Onyx BE150 Manual

15.6”/18.5” bedside terminal intel atom n270 processor high performance low power consumption wide lcd with multimedia
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
B e d s i d e T e r m i n a l
B E 1 5 0 / 1 8 0
BE150/180
15.6"/18.5" Bedside Terminal
®
TM
Intel
Atom
N270 Processor
High Performance
Low Power Consumption
Wide LCD with Multimedia
st
BE150/180 Manual 1
Edition
June. 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BE150 and is the answer not in the manual?

Questions and answers

Related Manuals for Onyx BE150

Summary of Contents for Onyx BE150

  • Page 1 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 BE150/180 15.6”/18.5” Bedside Terminal ® Intel Atom N270 Processor High Performance Low Power Consumption Wide LCD with Multimedia BE150/180 Manual 1 Edition June. 2010...
  • Page 2 ONYX Healthcare Inc., assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein ONYX Healthcare Inc. reserves the right to make changes in the product design without notice to its users...
  • Page 3 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 Acknowledgments ® ®  Intel and Atom™ N270 are registered trademarks of Intel Corporation.  IBM, PC/AT, PS/2 are trademarks of International Business Machines Corporation.

  • Page 4: Packing List

    BE150 or BE180 Bedside Terminal.  VESA Mount Screws  Utility CD-ROM (Please insert the ONYX-BE150/180 CD-ROM into external CD-ROM drive.) which Contains User’s Manual (in PDF format), Drivers and Utilities If any of these items are missing or damaged, you should contact your distributor or sales representative immediately.
  • Page 5 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 Worldwide Offices: Onyx Healthcare, USA Inc. 2663 Saturn street, Brea, CA 92821, USA Tel : +1-714-996-1800 Fax: +1-714-996-1811 Email: usasales@onyx-healthcare.com...
  • Page 6 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 Onyx Healthcare (SU ZHOU) INC. Room 12, 2F, Building B, No.5 Xing Han Street, Suzhou Industrial...
  • Page 7 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 Safety & Warranty Read these safety instructions carefully. Keep this user's manual for later reference. Disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning.
  • Page 8 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 If any of the following situations arises, get the equipment checked by service personnel: a. The power cord or plug is damaged. b.
  • Page 9 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 Classification Degree of production against electric shock: not classified Degree of protection against the ingress of water: IPX1 Equipment not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen or nitrous oxide.
  • Page 10 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may...
  • Page 11 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 UL Module Description BE150/180 AC modules are developed to suitable for the Classification Mark requirement...
  • Page 12 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 Safety Symbol Description The following safety symbols are the further explanations for your reference. Medical equipment with respect to electric shock, fire and mechanical hazards only in accordance with UL 60601-1, and CAN/CSA C22.2 NO.

  • Page 13: Table Of Contents

    1.3 Specification..............1-4 1.4 Dimension...............1-9 Chapter 2 Hardware Installation 2.1 Safety Precautions............2-2 2.2 A Quick Tour of the BE150/180........2-3 2.3 Removing the rear maintenance cover......2-6 2.4 Hard Disk Drive (2.5” HDD) Installation .......2-7 Chapter 3 Award BIOS Setup 3.1 System Test and Initialization........3-2 3.2 Award BIOS Setup.
  • Page 14 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 3.12 Load Optimized Defaults..........3-7 3.13 Set Supervisor/User Password........3-7 3.14 Save & Exit Setup............3-8 3.15 Exit without saving ............3-8 Chapter 4 Driver Installation 4.1 Installation ..............4-2 4.2 Card Reader Driver Installation ........4-3...

  • Page 15: Chapter 1 General Information

    B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 Chapter General Information Chapter 1 General Information...

  • Page 16: Introduction

    1.1 Introduction —A bedside terminal solution for ultimate patient services that boosts patient satisfaction and well-beings. BE150/180 offers the highly scalable bedside infotainment solution to enhance patient experiences within the hospital. Packaged with renowned software solution partners, 15.6” BE150 and 18.5”...

  • Page 17: Feature

    B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0  Entertainment on Demand  Video-on-Demand  TV/Radio Broadcasting 1.2 Feature 15.6”/18.5” Wide Color TFT LCD display ...

  • Page 18: Specification

    CPU Processor LCD Controller Intel®945GSE, Shared memory up to 224MB System Memory Up to 2GB DDRII 400/533/667 BE150: 15.6” Wide Color TFT LCD Display BE180: 18.5” Wide Color TFT LCD Windows® 7 (32 bit & 64 bit) Windows® XP Pro OS Support Windows®...
  • Page 19 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 Main Specification (Cont.) 1 x 2.5” HDD (SATA) 1 x Type II Compact Flash (internal on board Storage Disk Drive socket) 1 x Smart Card Reader...
  • Page 20 ONYX LCD panels are qualified for industry standard conditions in the following: total 7 dead pixels on a screen or if there are 3 within 1 inch square area of each other on the display.
  • Page 21 5 Wire Resistive Resolution 2048 x 2048 Light Transmission > 80% 35 million activities Lifetime Mechanical Specifications Model BE150 Series BE180 Series Architecture Close-Frame Front Bezel Complete flat for ease of cleaning White/Gray Color Mounting / Holder VESA 75/100mm, Desk Top...
  • Page 22 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 Power Supply Requirement Power Supply FSP Group Inc. Adapter Mode: 120 W Model No. PMP120-14 Input Voltage AC: 100 ~ 240V;...

  • Page 23: Dimension

    B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 1.4 Dimension Bedside Terminal BE150 Bedside Terminal BE180 Chapter 1 General Information...

  • Page 24: Chapter 2 Hardware Installation

    B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 Chapter Hardware Installation Chapter 2 Hardware Installation...

  • Page 25: Safety Precautions

    B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 2.1 Safety Precautions  Always completely disconnect the power cord from your board whenever you are working on it.

  • Page 26: A Quick Tour Of The Be150/180

    B E 1 5 0 / 1 8 0 2.2 A Quick Tour of the BE150/180 Before you start to set up the BE150/180, please take a moment to familiarize yourself with the locations and purposes of the controls, drives, connections and ports. The following figures illustrate the fully loaded bedside terminal with all applicable options.
  • Page 27 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 Picture 2.2: Bedside Terminal Bottom-Up View Picture 2.3: Front Panel Closer Up View LCD On/Off Brightness: + Volume: -- Barcode Scanner Trigger...
  • Page 28 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 On the back of BE150/180 Bedside Terminal, the back I/O section (Digital IO, USB, LAN, and Power connector) is just below the VESA mounting area.

  • Page 29: Removing The Rear Maintenance Cover

    B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 2.3 Removing the rear maintenance cover Unplug USB, DIO, LAN, and Power cables before removing the unit from the mounting arm. Unscrew the VESA mount screws.

  • Page 30: Hard Disk Drive (2.5" Hdd) Installation

    B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 and remove the rear cover. 2.4 Hard Disk Drive (2.5” HDD) Installation 1. Remove the rear cover as previously instructed. 2.
  • Page 31 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 remove internal rear cover. (Note: Please un/lock power supply first during disassemblying or assemblying process.) Un/lock Power Supply First 4.
  • Page 32 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 5. Insert one side connector of SATA cable to the SATA socket on main board and other side of SATA cable to the SATA port on HDD.

  • Page 33: Chapter 3 Award Bios Setup

    B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 Chapter Award BIOS Setup Chapter 3 Award BIOS Setup...

  • Page 34: System Test And Initialization

    The CMOS memory has lost power and the configuration information has been erased. The ONYX-BE150/180 SD CMOS memory has an integral lithium battery backup for data retention. However, you will need to replace the complete unit when it finally runs down.

  • Page 35: Award Bios Setup

    B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 3.2 Award BIOS Setup Awards BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off.
  • Page 36 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 PnP/PCI Configurations This entry appears if your system supports PnP/PCI. PC Health Status This menu shows you the status of PC. Frequency/Voltage Control This menu shows you the display of frequency/Voltage Control.

  • Page 37: Standard Cmos Features

    3.6 Integrated Peripherals Choosing the Integrated Peripherals from the INITIAL SETUP SCREEN menu, and you will see the screen contains the manufacturer’s default values for the ONYX-BE150/BE180. 3.7 Power management Setup Choosing the Power Management Setup from the INITIAL SETUP SCREEN menu, and the screen contains the...

  • Page 38: Pnp/Pci Configuration

    B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 manufacturer’s default values for the ONYX-BE150/BE180. 3.8 PnP/PCI configuration Choosing the PnP/PCI configurations from the Initial Setup Screen menu, and you will see the screen contains the manufacturer’s default values for the ONYX-BE150/BE180.

  • Page 39: Load Optimized Defaults

    B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 3.12 Load Optimized Defaults When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Optimized Defaults (Y/N)? Pressing "Y"...

  • Page 40: Save & Exit Setup

    Setup program without recording any new value or changing old one. For more detailed information, you can refer to the "ONYX BIOS Item Description.pdf" file in the CD for the meaning of each setting in this chapter. Chapter 3 Award BIOS Setup...

  • Page 41: Chapter 4 Driver Installation

    M e d i c a l S t a t i o n O N Y X - B E 1 5 0 / B E 1 8 0 Chapter Driver Installation Chapter 4 Driver Installation 4-1...
  • Page 42 M e d i c a l S t a t i o n O N Y X - B E 1 5 0 / B E 1 8 0 There are several installation ways depending on the driver package under different Operating System application. Please insert the BE-150/180 Utility CD-ROM into the UL approved external CD-ROM drive.
  • Page 43 M e d i c a l S t a t i o n O N Y X - B E 1 5 0 / B E 1 8 0 A driver installation screen will appear, please follow the onscreen instructions to install the driver in sequence and click on the Next button.

  • Page 44: Card Reader Driver Installation

    M e d i c a l S t a t i o n O N Y X - B E 1 5 0 / B E 1 8 0 4.3 Card Reader Driver Installation 1. Click on the Card_Reader driver folder and then double click on the setup.exe 2.
  • Page 45 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 Appendix Miscellaneous Appendix A Miscellaneous A-...

  • Page 46: General Cleaning Tips

    ONYX Healthcare Inc. has tested and verified these cleaning disinfectants, CIDEX, Viraguard, Control III Disinfectant Germicide, Caviwipes, Dispatch Disinfectant Cleaner CLH69101, Puregreen 24 Disinfectant, can be used with the BE150/180. Use of any other disinfectants will void the warranty. Appendix A Miscellaneous...

  • Page 47: Cleaning Tools

    B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 A.2 Cleaning Tools Although many companies have created products to help improve the process of cleaning your computer and peripherals users can also use household items to clean their computers and peripherals.
  • Page 48 B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0  Cotton swabs - Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas in your keyboard, mouse, and other locations.

  • Page 49: Scrap Computer Recycling

    B e d s i d e T e r m i n a l B E 1 5 0 / 1 8 0 A.3 Scrap Computer Recycling If the computer equipments need the maintenance or are beyond repair, we strongly recommended that you should inform us as soon as possible for the suitable solution.
