Be ds i de Te rm i nal
O N Y X - B E 1 0 0
BE100
10.1" Mini Bedside Terminal
SAMSUNG S5PV210 800MHzProcessor
Ultra Low Power Consumption
Fanless & compact design
st
BE100 Manual 1
Edition
October , 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BE100 and is the answer not in the manual?

Questions and answers

Related Manuals for Onyx BE100

Summary of Contents for Onyx BE100

  • Page 1 Be ds i de Te rm i nal O N Y X - B E 1 0 0 BE100 10.1” Mini Bedside Terminal SAMSUNG S5PV210 800MHzProcessor Ultra Low Power Consumption Fanless & compact design BE100 Manual 1 Edition October , 2011...
  • Page 2 ONYX Healthcare Inc., assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein ONYX Healthcare Inc. reserves the right to make changes in the product design without notice to its users...
  • Page 3 Be ds i de Te rm i nal O N Y X - B E 1 0 0 Acknowledgments SAMSUNG S5PV210 800MHz Process are registered  trademarks of SAMSUNG.  IBM, PC/AT, PS/2 are trademarks of International Business Machines Corporation. ®...

  • Page 4: Packing List

    BE100 Bedside Terminal.  VESA Mount Screws  Utility CD-ROM (Please insert the ONYX-BE100 CD-ROM into  external CD-ROM drive.) which Contains User’s Manual (in PDF format), Drivers and Utilities If any of these items are missing or damaged, you should contact your distributor or sales representative immediately.
  • Page 5 Be ds i de Te rm i nal O N Y X - B E 1 0 0 Worldwide Offices: Onyx Healthcare, USA Inc. 2663 Saturn street, Brea, CA 92821, USA Tel : +1-714-996-1800 Fax: +1-714-996-1811 Email: usasales@onyx-healthcare.com Onyx Healthcare EUROPE B.V.
  • Page 6 O N Y X - B E 1 0 0 Onyx Healthcare (Nanjing) INC. Room 1318, Metallurgy Building , East Zhongshan Road, Nanjing, China Tel: +86-025-58859841 Fax: +86-025-85088070 Email: Jonwang@onyx-healthcare.com Onyx Healthcare Singapore PTE LTD 57 Genting Lane, #07-00, Singapore 349564 Tel: +65-67498749 Fax +65-67461595 Email: sgsales@onyx-healthcare.com...
  • Page 7 Be ds i de Te rm i nal O N Y X - B E 1 0 0 Safety & Warranty Read these safety instructions carefully. Keep this user's manual for later reference. Disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning.
  • Page 8 Be ds i de Te rm i nal O N Y X - B E 1 0 0 If any of the following situations arises, get the equipment checked by service personnel: a. The power cord or plug is damaged. b.
  • Page 9 Be ds i de Te rm i nal O N Y X - B E 1 0 0 “ WARNING: No modification of this equipment is allowed” Caution: It may cause the danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by the manufacturer.
  • Page 10 Be ds i de Te rm i nal O N Y X - B E 1 0 0 Classification Degree of production against electric shock: not classified Equipment not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen or nitrous oxide. Mode of operation: Continuous Type of protection against electric shock: Class I equipment ME EQUIPMENT must be connected to an appropriate power...
  • Page 11 Be ds i de Te rm i nal O N Y X - B E 1 0 0 This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation.
  • Page 12 Be ds i de Te rm i nal O N Y X - B E 1 0 0 UL Module Description BE100 AC modules are developed to suitable for the Classification Mark requirement...
  • Page 13 Be ds i de Te rm i nal O N Y X - B E 1 0 0 Safety Symbol Description The following safety symbols are the further explanations for your reference. Medical equipment with respect to electric shock, fire and mechanical hazards only in accordance with ANSI/AAMI ES 60601-1, and CSA C22.2 NO 60601-1-08-CAN/CSA Attention, consult ACCOMPANYING...

  • Page 14: Table Of Contents

    1.3 Specification ..............1-4 1.4 Dimension ..............1-10 Chapter 2 Hardware Installation 2.1 Safety Precautions ............2-2 2.2 A Quick Tour of the BE100 ..........2-3 2.3 Mounting Installing ............2-5 2.4 Powering on the unit………………………………………. Appendix A Miscellanea A.1 General Cleaning Tips..........A-2 A.2 Cleaning Tools ............

  • Page 15: Chapter 1 General Information

    Be ds i de Te rm i nal O N Y X - B E 1 0 0 Chapter General Information Chapter 1 General Information...

  • Page 16: Introduction

    O N Y X - B E 1 0 0 1.1 Introduction —A bedside terminal solution for ultimate patient services that boosts patient satisfaction and well-beings. BE100 offers the highly scalable bedside infotainment solution to enhance patient experiences within the hospital. Packaged with BE100 renowned...

  • Page 17: Feature

    Be ds i de Te rm i nal O N Y X - B E 1 0 0 1.2 Feature Samsung S5PV210 800MHz Processor * 10.1” (16:9) wide color TFT LED LCD display (1024 x 600) * Fanless & Compact Design * Smart Card Reader * Less than 10 watt power (Energy Saving) * Hardware Decoder Support:...

  • Page 18: Specification

    Be ds i de Te rm i nal O N Y X - B E 1 0 0 1.3 Specification Model Number BE100 Model Description 10.1” Low Power Mini Bedside Terminal with Multimedia Main Specification SAMSUNG S5PV210 800MHz CPU Processor...
  • Page 19 Membrane Function Brightness control (Brightness+, Brightness-) Programmable function key I/O (Cont.) 2 x 2W High Quality Speakers Speaker LCD Specification Model BE100 Series Display Type 10.1” Color TFT LCD 1024 x 600 Max. Resolution 16.7M Max. Colors Dot Size (mm) 0.3 x 0.3...
  • Page 20 Be ds i de Te rm i nal O N Y X - B E 1 0 0 All ONYX's LCD products are manufactured with High precision technology. However, there are a small number of defective pixels in all LCD panels that are not able to change color.
  • Page 21 Be ds i de Te rm i nal O N Y X - B E 1 0 0 Anti-microbial design (Optional) Infection control design IP/Analog Phone None/built-in mic Hand Set RFID Scanner Optional Smart Card Readers Bottom center placement on the unit Power Supply Requirement Eljintek Inc) Power Supply...
  • Page 22 Be ds i de Te rm i nal O N Y X - B E 1 0 0 CE/FCC Class B, EN60601-1-3, Applied Part Anti-microbial bezel material (optional) Infection Control Chapter 1 General Information...

  • Page 23: Dimension

    Be ds i de Te rm i nal O N Y X - B E 1 0 0 1.4 Dimension Chapter 1 General Information...

  • Page 24: Chapter 2 Hardware Installation

    Be ds i de Te rm i nal O N Y X - B E 1 0 0 Chapter Hardware Installation Chapter 2 Hardware Installation...

  • Page 25: Safety Precautions

    Be ds i de Te rm i nal O N Y X - B E 1 0 0 2.1 Safety Precautions  Always completely disconnect the power cord from your board whenever you are working on it.  Do not make connections while the power is on, because a sudden rush of power can damage sensitive electronic components.

  • Page 26: A Quick Tour Of The Be100

    O N Y X - B E 1 0 0 2.2 A Quick Tour of the BE100 Before you start to set up the BE100, please take a moment to familiarize yourself with the locations and purposes of the controls, drives, connections and ports.
  • Page 27 Be ds i de Te rm i nal O N Y X - B E 1 0 0 Picture 2.2: Bedside Terminal Rear View Chapter 2 Hardware Installation 2-4...

  • Page 28: Mounting Installing

    Attention: When operating the Medical PC, please allow 15cm clearance area for optimal heat dissipation 2.4 Powering on the unit 1. Connect the 12 DC adaptor to the DC jack of BE100 2. Press the on/off button on the front panel 3. The system will boot up automatically 4.
  • Page 29 Be ds i de Te rm i nal O N Y X - B E 1 0 0 2.5 Connecting the Unit 1. The unit can be connected to the internet thru the LAN port 2. It should be connected to a DHCP router for automatic IP assignment 3.
  • Page 30 Be ds i de Te rm i nal O N Y X - B E 1 0 0 2.6 Operating the Unit 1. The devices connecting to the unit can all be hot plugged. 2. Shutting down the system can be done by simply removing the power adaptor from the unit Chapter 2 Hardware Installation 2-7...

  • Page 31: Appendix A Miscellanea

    Be ds i de Te rm i nal O N Y X - B E 1 0 0 Appendix Miscellanea Appendix A Miscellanea A...

  • Page 32: General Cleaning Tips

    Try not to put any food, drink or cigarette around the computer. Please remember to clean up the computer by weekly. ONYX Healthcare Inc. has tested and verified these cleaning disinfectants, CIDEX, Viraguard, Control III Disinfectant Germicide, Caviwipes, Dispatch Disinfectant Cleaner CLH69101, Puregreen 24 Disinfectant, can be used with the BE150/180.

  • Page 33: Cleaning Tools

    Be ds i de Te rm i nal O N Y X - B E 1 0 0 B.2 Cleaning Tools Although many companies have created products to help improve the process of cleaning your computer and peripherals users can also use household items to clean their computers and peripherals.
  • Page 34 Be ds i de Te rm i nal O N Y X - B E 1 0 0  Cotton swabs - Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas in your keyboard, mouse, and other locations. ...

  • Page 35: Scrap Computer Recycling

    For the computers that are no longer useful or work well, please contact with worldwide distributors for recycling. The worldwide distributors show on the following website: http://www.onyx-healthcare.com.tw/Contact.php Note: Please follow the national requirement for unit disposal. Appendix A Miscellanea A...
