Functional Settings - Control M6004 Instruction Manual

Programming
Humidifier Control
1. Verify that the humidifier is correctly wired to the thermostat (see installation guide or contact an electrician).
2. Ensure the thermostat is in HEAT mode. While in HEAT mode, at the end of Sunday P4 program,
press NEXT to view humidity setting.
3. Set humidity level using the UP/DOWN buttons.
4. Press DONE to save setting and to exit.
Note:
• The humidifier will automatically turn on if the relative humidity is lower than the humidity setting.
• Humidity is set in increments of 5%.
• The humidity level can be set from 20% to 70%
• The humidifer setting only functions when thermostat is in HEAT mode.
• Humidity is not pre-programmable; it must be set manually.
• When the humidifier is on, the HUMIDITY symbol will appear.
• To de-activate the humidifer, scroll DOWN to the lowest setting, displayed as OFF%.
21
