Summary of Contents for Verterx Standard VX-2200
- Page 1 American Communication Systems Discover the Power of Communications ™ http://www.ameradio.com TO ORDER – VISIT VX-2200 LTR PERATING ANUAL Vertex Standard LMR, Inc. 4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan...
- Page 2 AFETY ARNING NFORMATION WARNING - DO NOT operate the VX-2200 (LTR) radio when any person(s) (bystanders) outside the vehicle are within the distances shown in the chart at the bottom of this section. Safety Training information: Antennas used for this transmitter must not exceed an antenna gain of 0 dBd.
- Page 3 NTRODUCTION The VX-2200 LTR Series are full-featured FM transceivers designed for flexible mobile and base station business communications in the VHF or UHF Land Mobile bands. These transceiver are designed for reliable business communications in a wide variety of applications with a wide range of operating capability provided by their leading-edge design.
-
Page 4: Front Panel
In the factory default, pressing either button changes the current group (and displayed group number or name). Holding in either button for more than 1.5 second causes the radio to begin stepping (repeatedly) upward or downward through the groups. VX-2200 LTR S ERIES PERATING ANUAL... - Page 5 Low Transmt Power Mode Receiver Monitor “AUX A” Port is activated “Talk-Around” is enabled “Encryption” is enabled Home Zone/Group RSSI Indicator (four steps) 8 Character Alpha-numeric Display “Zone Scan” is enabled on the current Zone VX-2200 LTR S ERIES PERATING ANUAL...
-
Page 6: Rear Panel
An external loudspeaker may be connected to this 2-contact, 3.5-mm mini-phone jack. Caution: Do not connect either wire of this line to ground, and be certain that the speaker has adequate capability to handle the audio output (12 W) from the radio. VX-2200 LTR S ERIES PERATING ANUAL... - Page 7 VX-2200 LTR S ERIES PERATING ANUAL...
-
Page 8: Switching Power On/Off
If CTCSS or Digital Coded Squelch (DCS) Lockout has been programmed on a group, the radio can transmit only when there is no carrier being received or when the carrier being received includes the correct CTCSS tone or DCS code. VX-2200 LTR S ERIES PERATING... -
Page 9: Automatic Time-Out Timer
PTT switch and wait for the “penalty timer” to expire (if you press the PTT switch before this timer expires, the timer restarts, and you will have to wait another “penalty” period) VX-2200 LTR S ERIES PERATING... -
Page 10: Advanced Operation
DVANCED PERATION Programmable Function (PF) Buttons The VX-2200 LTR Series includes six Programmable Function (PF) Buttons. The PF button functions can be customized, via programming by your VERTEX STAN- DARD dealer, to meet your communications/network requirements. Some features may require the purchase and installation of optional internal accessories. The pos- sible PF button programming features are illustrated below, and these functions are explained on the pages to follow. -
Page 11: Description Of Operating Functions
Press (or press and hold) the assigned programmable key to select a different zone of groups. ONTINUOUS Press and holding in the assigned programmable key causes the radio to begin step- ping (repeatedly) upward or downward through the zones. VX-2200 LTR S ERIES PERATING ANUAL... - Page 12 “Low Power” mode. Press (or press and hold) the key again to return to “High Power” operation when in difficult terrain. When the radio’s transmitter is set to “Low Power” mode, the “ ” icon will be indicated on the display. VX-2200 LTR S ERIES PERATING ANUAL...
- Page 13 MERGENCY The VX-2200 LTR series include an “Emergency” feature which may be useful if you have someone monitoring on the same frequency as your transceiver’s channel. Press (or press and hold) the assigned programmable key to initiate an emergency call.
- Page 14 The precise lockout configuration must be programmed by your VERTEX STANDARD dealer. PTION This function is usable only when a FVP-35 Optional Unit is installed. It is used to toggle “on” or “off” the Rolling Encryption feature of the FVP-35. VX-2200 LTR S ERIES PERATING ANUAL...
-
Page 15: Arts (Auto Range Transpond System)
KILL status. When the radio is in the STUN status, the radio is not usable till a radio receives a REVIVE code. When the radio is in the KILL status, the radio is not usable, please bring the radio to your Vertex Standard dealer. VX-2200 LTR S ERIES PERATING... -
Page 16: Optional Accessories
Connection Cable for FIF-12 Availability of accessories may vary; some accessories are supplied standard per local requirements, others may be unavailable in some regions. Check with your VERTEX STANDARD Dealer for changes to this list. VX-2200 LTR S ERIES PERATING ANUAL... - Page 17 VX-2200 LTR S ERIES PERATING ANUAL...
- Page 18 VX-2200 LTR S ERIES PERATING ANUAL...
- Page 19 Part 15.21: Changes or modifications to this device not expressly approved by Vertex Standard could void the user’s authorization to operate this device.
- Page 20 Copyright 2012 Printed in China Vertex Standard LMR, Inc. All rights reserved. No portion of this manual may be reproduced without the permission of Vertex Standard LMR, Inc.
