V ented Design

SoloX Series Vented Enclosure Applications

The Kicker SoloX is truly awesome in a vented enclosure as this is
what it was designed for. Throw out every experience you have ever
had with a vented speaker and prepare to be blown away! Our engi-
neers have designed several boxes that will truly irritate everyone
within a 3 mile radius.
Because a woofer of this magnitude has never been produced, even
we do not know the total capabilities of the SoloX. The following chart
shows three recommended vented enclosures for the SoloX: Tuner,
SUV, and SPL. Keep in mind, these enclosure volume recommenda-
tions are for the airspace inside the enclosure and include the dis-
placement of the woofer. Do not make the airspace any greater than
recommended. These enclosures are just scratching the abilities of
this woofer to blow away all other woofers on the market. So keep
your eye on the website for the newest sick enclosures!
6
Tuner :
SUV:
SPL:
This enclosure is intended for SPL ONLY! It is designed
to be used with test tones above 56Hz! Playing music
with frequencies below 56Hz will result in very, very bad
For more advice on box building, see the Choosing and Building
Enclosures page in the Tech Tips & FAQs section of the Support area
on the Kicker website, www.kicker.com Or call Technical Services at 1-
405-624-8583.
The hardware we include will work with baffles up to 1.5"
thick. For thicker baffles you will need to use longer 1/4" x 20
SoloX Subwoofer
S18X

Recommended Enclosures

5 cu.ft. Port: 60sq.in. x 14.5"
Fb= 35Hz, Pmax= 5000W
( with 25hZ subsonic filter)
10 cu.ft. Port: 150 sq.in. x 21"
Fb= 35Hz, Pmax=4500W
( with 25hZ subsonic filter)
10 cu.ft. Port: 300sq.in. x 9"
Fb= 56Hz, Pmax= 10000
(Above tuning freq. only)
See below!
things happening!!
ATTENTION!
hardware.
