EBC-3A1 Series
3.5'' SBC with NXP i.MX6 Processor
ARM ® Cortex A9 Architecture
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EBC-3A1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nexcom EBC-3A1 Series

  • Page 1 User Manual Ver. 5 EBC-3A1 Series 3.5’’ SBC with NXP i.MX6 Processor ARM ® Cortex A9 Architecture...
  • Page 2 Information in this document is subject to change without notice and does not represent a commitment on the part of NEXCOM. NEXCOM provides this document as is, without warranty of any kind, either expressed or implied, including, but not limited to, its particular purpose. NEXCOM reserves the right to make improvements and/or changes to this manual, or to the products and/or the programs described in this manual, at any time.
  • Page 3 Declaration of Conformity FCC Class A Note: this device has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communication.
  • Page 4 Document Amendment History Revision Date Remark Jan 2016 Initial released Mar 2016 Hardware User Guide modified Mar 2016 Software User Guide & System Recovery modified Aug 2018 Tidy-up full document and add new sections. Aug 2019 Modify JCOMA to JCOMD to /dev/ttyXRUSB0 ~ /dev/ttyXRUSB3...
  • Page 5: Table Of Contents

    Table of Contents Product Overview .................... 11 1.1. Introduction ..................11 1.2. Specification ..................11 1.3. Block Diagram ................. 13 Hardware User Guide ..................15 ........................15 2.1. DIP Switch Setting and Connector Locations ........15 2.2. DIP Switch Setting ................16 2.2.1.
  • Page 6 2.4. Mechanical Drawing ................24 Software User Guide ..................26 ........................26 3.1. Introduction ..................26 3.2. Development Environment ..............26 3.2.1. How to Install Toolchain ............... 26 3.2.2. RS232 Debug Console ..............27 Debug Console Information ..........27 Debug Console Device Node ..........27 Boot Message ..............
  • Page 7 3.3.5. RTC & Watchdog ................. 36 RTC & Watchdog Information ..........36 RTC & Watchdog Specification ..........36 RTC & Watchdog Device Node ..........36 RTC & Watchdog Example ..........36 3.3.6. I2C bus (Inter-Integrated Circuit)..........37 I2C bus Information ............37 I2C bus Specification ............
  • Page 8 3.5.2. Storage Filesystem ..............50 Formats ................50 SPI Flash Storage ............. 50 3.5.3. System Time Utility ..............51 ntpdate - Utility Information ..........51 Timezone ................. 51 3.5.4. MQTT ..................52 mosquitto Information ............52 3.6. Program Languages ................53 Program Languages Information .........
  • Page 10 Chapter Product Overview This chapter provides background information of EBC-3A1.
  • Page 11: Product Overview

    1. Product Overview 1.1. Introduction EBC-3A1 is a 3.5’’ SBC (Single Board Computer) with ARM Cortex-A9 NXP i.MX6 Dual Lite 1GHz processor and ARM Cortex™-M0 32-bit RISC core (MCU). The EBC-3A1 supports 2GB DDR3, 8MB NOR Flash and 4GB eMMC NAND Flash, 2 x LVDS, 1 x HDMI display, 1 x Gigabit LAN with IEEE 1588, 4 x USB 2.0, 1 x USB OTG, 4 x RS-232(8-wire), 2 x RS-232(4 wire), 2 x RS-485, 2 x CAN, 1 x SDIO and 1 x SD.
  • Page 12 STM32F051R8T6 Storage Flash 8MB NOR Flash NEXCOM 1 x NEXCOM X Port (miscellaneous header-JMISC) Port 1 x I2C interface (2x10 1.25mm Hirose DF13 series compatible, shared with SPI and GPIO) for Mainboard MCU to accessory (i.e. OLED module) connection purpose 1 x SPI interface (2x10 1.25mm Hirose DF13 series compatible,...
  • Page 13: Block Diagram

    1.3. Block Diagram...
  • Page 14 Chapter Hardware User Guide This chapter introduces the startup procedures of EBC-3A1, device integration. It also introduces the setting of switches, indicators and shows the mechanical drawings. Be sure to read all safety precautions before you begin installation procedure.
  • Page 15: Hardware User Guide

    2. Hardware User Guide 2.1. DIP Switch Setting and Connector Locations Top side: JMISC JCOMA JCOMC JCOM1 JCOMD JUSB JGPIO JCOM4 JCOMB MPCIE1 JBLK JLVDS2 MPCIE2 JLVDS1 JSPI JI2C Internal RD connector SDIO DIPSW JSPKR_L JSPKR_R JDC-IN JAUDIO JRS-485 HDMI LINE_OUT DC-IN RS-485...
  • Page 16: Dip Switch Setting

    2.2. DIP Switch Setting The EBC-3A1 has a 10-bits DIP switches for configuration. Please make sure the switches set as the following settings. 2.2.1. Boot from eMMC (Default) DIPSW eMMC Table 1: DIPSW (default setting) 2.2.2. Boot from SD DIPSW Table 2: DIPSW (boot from SD) 2.2.3.
  • Page 17: Connector

    2.3. Connector 2.3.1. Connector List DC-IN DC power input connector ψ2.5mm DC Jack HDMI HDMI connector JAUDIO Audio pin header 5 x 2 header, pitch 2.0mm JBLK LVDS backlight connector 8 x 1 connector, pitch 2.0mm JCOM1 RS-232 pin header 5 x 2 header, pitch 2.0mm JCOM4 RS-232 pin header...
  • Page 18: Connector Setting

    2.3.2. Connector Setting JAUDIO Description Description LINE_IN_R LINE_IN_L MIC_DETECT MIC_IN MIC_BIAS LINE_OUT_R LINE_OUT_L LINE_OUT_DETECT GNDA JBLK Description Backlight EN (3.3V) Backlight CTL (3.3V) Remark: Match connector: JST PHR-08 P2.0 (or Equivalent) VIN pins connect to DC-IN power input directly. For example, if DC-In is attached to a 12V adaptor, then the VIN output voltage will be 12V.
  • Page 19: Jcom4

    JCOM4 Description Description RS-232_RX4 RS-232_TX4 RS-232_RTS4 RS-232_CTS4 JCOMA Description Description RS-232_RXA RS-232_DCDA RS-232_DTRA RS-232_TXA RS-232_DSRA RS-232_RTSA RS-232_CTSA RS-232_RIA JCOMB Description Description RS-232_DCDB RS-232_RXB RS-232_TXB RS-232_DTRB RS-232_DSRB RS-232_RTSB RS-232_CTSB RS-232_RIB JCOMC Description Description RS-232_RXC RS-232_DCDC RS-232_DTRC RS-232_TXC RS-232_DSRC RS-232_RTSC RS-232_CTSC RS-232_RIC...
  • Page 20: Jcomd

    MCU_SS: SPI Slave Select (active low, output from master) MCU_CLK: SPI Serial Clock (output from master) MCU_MOSI: SPI Master Output, Slave Input (output from master) MCU_MISO: Master Input, Slave Output (output from slave) MCU is for NEXCOM system product design only...
  • Page 21: Jfp

    Description Description LED control by MCU LED control by CPU CPU power on MCU_GPIO7 MCU_GPIO8 Remark: GPIO pin control by MCU (level 3.3V) JGPIO (i.MX6) Description Description GPIO_04 GPIO_00 GPIO_01 GPIO_05 GPIO_02 GPIO_06 GPIO_03 GPIO_07 JI2C Description 3.3V I2C_SCL I2C_SDA JLVDS1 Description Description...
  • Page 22: Jlvds2

    LVDS1_TX1- LVDS1_TX0- LVDS1_TX1+ LVDS1_TX0+ LVDS1_TX3- LVDS1_TX2- LVDS1_TX3+ LVDS1_TX2+ Match connector: DF13-20DS-1.25C JMISC Description Pin Pin Description NEXCOM X-Port RS-485 DATA- RS-485 DATA3- NEXCOM X-Port RS-485 DATA+ RS-485 DATA3+ CAN_1_H CAN_2_H CAN_1_L CAN_2_L JRS-485 Description RS-485 DATA2- RS-485 DATA2+ JSPI Description 3.3V...
  • Page 23: Jspkr_L

    JSPKR_L Description SPKR_L+ SPKR_L- Match connector: JST PHR-02 P2.0 (or Equivalent) JSPKR_R Description SPKR_R+ SPKR_R- Match connector: JST PHR-02 P2.0 (or Equivalent) JUSB Description Description USB_5V USB_5V USB_DN8 USB_DN7 USB_DP8 USB_DP7 RS-485 Description RS-485 DATA2- RS-485 DATA2+...
  • Page 24: Mechanical Drawing

    2.4. Mechanical Drawing...
  • Page 25 Chapter Software User Guide This chapter details the Linux operation on EBC-3A1.
  • Page 26: Software User Guide

    3. Software User Guide 3.1. Introduction This chapter details the EBC-3A1 platform. The platform is an embedded system with Linux kernel 3.10.53. It contains all system-required shell commands and drivers ready. User can develop under Linux environment. Such as Ubuntu, Debian, Fedora…etc. The purpose of this chapter is to introduce software development of EBC-3A1 and improve software development time and efficiency.
  • Page 27: Rs232 Debug Console

    3.2.2. RS232 Debug Console Debug Console Information The serial communication parameters are 115200, N81, VT100. Use your preferred serial terminal tools to access the RS232 debug console. RS232 Utility recommend: ➔ On Windows system, use putty or teraterm. ➔ On Linux/OSX system, use minicom utility. Debug Console Device Node RS232 Port Device node...
  • Page 28: Networking Settings

    3.2.3. Networking Settings The EBC-3A1 has one Ethernet port, the default network setting is following: Device Node IP mode IP Address Eth0 static 192.168.1.1 The network interface configuration file path is /etc/network/interfaces file which is standard Linux configure file, and user can get more information from Internet. Please edit to change network setting.
  • Page 29: Firmware Version

    3.2.4. Firmware Version Embux Image Version “version” command is developed by Embux. When user gets some problem, please send Embux version to the contact. root@ICM-3011:~# version Firmware Version: v1.0.90 (r1109) Linux Kernel Image Version “uname” command to get EBC-3011 Linux Kernel version. root@ICM-3011:~# uname -a Linux ICM-3011 3.10.53 #1109 SMP PREEMPT Tue Jul 31 23:36:30 PDT 2018 armv7l GNU/Linux...
  • Page 30 3.2.6. eMMC Default Partitions Device Node Size Format Discuses mmcblk0p1 Ext4 Main system. (Sync all data and metadata every 5 seconds) PATH: / mmcblk0p2 32MB Ext4 User Space. PATH: /media/mmcblk0p2 mmcblk0p3 1 byte mmcblk0p5 mmcblk0p6 mmcblk0p7 mmcblk0p8 mmcblk0p9 512MB VFAT User Space.
  • Page 31: Interface Introduce

    3.3. Interface Introduce 3.3.1. RS232 RS232 Interface 4 RS232 serial ports for user interface control, and all RS232 ports are DTE mode. The pinout direction please refer below table: Name Abbreviation Direction Transmitted Data Output Received Data Input Clear to Send Input Request to Send Output...
  • Page 32: Rs485

    3.3.2. RS485 RS485 Information 2 RS485 serial ports for user interface control, and Embux provided 2-line RS485 interface. (Data+ and Date-). The connection diagram please refer below (daisy chain): ICM-3011 Data+ Data- RS485 Specification Name Value Baud Rate Up to 500Kbps Data Bits 5, 6, 7, 8 bits Parity...
  • Page 33: Can Bus (Controller Area Network)

    3.3.3. CAN bus (Controller Area Network) CAN bus Information 2 CAN bus ports for user interface control. The current CAN bus driver is based on FlexCan which is an embedded network architecture that extends Controller Area Network (CAN). It provides more deterministic behavior over the CAN network. Its focus is on redundancy at the hardware level, and time-based prioritized communication at the protocol level.
  • Page 34: Gpio

    3.3.4. GPIO GPIO Information 8 GPIO ports for user interface controls. GPIO signals have paths like /sys/class/gpio/gpioN/ and have the following read/write attributes: "direction" ... reads as either "in" or "out". This value may normally be written. Writing as "out" defaults to initializing the value as low. "value"...
  • Page 35: Gpio Example

    GPIO Example Example Code: http://github.com/embux/Example/tree/master/gpio_test Example Commands: #1: GPIO_00 port sets to output and high voltage. root@ICM-3011:~# echo "out" > /sys/class/gpio/gpio00/direction root@ICM-3011:~# echo "1" > /sys/class/gpio/gpio00/value #2: GPIO_01 port sets to input. root@ICM-3011:~# echo "in" > /sys/class/gpio/gpio01/direction root@ICM-3011:~# cat /sys/class/gpio/gpio01/value Note: All GPIO ports are floating.
  • Page 36: Rtc & Watchdog

    3.3.5. RTC & Watchdog RTC & Watchdog Information A real-time clock (RTC) keeps track of the current time, and ICM-3011 will synchronize hardware clock to system clock when boot. Watchdog timer, during normal operation, the computer regularly resets the watchdog timer to prevent it from elapsing, or "timing out".
  • Page 37: I2C Bus (Inter-Integrated Circuit)

    3.3.6. I2C bus (Inter-Integrated Circuit) I2C bus Information The bus is intended for communication between different ICs. It consists of two lines: a bidirectional data signal (SDA) and a clock signal (SCL). Already in use I2C ID: Name Connect Device I2C1 WM8960 Audio (ID: 0x1A) I2C2...
  • Page 38: I2C Bus Example

    I2C bus Example Example Code: https://github.com/embux/Example/tree/master/i2c_example Example Commands: #1: Detect I2C1 ID: root@ICM-3011:~# i2cdetect 0 WARNING! This program can confuse your I2C bus, cause data loss and worse! I will probe file /dev/i2c-0. I will probe address range 0x03-0x77. Continue? [Y/n] y 0 1 2 3 4 5 6 7 8 9 a b c d e f -- -- -- -- -- -- -- -- -- -- -- -- -- 10: -- -- -- -- -- -- -- -- -- -- UU -- -- -- -- --...
  • Page 39: Spi Bus (Serial Peripheral Interface)

    3.3.7. SPI bus (Serial Peripheral Interface) SPI bus Information The Serial Peripheral Interface (SPI) is a synchronous serial communication interface specification used for short distance communication, primarily in embedded systems. SPI devices communicate in full duplex mode using a master-slave architecture with a single master.
  • Page 40: Audio

    3.3.8. Audio Audio Information ICM-3011 supports full Advanced Linux Sound Architecture (ALSA), that is a software framework and part of the Linux kernel that provides an application programming interface (API) for sound card device drivers. List of PLAYBACK Audio Devices: root@ICM-3011:~# aplay -l **** List of PLAYBACK Hardware Devices **** card 0: wm8960audio [wm8960-audio], device 0: HiFi wm8960-hifi-0 []...
  • Page 41: Audio Example

    Audio Example Example Commands: #1: Play test.wav audio file: root@ICM-3011:~# aplay test.wav Playing WAVE ' test.wav' : Signed 16 bit Little Endian, Rate 44100 Hz, Stereo #2: Get Headphone volume: root@ICM-3011:~# amixer get "Headphone" Simple mixer control 'Headphone',0 Capabilities: pvolume Playback channels: Front Left - Front Right Limits: Playback 0 - 127 Mono:...
  • Page 42: Display

    3.3.9. Display Display Information ICM-3011 provides HDMI and 2 * LVDS interface. Default display setting is LVDS 1280x800 18bits. Please download“L3.10.53_1.1.0_LINUX_DOCS” in NXP web site to know more display detail. Note: download file name should be: fsl-yocto-3.10.53-1.1.0.tar.gz Display Command “panel_settings” command is developed by Embux, and support to user switch display device and resolution.
  • Page 43: Service Introduce

    3.4. Service Introduce 3.4.1. SSH/SFTP Service Service Information EBC-3A1 already enabled SSH/SFTP server service based on “dropbeear” , user can remotely access platform by ssh/sftp client utility. SSH/SFTP Configure file root@ICM-3011:/# cat /etc/default/dropbear DROPBEAR_EXTRA_ARGS="-B" root@ICM-3011:/# Remote connection Use SSH command to remotely access ICM-3011 in desktop: embux@ubuntu:~$ ssh root@192.168.1.1 The authenticity of host '192.168.1.1 (192.168.1.1)' can't be established.
  • Page 44: Web Service

    3.4.2. Web Service Service Information EBC-3A1 supports apache2 webserver with php. Please open your browser and enter ICM- 3011 IP address (default: 192.168.1.1). Demo for default html. (192.168.1.1) Demo for default php. (192.168.1.1/index.php)
  • Page 45: Webserver Directory Path

    Webserver Directory Path root@ICM-3011:/www/htdocs# ls index.html index.php root@ICM-3011:/www/htdocs# pwd /www/htdocs root@ICM-3011:/www/htdocs# Webserver Configure file Configure file Path: root@ICM-3011:/etc/apache2# ls -l total 100 drwxr-xr-x 2 root root 4096 Aug 1 06:40 conf.d drwxr-xr-x 2 root root 4096 Aug 1 06:40 extra -rw-r--r-- 1 root root 19486 Jul 26 09:13 httpd.conf -rw-r--r-- 1 root root 13077 Jul 26 09:13 magic -rw-r--r-- 1 root root 53011 Jul 26 09:13 mime.types...
  • Page 46: Rc.local

    3.4.3. RC.LOCAL RC.LOCAL Information In order to have a command or program run when the boots, you can add commands to the rc.local file. This is especially useful if you want to be able to plug your EBC-3011 in to power headless, and have it run a program without configuration or a manual start.
  • Page 47: Rc.local Configure File

    RC.LOCAL Configure file Edit the file /etc/rc.local using the editor of your choice. You must edit with root, for example: root@ICM-3011:/# vi /etc/rc.local Add commands below the comment, but leave the line exit 0 at the end, then save the file and exit.
  • Page 48: Utilities

    # should match [a-zA-Z0-9._-]+, <source-url> should be a # URL that points to a directory containing a Familiar # Packages file, and <target-path> should be a directory # that exists on the target system. src all ftp://iwuser:nexcomuser@ftp.nexcom.com.tw/package/yocto/all src cortexa9hf-vfp-neon ftp://iwuser:nexcomuser@ftp.nexcom.com.tw/package/yocto/cortexa9hf-vfp-neon src cortexa9hf-vfp-neon-mx6 ftp://iwuser:nexcomuser@ftp.nexcom.com.tw/package/yocto/cortexa9hf-vfp-neon-mx6...
  • Page 49: Opkg Commands

    OPKG Commands Commonly used apt commands are listed below: • opkg update - update the package list. • opkg install <package> - install package. • opkg remove <package> - remove package. Note: before using opkg command, please make sure ICM-3011 already connect to public internet.
  • Page 50: Storage Filesystem

    3.5.2. Storage Filesystem Formats EBC-3011 provides below file system formats: File System Formats EXT2 EXT3 EXT4 VFAT MSDOS NTFS JFFS2 UBIFS TMPFS EBC-3011 supports udev which is a device manager for the Linux kernel, and when user hotplug SD or USB flash, udev will auto mount the device. SPI Flash Storage ICM-3011 provided 8Mb SPI Flash for user.
  • Page 51: System Time Utility

    3.5.3. System Time Utility ntpdate - Utility Information The ntpdate utility sets the local date and time by polling the Network Time Protocol (NTP) server(s). Example: #1: Get date form “0.pool.ntp.org” NTP server. root@ICM-3011:/# date Mon Aug 6 06:28:56 UTC 2018 root@ICM-3011:/# ntpdate 0.pool.ntp.org 6 Aug 06:44:54 ntpdate[26497]: step time server 103.18.128.60 offset 940.842922 sec...
  • Page 52: Mqtt

    3.5.4. MQTT mosquitto Information Mosquitto is an open source implementation of a server for version 3.1 and 3.1.1 of the MQTT protocol. It also includes a C and C++ client library, and the mosquitto_pub and mosquitto_sub utilities for publishing and subscribing. root@ICM-3011:~# mosquitto --help mosquitto version 1.4.4 (build date 2018-07-31 01:26:14-0700) mosquitto is an MQTT v3.1 broker.
  • Page 53: Program Languages

    3.6. Program Languages Program Languages Information EMC-3011 provides below languages for user: Language Version C/C++ Python 2.7.6 5.5.10 bash Program Languages Example Use different program languages to print “Hello, World!” in terminal console. C Example: Filename: Hello.c #include <stdio.h> int main(void){ printf("Hello, World!\n");...
  • Page 54 PHP Example: Filename: Hello.php <?php Echo "Hello, World!"; ?> Bash Example: Filename: Hello.sh #!/bin/sh echo "Hello, world!" exit 0...
  • Page 55 Chapter System Recovery This chapter introduces how to recover Linux operating system if it is damaged accordingly.
  • Page 56: System Recovery

    imx6dl-NEXCOM-icm3011.dtb...
  • Page 57: Downloading Board Images

    4.1.3. Downloading board images The board images can be downloaded to the target board by using the MFGTool. The release package includes MFGTool for EBC-3A1 in android_ L5.0.2_EBC-3A1.tar.xz. The MFGTool only works in the Windows® Operating System (OS) environment. Perform the following steps to download the board images: ➢...
  • Page 58 Step 3 ➢ Double click the application to run. There is a limitation that, when using the MFGTool V2 for the first time to burn an image to a device (such as: EBC-3A1), the device must be connected to PC before MFGTool V2 starts running.
  • Page 59 Process continuing: Wait and until it is done. Click “Stop” to finish, and Click “Exit” to terminate the application. Note: The manufacturing tool may sometimes report an error message when it is downloading the file system to the SD card. This can be caused by insufficient space in the SD card due to a small partition size.
  • Page 60: Download The Sd Image

    4.2. Download the SD image Please contact us (info@embux.com) to get SD card image. 4.3. Write an SD/MMC Card using Linux (Ubuntu) • From the terminal run df -h • Connect the SD card reader with the SD card inside. •...
  • Page 61: Write An Sd/Mmc Card Using Windows

    4.4. Write an SD/MMC Card using Windows 4.4.1. Introduction This guide describes the process of writing these images to a SD-Card on a Windows PC (under Linux you would use the dd command). 4.4.2. Preparations • Download the SD-Card image which described in Chap 4.1. •...
  • Page 62: Write An Sd/Mmc Card Using Mac Os X

    • Press write to start writing the image to the card. (This may take a couple of minutes) • After the Program is finished, you can eject your SD-Card. • Insert it into your target device, plug-in power cable and you could start using the device 4.5.
  • Page 63: Alternative Method

    diskutil unmountDisk /dev/disk4 e.g. sudo dd bs=1m if=image.img of=/dev/<disk# from diskutil> sudo dd bs=1m if=2015-02-16-raspbian-wheezy.img of=/dev/disk4 e.g. dd: invalid number '1m' This may result in a error if you have GNU coreutils installed. In that case you need to use sudo dd bs=1M if=image.img of=/dev/<disk# from diskutil>...
  • Page 64 sudo dd bs=1m if=2015-02-16-raspbian-wheezy.img of=/dev/rdisk3 dd: bs: illegal numeric value bs=1m If the above command reports an error ( ), please change bs=1M dd: /dev/rdisk3: Permission denied If the above command reports an error then that is because the partition table of the SD card is being protected against being overwritten by MacOS. Erase the SD card's partition table using this command: sudo diskutil partitionDisk /dev/disk3 1 MBR "Free Space"...
  • Page 65 Chapter This chapter introduces how to get board BSP (board support package)
  • Page 66: Bsp

    5. BSP 5.1. Yocto 1.6.2 Please find the document “L3.10.53_1.1.0_LINUX_DOCS” in NXP web site and refer the document to create the Yocto build environment. Note: download file name should be: fsl-yocto-3.10.53-1.1.0.tar.gz 5.2. Linux Kernel 5.2.1. Source Code URL PATH : https://github.com/embux/linux_kernel 5.2.2.
  • Page 67: Compile Uimage

    Compile uImage make ARCH=arm CROSS_COMPILE=arm-linux-gnueabihf- uImage LOADADDR=0x10008000 After compile completed, uImage image is in {Kernel PATH}/arch/arm/boot/uImage. Compile Device Tree make ARCH=arm CROSS_COMPILE=arm-linux-gnueabihf- dtbs After compile completed, dtb image is in {Kernel PATH}/arch/arm/boot/dts/imx6dl-embux- icm3011.dtb. Update Device Tree and Linux Kernel Please upload new image into /boot folder. Example: #1: upload uImage file: scp uImage root@192.168.1.1:/boot/...
