- Page 1 INSTRUCTION MANUAL MIBRASA - CHARCOAL OVENS ® WWW.MIBRASA.COM...
-
Page 2: Table Of Contents
CONTENTS Page Introduction Description of MIBRASA®. Models Installation Instructions 7-11 4.1 Installation and assembly instructions. 4.2 Fume extraction 5. Instructions of use 12-14 5.1 Loading the charcoal 5.2 Lighting the charcoal 5.3 Before cooking 5.4 Ready to cook 5.5 After use 5.6 Using the oven again... - Page 3 1. INTRODUCTION Congratulations on the purchase of one of our MIBRASA® ovens. We guarantee you will not be disappointed. Our Charcoal Oven MIBRASA® is robust and solid, an essential piece of equipment for any kitchen, which will give unique and delicious flavour to all your foods.
- Page 4 2. MIBRASA ® OVEN’S DESCRIPTION 1. Fire Break 2. Damper ( Open / Closed) 3. Door Handle 4. Grills 5. Thermometre 6. Cast Iron Grids 7. Door 8. Grease Collector 9. Ashpan Note: Regulating the entrance of airflow is controlled through the opening and closing of the ash pan whilst the outflow of air is controlled using the damper.
- Page 5 3. MODELS - WORKTOP OVENS HMB MINI Model HMB MINI Note: The HMB MINI should be set upon a worktop, 85cm above floor level. HMB 75, 110, 160 Model HMB 75 1030 1080 HMB 110 1120 1170 HMB 160 1120...
- Page 6 HMB SB 75, 110, 160 Model HMB SB 75 1000 1180 1080 HMB SB 110 1090 1270 1170 HMB SB 160 1090 1270 1020 1360 Note: The HMB SB should be set upon a worktop +/- 60cm above the floor level. - OVENS WITH CUPBOARD BELOW HMB AB 75, 110, 160 Model...
- Page 7 HMB AB SB 75, 110, 160 Model HMB AB SB 75 1810 1630 1080 HMB AB SB 110 1860 1680 1170 HMB AB SB 160 1860 1680 1020 1360 - OVENS WITH FULL CUPBOARD HMB AC 75, 110, 160 Model HMB AC 75 1870 1090...
-
Page 8: Installation Instructions
Such support must be strong enough to support the weight of the oven. The height of the table or stand for HMB MINI oven should be about 85 cm, and the height for 75/110/160 HMB will be about 70 cm. - Page 9 - Models with cupboard below: HMB AB 75, 110, 160 ; HMB AB SB 75, 110, 160 In order to attach the oven with the cupboard underneath, remove the grill, the cast iron bars, the supports and the ashpan. Carefully insert the forks of a suitable lifting device all the way into the space for the ashpan.
- Page 10 - Models with full cupboard: HMB AC 75, 110, 160 Remove the furniture beneath the cupboard. Place the cupboard in the desired position, open the cupboard doors and remove the grill and dismantle the front of the oven by removing the bolts found on both sides.
-
Page 11: Fume Extraction
Installation of the firebreak and the dissipating filter are recommended. Table of hood measurements and required flow rates: Flow rate Hood measurements (cm) Model (m3/h) (width/depth.) HMB MINI 2500 100 x 100 HMB 75 2800 130 x 130 HMB 110 3200... - Page 12 - Oven installed under extractor hood with other cooking appliances. General tubing: It is necessary to install the oven with the firebreak and dissipating filter. In this way the possible escape of sparks or flames are avoided, the fumes are filtered and the flow of smoke is gently reduced, cooling its temperature prior to contact with the ventilation system.
-
Page 13: Instructions Of Use
Open the ashpan about 5 cm. Position MIBRASA® firelighters in three places; one in the centre of the oven and one either side of the heap of coal. Put a little piece of coal on top of the firelighters, to facilitate setting it alight. -
Page 14: Before Cooking
5.3 BEFORE COOKING Once the coal has been lit, you should wait at least 40 minutes, until the coal has totally burned down to embers. It is important not to start cooking until the charcoal has burned down to embers. Once the embers are burning, close the ashpan, and leave to rest for a few minutes until the flames die down. -
Page 15: After Use
Gently turn the draft regulator to a 45 º – 60 º angle so that the oven reaches a suitable temperature for cooking. (See Fig. 1). Remember that the ashpan should remain closed when cooking. You can change the position of the draft regulator according to how high or how low the temperature needs to be. -
Page 16: Safety And Maintenance Standards
• Keep flammable products away from children. • We recommend you only use MIBRASA® charcoal. • Do not put a barbecue cover or other flammable items on or in a MIBRASA® oven. • Keep children and pets away from the oven. -
Page 17: Daily Cleaning
We recommend using a double filter system for the Extractor Hood area where the oven is located. MIBRASA® is not responsible for any damages occurred caused by wrongful use. - Page 18 Factory, Offices and Showroom: Polygon Pla de Sant Joan C/ Joan Rovira i Bastons, Nave 26 17230 Palamós (Girona) Telf. +34 972 601 942 Web: www.mibrasa.com E-mail: mibrasa@mibrasa.com...
