  • Page 1 UPER ® 5035L-I uper erver USER’S MANUAL Revision 1.0...
  • Page 2 Please Note: For the most up-to-date version of this manual, please see our web site at www.supermicro.com. Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual at any time and without notice. This product, including software, if any, and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or reduced to any medium or machine without prior written consent.

  • Page 3: About This Manual

    About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 5035L-I. Instal- lation and maintenance shall be performed by experienced technicians only. The SuperServer 5035L-I is a single processor system based on the SC731I-300B mini-tower chassis and the Super X7SLM-L motherboard.
  • Page 4 UPER ERVER 5035L-I User's Manual Chapter 5: Advanced Motherboard Setup Chapter 5 provides detailed information on the X7SLM-L motherboard, including the locations and functions of connectors, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfi guring the motherboard.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    System Power ....................1-3 SATA Subsystem ..................... 1-3 Front Control Panel ..................1-3 I/O Backplane ....................1-3 Cooling System ....................1-3 Contacting Supermicro ..................1-5 Chapter 2 System Setup Overview ......................2-1 Unpacking the System ..................2-1 Setting Up the System ..................2-2 Checking the Motherboard Setup ..............
  • Page 7 Table of Contents Chapter 5 Advanced Motherboard Setup Handling the Motherboard ................5-1 Precautions ..................... 5-1 Unpacking ....................... 5-2 Motherboard Installation .................. 5-2 Connecting Cables ..................5-2 Connecting Data Cables ................. 5-2 Connecting Power Cables ................5-3 Connecting the Control Panel ................. 5-3 I/O Ports ......................
  • Page 8 UPER ERVER 5035L-I User's Manual Watch Dog Enable/Disable ..............5-17 5-11 Onboard Indicators ..................5-18 LAN1/2 LEDs .................... 5-18 Onboard Power LED (LE1) ..............5-18 5-12 SATA and IDE Ports ..................5-19 SATA Ports ....................5-19 IDE Connector ..................5-19 Chapter 6 Advanced Chassis Setup Static-Sensitive Devices ..................

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction Overview The SuperServer 5035L-I is a high-end server comprised of two main subsystems: the SC731I-300B mini-tower chassis and the X7SLM-L motherboard. Please refer to our web site for information on operating systems that have been certifi ed for use with the SuperServer 5035L-I (www.supermicro.com).

  • Page 10: Motherboard Features

    ERVER 5035L-I User's Manual Motherboard Features At the heart of the SuperServer 5035L-I lies the X7SLM-L, a single processor moth- erboard based on the Intel 945GC + ICH7R chipset. Below are the main features of the X7SLM-L. (See Figure 1-1 for a block diagram of the chipset).

  • Page 11: Chassis Features

    Chapter 1: Introduction Chassis Features The SC731I-300B is a mini-tower chassis with a unique design that allows most confi gurations to be performed without the need for tools The following is a general outline of the main features of the SC731I-300B chassis. System Power The SC731I-300B features a high-effi...
  • Page 12 UPER ERVER 5035L-I User's Manual Figure 1-1. Intel 945GC Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. VRM V11 LGA775_PROCESSOR VRM 11 IDTCV183-1 FSB: 800/533MHz INTEGRATED DIMM_CHA DDR2_667/533/400 GRAPHIC 945GC PCIE_x16 1 PCIE_x16 PCIE_x4 Slot...

  • Page 13: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...
  • Page 14 UPER ERVER 5035L-I User's Manual Notes...

  • Page 15: Chapter 2 System Setup

    Unpacking the System You should inspect the box the SuperServer 5035L-I was shipped in and note if it was damaged in any way. If the server itself shows damage, you should fi le a damage claim with the carrier who delivered it.

  • Page 16: Setting Up The System

    UPER ERVER 5035L-I User's Manual Setting Up the System You should fi rst open the left side panel (when facing the front of the chassis) to make sure the motherboard is properly installed and all connections have been made. Warning: Only qualifi ed service technicians should access the inside of the system.
  • Page 17 Chapter 2: System Setup Figure 2-1. Accessing the Inside of the 5035L-I Release Tab (B) Handle (A)
  • Page 18 UPER ERVER 5035L-I User's Manual Check the SATA disk drives: Depending upon your system's confi guration, your system may have up to four SATA drives already installed. If you need to install or remove an SATA drive, please refer to the appropriate section in Chapter 6.

  • Page 19: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are four LEDs on the control panel to keep you constantly informed of the overall status of the system as well as the activity and health of specifi c components. The control panel also is where to fi...

  • Page 20: Nic

    UPER ERVER 5035L-I User's Manual Indicates network activity on the Gigabit LAN port when fl ashing. Overheat/Fan Fail When this LED fl ashes it indicates a fan failure. When on continuously (on and not fl ashing) it indicates an overheat condition, which may be caused by cables ob- structing the airfl...

  • Page 21: Chapter 4 System Safety

    Basic electrical safety precautions shall be followed to protect yourself from harm and the SuperServer 5035L-I from damage: • Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.

  • Page 22: General Safety Precautions

    General Safety Precautions Follow these rules to ensure general safety: • Keep the area around the SuperServer 5035L-I clean and free of clutter. • The SuperServer 5035L-I weighs approximately 43 lbs. (19.5 kg) when fully loaded. When lifting the system, two people at either end should lift slowly with their feet spread out to distribute the weight.

  • Page 23: Esd Precautions

    Chapter 4: System Safety • After accessing the inside of the system, close the system back up and secure it to the rack unit with the retention screws after ensuring that all connections have been made. ESD Precautions Electrostatic discharge (ESD) is generated by two objects with different electrical charges coming into contact with each other.

  • Page 24: Operating Precautions

    UPER ERVER 5035L-I User's Manual Operating Precautions Care must be taken to assure that the chassis cover is in place when the 5035L-I is operating to assure proper cooling. Out of warranty damage to the system can occur if this practice is not strictly followed. Figure 4-1.

  • Page 25: Chapter 5 Advanced Motherboard Setup

    Chapter 5: Advanced Motherboard Setup Chapter 5 Advanced Motherboard Setup This chapter covers the steps required to install the X7SLM-L motherboard into the chassis, connect the data and power cables and install add-on cards. All mother- board jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference.

  • Page 26: Unpacking

    UPER ERVER 5035L-I User's Manual Unpacking The motherboard is shipped in antistatic packaging to avoid electrical static dis- charge. When unpacking the board, make sure the person handling it is static protected. Motherboard Installation This section explains the fi rst step of physically mounting the X7SLM-L into the SC731I-300B chassis.

  • Page 27: Connecting Power Cables

    Chapter 5: Advanced Motherboard Setup should take care to keep them routed as they were originally after reconnecting them (make sure the red wires connect to the pin 1 locations). The following data cables (with their locations noted) should be connected. (See the layout on page 5-9 for connector locations.) •...

  • Page 28: I/O Ports

    LGA 775 processor pre-installed, make sure that the CPU plastic cap is in place, and none of the CPU pins are bent; otherwise, contact the retailer immediately. • Refer to the Supermicro web site for more details on CPU support.

  • Page 29: Installing The Lga 775 Processor

    Chapter 5: Advanced Motherboard Setup Installing the LGA 775 Load Lever Processor PnP Cap on Press the load lever to release the load top of the Load plate, which covers the CPU socket, from Plate its locking position. Gently lift the load lever to open the load plate.
  • Page 30 UPER ERVER 5035L-I User's Manual Warning: Please save the plastic PnP cap. The motherboard must be shipped with the PnP cap properly installed to protect the CPU socket pins. Shipment without the PnP cap properly installed will cause dam- age to the socket pins. Load Lever Plastic cap is re- leased from the load...

  • Page 31: Installing Memory Modules

    Narrow end of the groove points outward Installing Memory Modules Note: Check the Supermicro web site for recommended memory modules. CAUTION Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Installing & Removing DIMMs Insert the desired number of DIMMs into the memory slots, starting with DIMM #1A.

  • Page 32: Installing Pci Add-On Cards

    UPER ERVER 5035L-I User's Manual Figure 5-3. DIMM Installation DDR 2 Slot To Install: Insert module vertically and press Release Tab Release Tab down until it snaps into place. Pay attention to the alignment notch at the bottom. DDR2 To Remove: Notch Notch Use your thumbs to...
  • Page 33 Chapter 5: Advanced Motherboard Setup If desired, screws can be used to secure the add-on cards into the chassis. Close the protective bracket over the tops of the add-on card brackets. The SC731 chassis includes clips to accomodate the use of long-length add-on cards.

  • Page 34: Motherboard Details

    UPER ERVER 5035L-I User's Manual Motherboard Details Figure 5-5. X7SLM-L Layout Fan5 JPW2 JPW1 KB/MOUSE Fan 1/CPU Fan DIMM1B USB0/1 UNB NON-ECC DDR2 400/533/667 Required DIMM1A X7SLM-L Speaker COM1 CTRL JOH1 Intel 945GC Fan2 Intel LAN1 LAN2 CTRL Clock chip Slot 7: PCI-E x16 CTRL Slot 6: PCI 33MHz...

  • Page 35: X7Slm-L Quick Reference

    Chapter 5: Advanced Motherboard Setup X7SLM-L Quick Reference Jumper Description Default Setting JBT1 CMOS Clear (See Section 5-10) JPL1/JPL2 LAN 1/2 Enable/Disable Pins 1-2 (Enabled) Watch Dog Timer Enable/Disable Pins 1-2 (Reset) Connector Description COM1/COM2 COM1/2 Serial Port Connectors Fan 1~5 Fan headers (Fan 1 = CPU fan) I-SATA 0~5 (Intel South Bridge) SATA Ports...

  • Page 36: Connector Defi Nitions

    UPER ERVER 5035L-I User's Manual Connector Defi nitions ATX Power 24-pin Connector Pin Defi nitions (JPW1) Pin# Defi nition Pin # Defi nition Main ATX Power Supply +3.3V +3.3V Connector -12V +3.3V The primary power supply connec- tor (JPW1) meets the SSI EPS 12V PS_ON specifi...

  • Page 37: Reset Connector

    Chapter 5: Advanced Motherboard Setup Reset Connector Reset Button The reset header is located on pins 3 Pin Defi nitions (JF1) and 4 of JF1. Attach the reset switch Pin# Defi nition on the computer chassis to these Reset pins. See the table on the right for Ground pin defi...

  • Page 38: Chassis Intrusion

    UPER ERVER 5035L-I User's Manual Chassis Intrusion Chassis Intrusion Pin Defi nitions (JL1) The Chassis Intrusion header is des- Pin# Defi nition ignated JL1. Attach an appropriate Intrusion Input cable from the chassis to inform you Ground of a chassis intrusion when the chas- sis is opened PS/2 Keyboard and ATX PS/2 Keyboard and PS/2...

  • Page 39: Power Led/Speaker

    Chapter 5: Advanced Motherboard Setup Power LED/Speaker Speaker Connector On the JD1 header, pins 1~3 are used Pin Defi nitions (JD1) for a power LED and pins 4~7 are Pin Setting Defi nition used for an external speaker. If you Pins 6-7 Internal Speaker wish to use the onboard speaker, you...

  • Page 40: 5-10 Jumper Settings

    UPER ERVER 5035L-I User's Manual 5-10 Jumper Settings Explanation of Jumpers To modify the operation of the mother- board, jumpers can be used to choose Connector between optional settings. Jumpers Pins create shorts between two pins to change the function of the connector. Pin 1 is identifi...

  • Page 41: Lan1/Lan2 Enable/Disable

    Chapter 5: Advanced Motherboard Setup LAN1/LAN2 Enable/Disable LAN1/LAN2 Enable/Disable Change the setting of jumper JPL1 or Jumper Settings (JPL1/JPL2) JPL2 to enable or disable the LAN1 and Jumper Setting Defi nition LAN2 Ethernet ports, respectively. See Pins 1-2 Enabled the table on the right for jumper set- Pins 2-3 Disabled tings.

  • Page 42: 5-11 Onboard Indicators

    UPER ERVER 5035L-I User's Manual 5-11 Onboard Indicators LAN1/2 LEDs LAN1/2 LED The Ethernet ports (located beside (Connection Speed Indicator) the VGA port) have two LEDs. On LED Color Defi nition each port, one LED indicates activity No Connection or 10 Mb/s while the other LED may be green, Green 100 Mb/s...

  • Page 43: 5-12 Sata And Ide Ports

    Chapter 5: Advanced Motherboard Setup 5-12 SATA and IDE Ports SATA Port SATA Ports Pin Defi nitions (I-SATA0 ~ I-SATA5 Six Serial ATA (SATA) ports (I-SATA Pin # Defi nition 0~5) are located on the motherboard Ground to provide serial link connections. Se- rial Link connections provide faster data transmission than those of the traditional Parallel ATA.
  • Page 44 UPER ERVER 5035L-I User's Manual Notes 5-20...

  • Page 45: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform simple maintenance on the SC731I-300B chassis. Following the component installation steps in the order given will eliminate most common problems. If some steps are unnecessary, skip ahead to the next step.

  • Page 46: Front Control Panel

    UPER ERVER 5035L-I User's Manual Front Control Panel The front control panel must be connected to the JF1 connector on the motherboard to provide you with system status and alarm indications. A ribbon cable has bundled these wires together to simplify this connection. Connect the cable from JF1 on the motherboard (making sure the red wire plugs into pin 1) to the appropriate comn- nector on the front control panel PCB (printed circuit board).
  • Page 47 Chapter 6: Advanced Chassis Setup Figure 6-2. Chassis Rear View Power Supply I/O Backplane (see Figure 5-2) PCI Expansion Slots...

  • Page 48: Front Bezel

    UPER ERVER 5035L-I User's Manual Front Bezel A bezel may be installed to cover the front of the chassis. Front Bezel Installation Remove the dummy cover (A) on the peripheral drive bay. Push the front bezel into place on the front of the chassis to complete the installation (see Figure 6-4).

  • Page 49: Removing The Chassis Cover

    Chapter 6: Advanced Chassis Setup Removing the Chassis Cover The left side cover of the chassis must be removed before replacing the system fan or installing and removing hard drives. Warning: Only qualifi ed service technicians should access the inside of the system.

  • Page 50: System Fans

    UPER ERVER 5035L-I User's Manual System Fans The SC731 includes a super quiet system fan that provides cooling for the chassis. No tools or screws are required to install the system fan. Fan Failure Under normal operation, the chassis fan and the power supply fan both run continu- ously.

  • Page 51: Drive Bay Installation

    Chapter 6: Advanced Chassis Setup Drive Bay Installation The SC731 chassis must be powered-down before hard drives can be removed from the hard drive carriers, which are not hot-swappable. SATA Drives The SATA drive IDs are preconfi gured as 0 through 3 in order from bottom to top. In order to access and install components in the chassis interior, it is necessary to rotate the hard drive cage.
  • Page 52 UPER ERVER 5035L-I User's Manual Release Tab (A) HDD Cage (B) Figure 6-6: Rotating the Hard Drive Cage Release Tabs Figure 6-7: Removing a Hard Drive Carrier from the Hard Drive Cage...

  • Page 53: Installing Drives In The Optional Drive Bays

    Chapter 6: Advanced Chassis Setup Installing Drives in the Optional Drive Bays The SC731 chassis has two empty drive bays that support optional devices such as a DVD-ROM. Installing an Optional Device Power down the server and disconnect it from the power source. Remove the front bezel from the chassis by lifting it upwards from the bottom, and pulling off the front of the chassis.

  • Page 54: Power Supply

    UPER ERVER 5035L-I User's Manual Power Supply The SC731 chassis includes a 300-watt power supply. The power supply has the capability to automatically sense and operate with an input voltage of 100 or 240V If it becomes necessary to replace the power supply, follow the instructions be- low.

  • Page 55: Chapter 7 Bios

    When an option is selected in the left frame, it is highlighted in white. Often a text message will accompany it. (Note: the AMI BIOS has default text messages built in. Supermicro retains the option to include, omit, or change any of these text messages.) The AMI BIOS Setup Utility uses a key-based navigation system called hot keys.

  • Page 56: Starting The Setup Utility

    UPER ERVER 5035L-I User's Manual Starting the Setup Utility Normally, the only visible POST (Power On Self Test) routine is the memory test. As the memory is being tested, press the <Delete> key to enter the main menu of the AMI BIOS Setup Utility. From the main menu, you can access the other setup screens.
  • Page 57 Chapter 7: BIOS Processor The AMI BIOS automatically displays the status of processor as shown below: Genuine Intel (R) CPU @ XX.XXGHz Speed :XXXXMHz Count System Memory This displays the size of memory available in the system, in megabytes (MB). Size :XXXXMB...

  • Page 58: Advanced Setup Confi Gurations

    UPER ERVER 5035L-I User's Manual Advanced Setup Confi gurations Use the arrow keys to select Boot Setup and hit <Enter> to access the submenu items: BIOS Features Quick Boot If Enabled, this option will skip certain tests during POST to reduce the time needed for system boot.
  • Page 59 Chapter 7: BIOS enabled. Use this feature to select the interrupt address. The options are [FED00000h], [FED01000h], [FED02000h], and [FED03000h]. ACPI Confi guration Use this feature to confi gure ACPI (Advanced Confi guration and Power Interface) power management settings for your system. ACPI Aware OS Select Yes to enable ACPI support for the OS.
  • Page 60 UPER ERVER 5035L-I User's Manual Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19 at boot and allow the drives that are attached to these host adaptors to func- tion as bootable disks.
  • Page 61 Chapter 7: BIOS Execute-Disable Bit Capability (Available when supported by the OS and the CPU) Set to Enabled to enable the Execute Disable Bit which will allow the processor to designate areas in the system memory where an application code can execute and where it cannot, thus preventing a worm or a virus from fl...
  • Page 62 UPER ERVER 5035L-I User's Manual Confi gure DRAM Timing by SPD Select Enable to allow the BIOS to read the SPD (Serial Presence Detect) chip which is built in the memory module in order to get the exact memory specifi ca- tions.
  • Page 63 Chapter 7: BIOS Boot Display Device This option allows the user to select the boot display device. The options are CRT on Port 0, LFP on Port2, and CRT-Port 0 & LFP-Port 2. USB Functions This feature allows the user to decide the number of onboard USB ports to be enabled.
  • Page 64 fi gure your RAID by pressing and holding down <Ctrl> and pressing <I> (the "i" key) during POST. For a downloadable PDF manual, please visit Supermicro's website at: http://www.supermicro.com/support/manuals/ and click "HostRAID - Setup for Intel ICH7R / ICH9R" under RAID Installation Guides.
  • Page 65 Chapter 7: BIOS Type Select the type of device connected to the system. The options are Not Installed, Auto, CD/DVD and ARMD. LBA/Large Mode LBA (Logical Block Addressing) is a method of addressing data on a disk drive. In the LBA mode, the maximum drive capacity is 137 GB. For drive capacities over 137 GB, your system must be equipped with a 48-bit LBA mode addressing.
  • Page 66 UPER ERVER 5035L-I User's Manual DMA Mode Select Auto to allow the BIOS to automatically detect IDE DMA mode when the IDE disk drive support cannot be determined. Select SWDMA0 to allow the BIOS to use Single Word DMA mode 0. It has a data transfer rate of 2.1 MBs.
  • Page 67 Chapter 7: BIOS Hard Disk Write Protect Select Enabled to use the feature of Hard Disk Write Protect to prevent data from being written to HDD. The options are Enabled or Disabled. IDE Detect Time Out Use this feature to set the time-out value for the BIOS to detect the ATA, ATAPI devices installed in the system.
  • Page 68 UPER ERVER 5035L-I User's Manual Load Onboard LAN 1 Option ROM/ Load Onboard LAN 2 Option ROM Select Enabled to load the onboard LAN Option ROM for the LAN port as specifi ed. The options are Enabled and Disabled. Super IO Confi guration Onboard Floppy Controller Select Enabled to enable the onboard Floppy Controller.
  • Page 69 Chapter 7: BIOS CPU Temperature, System Temperature, Fan Speed Control Modes This feature allows the user to decide how the system controls the speeds of the onboard fans. The CPU temperature and the fan speed are correlative. When the CPU on-die temperature increases, the fan speed will also increase, and vice versa.

  • Page 70: Security Settings

    UPER ERVER 5035L-I User's Manual Flow Control This feature allows the user to set the fl ow control for Console Redirection. The options are None, Hardware, and Software. Redirection After BIOS POST Select Disabled to turn off Console Redirection after Power_On_Self_Test (POST).
  • Page 71 Chapter 7: BIOS Change Supervisor Password: Use this feature to set a supervisor password. It secures the system from unau- thorized use by restricting access to persons only with the proper supervisor-level password. Select this feature and press <Enter>, and then type in the Supervisor Password.

  • Page 72: Boot Confi Guration

    UPER ERVER 5035L-I User's Manual Boot Confi guration Use this feature to confi gure Boot Settings: Boot Device Priority This feature allows the user to specify the sequence of priority for the Boot Device. The settings are 1st boot device, 2nd boot device, 3rd boot device, and Disabled. •...

  • Page 73: Exit Options

    Chapter 7: BIOS CD/DVD Drives This feature allows the user to specify the boot sequence from available CD/DVD Drives. The settings are 1st boot device and Disabled. • 1st Drive - [CD/DVD: XXXXXXXXXXX] Exit Options Select the Exit tab from the AMI BIOS Setup Utility screen to enter the Exit BIOS Setup screen.
  • Page 74 UPER ERVER 5035L-I User's Manual Load Fail-Safe Defaults To set this feature, select Load Fail-Safe Defaults from the Exit menu and press <Enter>. The Fail-Safe settings are designed for maximum system stability, but not for maximum performance. 7-20...

  • Page 75: Appendix A Post Error Beep Codes

    Appendix A: POST Error Beep Codes Appendix A POST Error Beep Codes This section lists POST (Power On Self Test) error beep codes for the AMI BIOS. POST error beep codes are divided into two categories: recoverable and terminal. This section lists Beep Codes for recoverable POST errors. Recoverable POST Error Beep Codes When a recoverable type of error occurs during POST, BIOS will display a POST code that describes the problem.
  • Page 76 UPER ERVER 5035L-I User's Manual Notes...

  • Page 77: Appendix B Installing Windows

    RAID settings before you install the OS and other software drivers. To install the Linux OS or to confi gure RAID settings, please refer to the OS Installation or RAID Confi guration User Guides posted on our web site at www.supermicro.com/sup- port/manuals. Please note that the ICH9R Driver does not support the Windows 2000 OS.
  • Page 78 Windows XP/2000/2003 installation. After the Windows XP/2000/2003 OS Installation is completed, the system will automatically reboot. Insert the Supermicro Setup CD that came with your motherboard into the CD Drive during system boot, and the main screen will display.

  • Page 79: Appendix C System Specifi Cations

    Appendix C: System Specifi cations Appendix C System Specifi cations Processors One Intel® Core™ 2 processor E4000 series or a Pentium® dual core or Celeron® brand processor up to 800 MHz FSB Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel 945GC + ICH7R BIOS...
  • Page 80 UPER ERVER 5035L-IB User's Manual Weight Gross (Bare Bone): 16 lbs. (7.26 kg.) System Cooling One whisper-quiet 9-cm exhaust fan System Input Requirements AC Input Voltage: 100-240 VAC Rated Input Current: 6A (115V) to 3A (240V) Rated Input Frequency: 50/60 Hz Power Supply Rated Output Power: 300W (Part# PWS-303-PQ) Rated Output Voltages: +3.3V (16A), +5V (19A), +12V (11A), -12V (0.15A),...
  • Page 81 Appendix C: System Specifi cations Notes...
  • Page 82 ERVER 5035L-IB User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in signifi...
