the holding plate. The holding plate hole combinations allow 5 different depth settings. Pre-requisites: • 1x 10 mm open-ended spanner • Use the open-ended wrench to loosen the nut (1) and remove.

  • Page 88: Adjusting The Height Of The Calf Plate

    9.2.2.6 Adjusting the height of the calf plate Pre-requisites: • 1x 4 mm Allen key • Use the Allen key to loosen the screws (1). • Adjust to the desired position. • Re-tighten the screws.

  • Page 89: Unlocking And Swivelling The Calf Plate Backward When Alighting

    9.2.2.7 Unlocking and swivelling the calf plate backward when alighting • Press the calf plate straight down. • Unlock the legrest and swivel outward. The calf plate swivels backward on its own.

  • Page 90: Adjusting The Angle Adjustable Foot Plate

    • Lift leg over the heel strap and place on the ground. 9.2.2.8 Adjusting the angle adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen both set screws on the foot plate. •...

  • Page 91: Adjusting The Angle And Depth Adjustable Foot Plate

    9.2.2.9 Adjusting the angle and depth adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen the set screw on the foot plate (1). • Adjust the foot plate to the desired angle or depth. •...

  • Page 92: Manually Height Adjustable Legrest 80° - 0° With Ergonomic Length Adjustment

    9.2.3 Manually height adjustable legrest 80° - 0° with ergonomic length adjustment 9.2.3.1 Swivelling the legrest outward and/or removing The small unlocking button is located on the upper section of the legrest. When the legrest is unlocked, it can be swivelled inward or outward when getting into wheelchair as well as being removed completely.

  • Page 93: Setting The Angle

    9.2.3.2 Setting the angle PLEASE NOTE: Danger of crushing! • Do not reach inside the swivelling range of the legrest! PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that there is an adequate distance between the legrests and the steering wheels or the ground! •...
  • Page 94 • Lowering: Keep the legrest in the foot plate area, pull the lateral adjusting lever (1) and lower the legrest slowly.

  • Page 95: Adjusting The Length Of The Legrest

    9.2.3.3 Adjusting the length of the legrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that there is an adequate distance between the legrests and the steering wheels or the ground! Pre-requisites: •...

  • Page 96: Adjusting The Depth Of The Calf Plate

    9.2.3.4 Adjusting the depth of the calf plate The depth of the calf plate can be adjusted via the holding plate. The holding plate hole combinations allow 5 different depth settings. Pre-requisites: • 1x 10 mm open-ended spanner • Use the open-ended wrench to loosen the nut (1) and remove.

  • Page 97: Adjusting The Height Of The Calf Plate

    9.2.3.5 Adjusting the height of the calf plate Pre-requisites: • 1x 4 mm Allen key • Use the Allen key to loosen the screws (1). • Adjust to the desired position. • Re-tighten the screws.

  • Page 98: Unlocking And Swivelling The Calf Plate Backward When Alighting

    9.2.3.6 Unlocking and swivelling the calf plate backward when alighting • Press the calf plate straight down. • Unlock the legrest and swivel outward. The calf plate swivels backward on its own.

  • Page 99: Adjusting The Angle Adjustable Foot Plate

    • Lift leg over the heel strap and place on the ground. 9.2.3.7 Adjusting the angle adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen both set screws on the foot plate. •...

  • Page 100: Adjusting The Angle And Depth Adjustable Foot Plate

    9.2.3.8 Adjusting the angle and depth adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen the set screw on the foot plate (1). • Adjust the foot plate to the desired angle or depth. •...

  • Page 101: Electrically Height Adjustable Legrest 80° - 0° With Ergonomic Length Adjustment

    9.2.4 Electrically height adjustable legrest 80° - 0° with ergonomic length adjustment 9.2.4.1 Swivelling the legrest outward and/or removing The small unlocking button is located on the upper section of the legrest. When the legrest is unlocked, it can be swivelled inward or outward when getting into wheelchair as well as being removed completely.

  • Page 102: Setting The Angle

    9.2.4.2 Setting the angle PLEASE NOTE: Danger of crushing! • Do not reach inside the swivelling range of the legrest! PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that there is an adequate distance between the legrests and the steering wheels or the ground! The electrically height adjustable legrest is operated via the remote.

  • Page 103: Adjusting The Length Of The Legrest

    9.2.4.3 Adjusting the length of the legrest PLEASE NOTE: Danger of injury due to incorrect adjustment of the footrests and legrests. • Before and during every journey it is imperative to ensure that there is an adequate distance between the legrests and the steering wheels or the ground! Pre-requisites: •...

  • Page 104: Adjusting The Depth Of The Calf Plate

    9.2.4.4 Adjusting the depth of the calf plate The depth of the calf plate can be adjusted via the holding plate. The holding plate hole combinations allow 5 different depth settings. Pre-requisites: • 1x 10 mm open-ended spanner • Use the open-ended wrench to loosen the nut (1) and remove.

  • Page 105: Adjusting The Height Of The Calf Plate

    9.2.4.5 Adjusting the height of the calf plate Pre-requisites: • 1x 4 mm Allen key • Use the Allen key to loosen the screws (1). • Adjust to the desired position. • Re-tighten the screws.

  • Page 106: Unlocking And Swivelling The Calf Plate Backward When Alighting

    9.2.4.6 Unlocking and swivelling the calf plate backward when alighting • Press the calf plate straight down. • Unlock the legrest and swivel outward. The calf plate swivels backward on its own.

  • Page 107: Adjusting The Angle Adjustable Foot Plate

    • Lift leg over the heel strap and place on the ground. 9.2.4.7 Adjusting the angle adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen both set screws on the foot plate. •...

  • Page 108: Adjusting The Angle And Depth Adjustable Foot Plate

    9.2.4.8 Adjusting the angle and depth adjustable foot plate Pre-requisites: • 1x 5 mm Allen key • Use the Allen key to loosen the set screw on the foot plate (1). • Adjust the foot plate to the desired angle or depth. •...

  • Page 109: Electrical System

    Electrical System 10.1 Electronics Protection System The vehicle's electronics are equipped with an overload-protection system. If the motors are put under considerable strain for a longer period of time (for example, when driving up a steep hill) and especially when the ambient temperature is high, then the electronic system could overheat.

  • Page 110: 10.1.1 The Main Fuse

    NOTE A defective main fuse may be replaced only after checking the entire electric system. An Invacare® specialised dealer must perform the replacement. You can find information on the fuse type in chapter "Technical Specifications" starting on page 144. All electrical equipment fitted to the wheelchair is protected against overload by the main fuse.

  • Page 111: Batteries

    10.2 Batteries 10.2.1 What you need to know about batteries Power is supplied by two 12V gel batteries. The batteries are maintenance-free and only need regular charging. New batteries should always be fully charged once before their first use. New batteries will be at their full capacity after having run through approx.
  • Page 112 The batteries cannot be overcharged with the specified charger. Please use only charging devices in Class 2. This class of chargers may be left unattended during charging. All charging devices which are supplied by Invacare® and comply with these requirements.

  • Page 113: 10.2.2 Charging The Batteries

    Danger of explosion and destruction of batteries if the wrong battery charger is used! • Only ever use the battery charger supplied with your vehicle, or a charger that has been approved by Invacare®! Danger of electric shock and damage to the battery charger if it is allowed to get wet! •...
  • Page 114 Charging the batteries • Switch off the wheelchair at the Joystick Box. • Connect the battery charger to the Joystick Box - the charging socket is located on the bottom of the Joystick Box (1). • Connect battery charger to the mains outlet and switch on if necessary.

  • Page 115: 10.2.3 Removing And Fitting Batteries

    10.2.3 Removing and fitting batteries WARNING: Danger of injury if the batteries are not handled correctly during assembly and maintenance work! • New batteries should be installed by authorised technicians! • Observe the warnings on the batteries! • Take into account the heavy weight of the batteries! •...

  • Page 116: 10.2.3.1 Removing The Batteries

    10.2.3.1 Removing the batteries CAUTION: Risk of fire and burns if battery poles are bridged! • When replacing the batteries the battery poles MUST NOT come into contact with metal parts of the wheelchair causing bridging. • Be sure to replace the battery pole caps after the batteries have been replaced. WARNING: Risk of fire and burns due to damage to the battery cables! •...
  • Page 117 • Run the seat lifter to the top position. • Remove legrests • Pull out the actuator bolt locking at the belt.
  • Page 118 • One person now pulls the seat upwards, and a second person ensures that the actuator bolt head (1) is guided out of its mounting and does not jam.
  • Page 119 • Push the holding mechanism (1) completely to the front so that it engages. • Run the actuator bolt down completely. • Pull the cladding off forwards.
  • Page 120 • Loosen the screws (1) on both sides with the 8 mm Allen key and remove. • Press the bottom actuator holder lightly inwards together with the regulator motor.
  • Page 121 • ..then lift (1) and pull out completely to the front (2). In doing so it can be helpful to use one hand under the chassis to guide the actuator holder locking pin into the position from which it can be pulled out upwards. •...
  • Page 122 • Remove the terminal cover from the battery terminals (1). • First undo the bolt on the negative terminal (black cable) with the 11 mm jaw spanner. • After this, undo the bolt on the positive terminal (red cable). CAUTION! Danger of crushing! •...
  • Page 123 CAUTION! Fire hazard! Cables can be jammed and frayed. • Please ensure that the cables are correctly located. They may not protrude into the lifter area. Use cable clamps if necessary. When installing new batteries, no cables may be located between the front battery and the lifter actuator! If so, they can be damaged when the lifter is actuated! WRONG! RIGHT!
  • Page 124 Please note The battery terminals on the rear battery must face the rear, and the terminals on the front battery must face the front. The batteries cannot be connected in any other alignment. CAUTION! Danger of crushing! • Please ensure that the actuator head slides into the top bracket. •...
  • Page 125 • Raise the seat slightly and release the holding mechanism (1). Lower the seat slowly until the weight of the lifter is resting on the actuator again. • Check all vehicle functions. • Check the new battery status and charge completely.

  • Page 126: 10.2.3.2 How To Handle Damaged Batteries Correctly

    • Only ever transport damaged batteries in an appropriate acid-resistant receptacle. • Wash all objects that have come into contact with acid with lots of water. Disposing of dead or damaged batteries correctly Dead or damaged batteries can be given back to your dealer or directly to Invacare®.

  • Page 127: Care And Maintenance

    Care and maintenance NOTE: Have your vehicle checked once a year by an authorised Invacare® dealer in order to maintain it's driving safety and roadworthiness. Cleaning the vehicle When cleaning the vehicle, pay attention to the following points: • Only use a damp cloth and gentle detergent.
  • Page 128 Maintenance Jobs Seat and backrest padding: - Check for perfect condition. Side part and armrest: - Are all fastening elements installed? - Can armrests / side parts be removed and installed without too much physical effort? - Are armrests secured in their positions? Legrests: - Do legrests lock into place without any problem? (Only applies to detachable legrests)
  • Page 129 - Clean all parts carefully. When necessary Have your vehicle inspected and serviced once a year by your authorised dealer. A complete checklist of necessary maintenance work can be found in the Service Manual, which can be obtained from Invacare®.

  • Page 130: Maintenance- And Repair Work

    "Technical Specifications" on page 144, or consult the Service Manual, available from Invacare® (in this connection please see the addresses and phone numbers in section "How can you get in touch with Invacare®?" on page 2). In case you require assistance, please contact your Invacare® Dealer.

  • Page 131: Repairing Punctures (Drive Wheel With Gb Motor And Pneumatic Tyres)

    12.1.1 Repairing punctures (drive wheel with GB motor and pneumatic tyres) EXPLOSION HAZARD! The wheel will explode if you do not let the air out of the tyre before removing the wheel! • Always let the air out of the tyre before removing it (press in the pin in the middle of the valve)! Injury hazard!If the wheel has been insufficiently tightened during assembly, it can become loosened during driving!
  • Page 132 Disassembly • Block up the vehicle (place wooden blocks under frame). • Unscrew valve cap. • Depressurise tyre by pressing in the pin in the valve (1). • Unscrew 5 screws (2). • Remove the wheel rim halves. • Remove the inner tube from the tyre. NOTE: If the old inner tube is to be repaired and re-used, and has become wet during repair, you can make replacement easier by sprinkling the inner tube with a little talcum powder.
  • Page 133 • Repair inner tube and replace, or insert new. • Replace the inner tube in the tyre. • Insert the wheel rim halves once again. • Insert the screws and tighten slightly. • Pump a little air into the inner tube. •...

  • Page 134: Transport

    Transport 13.1 Transferring the wheelchair to another vehicle WARNING: Danger of tipping over, if the wheelchair is transferred to another vehicle with the user seated in it! • If the wheelchair has to be transferred to another vehicle over a ramp, then it must be secured against tipping over by an attendant standing behind it during the transfer process! •...

  • Page 135: Transportation Of The Wheelchair And Use As A Vehicle Seat

    These accessories are not included in the standard scope of wheelchair order and delivery, but can be obtained from Invacare as an option. This electric wheelchair complies with the requirements of ISO 7176/19-2001 and may be used as a vehicle seat in connection with an anchoring system that has been checked and approved in accordance with ISO 10542.
  • Page 136 Caution: There is a danger of injury if the wheelchair is not properly secured during use as a vehicle seat! • If possible, the user should always leave the wheelchair to use a vehicle seat and the seatbelts provided with the vehicle! •...

  • Page 137: 13.2.1 How The Wheelchair Is Anchored In A Vehicle For Use As A Vehicle Seat

    13.2.1 How the wheelchair is anchored in a vehicle for use as a vehicle seat The electric wheelchair is fitted with four anchoring points, which are labelled with the symbol shown on the right. Snap hooks or belt loops can be used for fixation.

  • Page 138: 13.2.2 How The User Is Secured Within The Wheelchair

    13.2.2 How the user is secured within the wheelchair Caution: there is a danger of injury if the user is not properly secured within the wheelchair! • Even if the wheelchair is fitted with a securing belt, this is no substitute for a proper seatbelt in a travelling vehicle! Always use the transport vehicle seatbelt! •...
  • Page 139 Seat belts may not be held at a distance The pelvic belt should be positioned in the from the user's body using parts of the area between the user's pelvis and thighs wheelchair such as armrests or wheels. so that it is unobstructed and not too loose. The ideal angle of the pelvic belt to the horizontal is between 45°...
  • Page 140 The safety belt of the transporting vehicle should be applied as shown in the illustration at right. 1) Centre line of the body 2) Centre of the sternum...

  • Page 141: Securing The Wheelchair For Transport Without Passengers

    13.3 Securing the wheelchair for transport without passengers CAUTION: Injury hazard! • If you are unable to fasten your electric wheelchair securely in a transport vehicle, we recommend that you do not transport it! • Before transporting your wheelchair, make sure the motors are engaged and that the Joystick Box is switched off.

  • Page 142: Refurbishment

    • Cleaning and disinfection. Please see chapter "Care and maintenance" on page 127. • Inspection according to service plan. Please consult service instructions, available from Invacare®. • Adaptation to the user. Please see chapter "Adjusting the wheelchair to the user's seating...

  • Page 143: Disposal

    Disposal • The equipment wrapping is potentially recyclable. • The metal parts are used for scrap metal recycling. • The plastic parts are used for plastic recycling. • Electric components and printed circuit boards are disposed of as electronic scrap. •...

  • Page 144: Technical Specifications

    Technical Specifications Permissible Operating and Storage Conditions Temperature range for operation • -25 … +50 °C according to ISO 7176-9: Temperature range for storage • -40 … +65 °C according to ISO 7176-9: Electrical system Motors • 2 x 500 W Batteries •...
  • Page 145 Driving characteristics Speed • 6 km/h • 10 km/h • 12 km/h Max. hill-climbing ability without • 20% (11.3°) overturning Max. climbable obstacle height • 7,5 cm Turning radius • 56 cm Drive range in accordance with • 52 km ISO 7176 *** Dimensions Standard...
  • Page 146 Dimensions Standard Contour Recaro Flex Seat height **** • 40 cm (+30 • 40 cm (+30 • 40 cm (+30 • 40 cm (+30 cm with cm with cm with cm with lifter) lifter) lifter) lifter) • 47 cm (+30 •...
  • Page 147 Dimensions Standard Contour Recaro Flex Legrest lengths • Short (for leg length 32-38 cm) • 29.5 - 35.5 • 29.5 - 35.5 • 29.5 - 35.5 • 29.5 - 35.5 • Medium (for leg length 38-44 • 35.5 - 41.5 •...
  • Page 148 *** Note: The drive range of an electric wheelchair is strongly influenced by external factors, such as the charging state of the batteries, surrounding temperature, local topography, road surface characteristics, tyre pressure, weight of driver, drive style and use of batteries for lighting, servos etc.

  • Page 149: Inspections Performed

    It is confirmed by stamp and signature that all jobs listed in the inspection schedule of the Service and Repair Instructions have been properly performed. The list of the inspection jobs to be performed can be found in the Service Manual which is available through Invacare®. Delivery Inspection...

This manual is also suitable for:

Typhoon ii standardTyphoon ii contourTyphoon ii recaroTyphoon ii flex

Table of Contents
