- Page 1 Single Board Computer PEAK 870 Series User’s Manual 03-02-2006 Update Feb-06-2007 Edit User’s Manual is subject to change without prior notice. For any update, please visit our website: www.nexcom.com PEAK 870 User’s Manual Preface...
-
Page 2: Preface
This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. No part of this manual maybe reproduced, copied, translated or transmitted in any form or by any means without the prior written consent from NEXCOM International Co., Ltd. -
Page 3: Ce Certification
CE Certification The product(s) described in this manual complies with all applicable European Union (CE) directives if it has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling techniques. WARNINGS Read and adhere to all warnings, cautions, and notices in this guide and the documentation supplied with the chassis, power supply, and accessory... -
Page 4: Table Of Contents
Table of Content ……………...……………..……………………………………….………….…………………..2 Preface ………………..……………………………………….……………………………………..2 Copyright ………………………..………………………………..…………………………………….. 2 Disclaimer ……………………………………………..………………………………..…… 2 Acknowledgements ……………………..…………………………………………2 Regulatory Compliance Statements ……………..……….…2 Federal Communications Commission (FCC) For Class A Device ………………………………………………………………………………………...3 CE Certification ……………………………………………………………………………………..3 Safety Information ……………………………………………………………………………………. Table of Content Chapter 1 General Information 1.1 Main Feature…………………………………………………….…………………………………….. -
Page 5: Chapter 1 General Information
Chapter 1 General Information PEAK 870 User’s Manual Chapter 1... -
Page 6: Main Feature
1.1 Main Feature PEAK 870VL2 is the first PICMG 1.3 full-size Single Board Computer (SBC), which support Intel® Core™2 Duo technology. Featuring Intel® 945G and ICH7 chipsets, the PEAK870VL2 supports socket LGA775 of Intel® Pentium® 4/Pentium® D/Celeron® D processor with 533/800/1066 MHz FSB supporting speeds up to 3.8 GHz and Hyper-Threading technology. -
Page 7: Specifications
1.2 Specifications Core 2 Duo / Pentium 4 Pentium D / Celeron D LGA 775 FSB 400/533/800/1066 MHz PICMG 1.3 Golden Finger DDR2 DIMM Intel 945G DDR2 533/667MHz PCI Express x16 GMCH DDR2 DIMM PICMG 1.3 Golden Finger Intel GMA950 Graphics DMI 2GB/s 4 PCIe x1 or 1 PCIe x4 PCIe x1... - Page 8 Intel® 945G GMCH Integrated Intel® GMA 950, Max 128 MB of DVMT for graphics Display memory allocation Analog display support up to 2048 x 1536 @ 85 Hz for CRT AC＇ 97 Audio Codec, Realtek ALC655 Audio 3 x (1x4 pin header) for Line in /Line out /MIC in 1-minute increments from 1 to 255 minutes Watchdog Timer 1-second increments from 1 to 255 seconds...
-
Page 9: Power Consumption Measurement
- FCC Class A Ordering Information PEAK 870VL2 (LF) PICMG 1.3 Full-Size SBC, Intel 945GChipset, LGA775 Core 2 Duo CPU support.Max. 2 GB DDR2 400 DIMM, VGA integrated , 2 x Intel 82573L PCI Express Gigabit Ethernet, 4 x SATA ports 1.3 Power Consumption Measurement... -
Page 10: Board Layout
1.4 Board Layout Figure 1.2: Overview of PEAK 870 1.5 Board Dimensions Figure 1.3: Mechanical Drawing of the PEAK-870 PEAK 870 User’s Manual Chapter 1... - Page 11 Chapter 2 Jumper Setting PEAK 870 User’s Manual...
-
Page 12: Before You Begin
This chapter of the User’s Manual describes how to set jumpers. Note: The procedures that follow are generic for all PEAK 870 series. 2.1 Before You Begin Ensure you have a stable, clean working environment. Dust and dirt can get into components and cause a malfunction. -
Page 13: Setting Jumpers
2.3 Setting Jumpers A jumper is the simplest kind of electric switch. It consists of two metal pins and a cap. When setting the jumpers, ensure that the jumper caps are placed on the correct pins. When the jumper cap is placed on both pins, the jumper is SHORT. -
Page 14: Location Of Jumpers
2.4 Location of Jumpers DIMM DIMM SATA1 SATA0 J5 J7 JP14 JP11 Intel LGA775 JP15 Intel ICH7R socket LAN2 (CON1) Intel 945G Power Power LAN1 (CON2) □=PIN 1 JP12 JP13 Reset Buzzer Figure 2-1: Jumper Location Switch setting table (*: default setup) COM Port Type Select 1-20 2-19... - Page 15 Connector Define Connector Function NOTE System FAN 2 AUX +12V Power Floppy CPU FAN System FAN 1 SATA 0 SATA 1 GPIO External LPC connector USB 0/1 USB 2/3 COM 2 Primary IDE COM 1 External keyboard VGA connector Disk on module external power CF card socket IDE LED / Power LED / Power ON / Reset / Buzzer/SM Bus...
-
Page 16: Pin Definitions Of Connectors
2.5 Pin definitions of connectors J1/J7 : System FAN 2/ System FAN 1 Definition Definition Sense +12V J2 : AUX +12V Power Definition Definition +12V +12V J4 : Floppy Definition Definition DIR# DENSEL# STEP# Write Data# WGATE# INDEX# TK00# MOTEA# WPT# DRVB# Read Data#... - Page 17 J12 : GPIO Definition Definition GP25_D_IN1(PIN25) GP22_D_OUT2(PIN22) GP20_D_OUT0(PIN20) 8 GP26_D_IN2(PIN26) GP24_D_IN0(PIN24) GP23_D_OUT3(PIN23) GP21_D_OUT1(PIN21) 10 GP27_D_IN3(PIN27) J13 : External LPC connector Definition Definition ISA 14 MHZ LPC DRQ# LPC FRAME# +3.3V Series IRQ LPC Address 3 +3.3V LPC Address 2 Reset# LPC Address 1 LPC Address 0 PCI 33MHZ...
- Page 18 Data 5 IOCHRDY Data 10 Data 4 DMA ACK# Data 11 Data 3 Interrupt Data 12 Data 2 DiskAddress 1 Data 13 DMA66 Detect Data 1 DiskAddress 0 Data 14 DiskAddress 2 Data 0 HDCCS1# Data 15 HDCCS3# HDD Active # J19 : PIO Definition Definition...
- Page 19 J23 : Disk on module external power Definition Definition J24 : CF card socket Definition Definition Data 3 Data 11 Data 4 Data 12 Data 5 Data 13 Data 6 Data 14 Data 7 Data 15 HDCCS1# HDCCS3# IOR# IOW# Interrupt CF_CSEL# Reset#...
- Page 20 IRRX JP4 : Keyboard lock Definition Definition Keyboard Lock JP5 : Line-out Definition Definition LINEOUT_L LINEOUT_R JP6 : Line-in Definition Definition LINEIN_L LINEIN_R JP7: MIC-in Definition Definition MICIN2 MICIN1 JP9/JP11 : 82573L LAN1 LINK1000 LED / 82573L LAN2 LINK1000 LED Definition Definition Speed100#...
-
Page 21: Chapter 3 Expansion
Chapter 3 Expansion PEAK 870 User’s Manual Appendix B... -
Page 22: System Memory
3.1 System Memory PEAK 870 incorporates Intel 945G chipset supports dual channel non-ECC un-buffered DDR2 533/667 MHz memory up to 2GB. Two 240-pins DIMM sockets support up to a maximum 2GB DIMM. Followings are the recommended memory modules. Size (MB) Technology Type Vendor Remark... - Page 23 Figure 3-2: How to Install DIMM (2) 3. Then press the DIMM module down right into the socket, until a click is heard. That means the two handles automatically locked the memory modules into the right position of the DIMM socket. Figure 3-3: How to Install DIMM (3) 4.
-
Page 24: Installing Intel Pentium-M Cpu And Fan Heatsink
3.3 Installing LGA775 Intel Pentium-4 CPU, Heat Sink, and Fan Since the socket 775 is comprised of sensitive arrays of pins, improper or careless installation may cause permanent harm to the CPU. In some cases users may accidentally damage the socket simply by adjusting the position of the CPU. - Page 25 Step 3: a. Verify that the CPU if properly mated to the orientation keys. b. Close the upper plate, place the load lever back to the original position. Step 4: a. Place the Heat Sink with Fan Set onto the four holes around the CPU socket making sure that the four screws are aligned with the holes on the PEAK 870.
