OPERATING INSTRUCTIONS
S 910
Handheld Transmitter
TS 910
Beltpack Transmitter

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S 910 and is the answer not in the manual?

Questions and answers

Related Manuals for Beyerdynamic S 910

Summary of Contents for Beyerdynamic S 910

  • Page 1 OPERATING INSTRUCTIONS S 910 Handheld Transmitter TS 910 Beltpack Transmitter...

  • Page 3: Table Of Contents

    Safety Instructions ........Page S 910 Handheld Transmitter ......Page TS 910 Beltpack Transmitter .

  • Page 4: Safety Instructions

    OPERATING INSTRUCTIONS S 910 / TS 910 Thank you for selecting the S 910 handheld or TS 910 beltpack transmitter. Please take some time to read carefully through this manual before setting up the equipment. Important: • When you unpack the product, inspect it for transport damage. If you do find transport damage, notify the transportation company without delay.
  • Page 5 • Consult the dealer or an experienced radio/TV technician for help. In accordance with FCC requirements, changes or modifications not expressly approved by beyerdynamic GmbH & Co. KG could void the user’s authority to operate this product. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to...

  • Page 6: S 910 Handheld Transmitter

    There are different condenser and dynamic microphone capsules for the handheld transmitter (refer to Optional Accessories). The S 910 C handheld transmitter has charging contacts and can be operated with the integrated rechargeable battery pack only. For charging, the SLG 900 charger is available.
  • Page 7 2. Insert two 1.5 V batteries into the battery compartment observing polarity markings. Note: The S 910 C transmitter is powered by rechargeable batteries which cannot be changed by the user. If the rechargeable batteries have to be changed, please contact your beyerdynamic dealer.
  • Page 8 DM 969 Supercardioid dynamic microphone capsule. Suitable for vocals. EM 981 Cardioid electret condenser microphone capsule for solo vocals, conferences and speech. RM 510 Cardioid dynamic ribbon microphone head. Weight 165 g. 1.4 Maintenance • Protect the handheld transmitter from humidity, knocks and shock. Avoid dropping the transmitter at all times.
  • Page 9 DM 960 • Unscrew the upper part of the microphone basket (turn anti-clockwise). • Clean it under clear water. • Let the pop shield dry overnight before you replace it. • The upper part of the microphone basket cannot be cleaned in a dishwasher. DM 969 •...
  • Page 10 RM 510 • Loosen the screws. • Unscrew the upper part of the microphone head (turn anti-clockwise). • Clean the upper basket under clear running water. • Allow the upper basket to dry overnight before you replace it. • The upper basket cannot be cleaned in a dishwasher.
  • Page 11 1.5 How to adjust the gain of the handheld transmitter • To adjust the gain unscrew the complete microphone head with the upper shaft as indicated by the arrows. • Use a screwdriver to select the gain (0 dB, -10 dB, -20 dB, -30 dB). •...

  • Page 12: Ts 910 Beltpack Transmitter

    TS 910 Beltpack Transmitter The TS 910 C beltpack transmitter provides charging contacts and can be powered by the optional beyerdynamic TS 900 AP rechargeable battery pack. For charging, the SLG 900 charger is available. With this charger the TS 900 AP battery pack inside the TS 910 C beltpack transmitter can be recharged only, no standard rechargeable batteries.
  • Page 13 AF input, 4-pin mini XLR for microphones (lavalier, neckworn mics). For connection please refer to chapter 2.5 “AF Connection”. ON/OFF switch (ON = switch to “ON“ position; OFF = switch to “OFF“ position). Switch off the transmitter when not in use. TS 910 C only: Battery status LED to indicate the power on / off and battery status.
  • Page 14 TS 910 M TS 910 M...
  • Page 15 AF input, 4-pin mini XLR for microphones (lavalier, neckworn mics). For connection please refer to chapter 2.5 “AF Connection”. ON/OFF switch (ON = switch to “ON“ position; OFF = switch to “OFF“ position). Switch off the transmitter when not in use. Transmitting antenna LC-Display Infrared receiving diode for ACT function.
  • Page 16 2.2 How to insert the batteries / rechargeable battery pack 1. Push down the two snap locks on the right and left of the battery compartment and open it. Remove the batteries. Refer to Fig. 1. 2. Insert two 1.5 V batteries into the battery compartment observing polarity markings.
  • Page 17 2.3 Setting up 1. Push down the two snap locks on the right and left of the battery compartment and open it. Now you can adjust the GT/MT switch the gain control 2. Make sure that the transmitter and receiver are on the same frequency. 3.
  • Page 18 2.5 AF connection 2-Wire Electret Condenser Microphone Capsule e.g. MCE 5.18, MCE 10.18, MCE 60.18 3-Wire Electret Condenser Microphone Capsule e.g. Opus 54.18, Opus 55.18, Opus 56.18, MCE 7.18 Dynamic Microphone Electric Guitar Line-in (impedance 8Ω, attenuation 10 dB)

  • Page 19: How To Switch Off The Transmitter

    LC-Display 1. “ERR“ Message: When the “ERR“ message is displayed, there is an error. ERR noo3: The frequency you want to program is above the switching bandwidth of the transmitter. Use a receiver with an appropriate frequency group. (At this time the microphone is still operating and the frequency remains unchanged.

  • Page 20: Positioning Of Transmitters If Interferences Occur

    • Please do not throw used battery packs away with your household rubbish, but take them to your local collection points. • When using the S 910 C handheld transmitter or TS 910 C beltpack transmitter (fitted with TS 900 AP rechargeable battery pack) use the beyerdynamic SLG 900 charger only.

  • Page 21: Trouble Shooting

    • Battery of the • Replace the transmitter is too weak batteries 11. Service In the unlikely event of equipment failure, the product should be returned to your beyerdynamic dealer. Unauthorised attempts at repair may invalidate the warranty.
  • Page 22 In most countries around the world, wireless systems must be approved for use by the authorities and it may be necessary to obtain a licence to use it legally. Your local beyerdynamic dealer will be able to give you details on wireless system regulations for your area.

  • Page 23: Optional Accessories

    NiMH battery Rechargeable battery, 1.2 V / 2500 mAh for S 910 C ......Order # 903.442...

  • Page 24: Technical Specifications

    S 910 + EM 981 ....50 - 18,000 Hz (close miking 2 cm) at 80 dB SPL S 910 + CM 930 ....40 - 20,000 Hz (close miking 2 cm) at 80 dB SPL S 910 + RM 510.
  • Page 25 Dimensions Length ......S 910 C: 188 mm S 910 M: 210.5 mm Shaftø ......S 910 C: 38 mm S 910 M: 38 mm Weight with batteries .
  • Page 28 GmbH & Co. KG Theresienstr. 8 | 74072 Heilbronn – Germany Tel. +49 (0) 7131 / 617 - 0 | Fax +49 (0) 7131 / 617 - 204 info@beyerdynamic.de | www.beyerdynamic.com For further distributors worldwide, please go to www.beyerdynamic.com...
