Dell 1707FPc Service Manual 17” LCD MONITOR DELL 1707FPc THESE DOCUMENTS ARE FOR REPAIR SERVICE INFORMATION ONLY.EVERY REASONABLE EFFORT HAS BEEN MADE TO ENSURE THE ACCURACY OF THIS MANUAL; WE CANNOT GUARANTEE THE ACCURACY OFTHIS INFORMATION AFTER THE DATE OF PUBLICATION AND DISCLAIMS RELIABILITY FOR...
Dell 1707FPc Revision List Revision Release Date Revise history TPV model T780KSCDKRDFUP T780KSCDKRDMUP Nov.-28-2005 Initial Release T780KGCHKRDEUP T780KGCHKRDMUP Sold area in EU and attach the corresponding Dec.-22-2005 T780KSCHBRDEQP Mar.-28-2006 Add “Definition Of Pixel Defects” Add” Max Brightness measurement ” on...
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINGS Important Safety Notice Proper service and repair is important to the safe, reliable operation of all Dell Company** Equipment. The service procedures recommended by Dell and described in this service manual are effective methods of performing service operations.
165MHz (Max) Optimal preset resolution 1280 x 1024 at 60 Hz Highest preset resolution 1280 x 1024 at 75 Hz Plug & Play VESA DDC ON Mode (with Dell <65W Sound bar and USB EPA ENERGY ® active) STAR OFF Mode <3W...
Dell 1707FPc 2. LCD Monitor Description The LCD monitor will contain a main board, power board, key board, and USB board which house the flat panel control logic, brightness control logic and DDC. The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips each voltage.
Dell 1707FPc 3. Operation instructions 3.1 General Instructions Press the power button to turn the monitor on or off. The other control buttons are located at front panel of the monitor. By changing these settings, the picture can be adjusted to your personal preferences.
Page 8
Use the Input Select button to select between two different video signals that may be connected to your monitor. NOTE: The floating 'Dell Self-test Feature Check' dialog appears on a black background If the monitor cannot sense a video signal. Depending upon the selected input, one of the dialogs shown below will scroll continually.
Page 9
Use to mount the monitor. (Behind attached base plate) Barcode serial number label Refer to this label if you need to contact Dell for technical support. Security lock slot Use a security lock with the slot to help secure your monitor.
Page 10
Dell 1707FPc Power connector Insert the power cable. Dell Soundbar power connector Connect the power cord for the Soundbar (optional). DVI connector Connect your computer DVI cable. VGA connector Connect your computer VGA cable. Connect the USB cable that came with your monitor to the monitor USB upstream connector and the computer.
Dell 1707FPc 3.3 Adjusting the Picture NOTE: If you change the settings and then either proceed to another menu, or exit the OSD menu, the monitor automatically saves those changes. The changes are also saved if you change the settings and then wait for the OSD menu to disappear.
Page 12
Dell 1707FPc Menu and Icon Description Submenus Select to exit the Main menu Exit Brightness adjusts the luminance of the backlight. Brightness/ Contrast Adjust Brightness first, then adjust Contrast only if further adjustment is necessary. Push the + button to increase luminance and push the - button to decrease luminance (min 0 ~ max 100).
Page 13
Dell 1707FPc NOTE: When using DVI source, the Positioning option is not available. Auto Adjust Even though your computer recognizes your monitor on startup, the Auto Adjustment function optimizes the display settings for use with your particular setup. Select to activate automatic setup and adjustment. The following dialog appears...
Page 14
Dell 1707FPc Blue Preset The color hue is most noticeable in areas of white. • Red Preset Blue Preset is selected to obtain a bluish tint. This color setting is typically used for text based applications (spreadsheets, programming, Normal text editors, etc.).
Page 15
Dell 1707FPc NOTE: When the OSD is locked, pressing the menu button takes the user directly to the OSD settings menu, with OSD Lock selected. Select No (-) to unlock and allow user access to all applicable settings. OSD Lock NOTE: You can also lock or unlock the OSD by pushing and holding the Menu button for 15 seconds.
Page 16
Dell 1707FPc NOTE: When the Dell Soundbar is not properly connected to the monitor, the audio menu is not available. Reset the OSD menu options to the factory-preset values. Factory Reset: Exit — Select to exit out of Reset to Factory Settings menu without resetting any OSD options.
Dell 1707FPc NOTE: The floating Dell Self-test Feature Check dialog appears on-screen if the monitor cannot sense a video signal. Occasionally, no warning message appears, but the screen is blank. This could also indicate that the monitor is not synchronizing with the computer.
Page 18
Dell 1707FPc 1. Turn off your computer and disconnect the power cable. 2. Connect either the white DVI or blue VGA cables to the connectors on the computer and the monitor. Connect the USB cable that was included with your monitor to the computer and the upstream USB connector on the monitor.
Dell 1707FPc 4. Input/Output Specification 4.1 Input Signal Connector 4.1.1 D-Sub Connector Signal Assignment Pin. Signal Assignment Red Video DDC +5V Green Video GND-Sync Blue Video DDC Data Self Test H-Sync R-Ground V-Sync G-Ground DDC Clock B-Ground VGA Connector layout 4.1.2 DVI Connector...
Page 27
Dell 1707FPc 1) MCU Initializes. 2) Is the EEprom blank? 3) Program the EEprom by default values. 4) Get the PWM value of brightness from EEprom. 5) Is the power key pressed? 6) Clear all global flags. 7) Are the AUTO and SELECT keys pressed? 8) Enter factory mode.
Dell 1707FPc 8. Mechanical Instruction Tools: 2 Power screwdrivers (φ=5mm,L=60mm); 1 small cross screwdriver; turnbuckle driver; Setting: Power screwdriver torque A=11 kgF. Cm; torque B=6 kgF. Cm Note: Firstly, put the monitor on a soft, flat and clean surface, wear gloves.
Page 44
Dell 1707FPc 2. Pry the monitor up then find out the hooks’ position, use the tool (like the picture or other card) to insert into the gap of bezel and rear cover. 3. Take off the bezel Remove rear cover :...
Page 45
Dell 1707FPc Remove the shield : 1. Remove the 4 screws by Torque B 2. Remove the USB2 board cover by Torque B or by manual 3. Remove the 6 screws by Torque B or by manual...
Page 46
Dell 1707FPc 4. Disconnect the wire harness between USB1 and USB2 5. Push the main shield as the arrowhead direction Disconnect the connector pin: Disconnect the connector pin between key and main boards...
Page 47
Dell 1707FPc Install: Lay the KEPC cable as the figure showed Remove USB and main board : 1. Remove the 7 screws by Torque B 2. Disconnect the connector wire...
Page 48
Dell 1707FPc 3. Disconnect the wire harness between main board and panel EVA washers Magnetism ring Cable hook Install: Fix the LVDS cable by black tape and cable hook Black tape...
Page 49
Dell 1707FPc 4. Disconnect the wire holder Install: Lay the cables as the line direction Remove the power board : Remove the 5 screws by Torque...
Page 50
Dell 1707FPc Disconnect wire harness : Disconnect the wire harness between power board and lamps Stick black tapes on the black lights connector for fixing the cables Remove USB board : Remove the 2 screws by Torque...
Page 51
Dell 1707FPc Remove the main frame : Remove the 4 screws (left and right) by manual or torque = 3kgF.Cm Samsung panel LG panel...
Dell 1707FPc 9. Maintainability 9.1 Equipments and Tools Requirement 1. Voltage meter 2. Oscilloscope 3. Pattern Generator 4. LCD Color Analyzer 5. Service Manual 6. User Manual...
Dell 1707FPc 9.2 Trouble shooting 9.2.1 Main Board Note: 1. If replace “Main-Board”, Please re-do “DDC-content” programmed & “White-Balance”. 2. If replace “Power Board” only, Please re-do “ White-Balance”. No power No power Press power key and look if the...
Page 54
Dell 1707FPc No picture (LED is orange) No picture Measure U601 PIN2=3.3V U602 PIN2=1.8V Replace U601, U602 X301 oscillate waveforms are normal Replace X301 Check if the sync signal from computer is output and video cable is connected normally Input the sync signal of...
Page 55
Dell 1707FPc White screen White screen Measure Q603 base X301 oscillate waveform is normal is high level? Replace X301 Check Q602, Q603 is broken Check reset circuit of or CN501 solder? U401 is normal Check Correspondent Check Correspondent component. component.
Page 56
Dell 1707FPc 9.2.2 Inverter/Power Board No Power No power Check AC line volt 110V or 220V Check AC line Check the voltage of C903(+) Check F901, bridge rectified circuit Check start voltage for the pin3 of IC901 Check R903, R04, R905...
Page 58
Dell 1707FPc 9.2.3 Key Board OSD is unstable or not working Is Keypad board connecting normally? Connect Keypad Board Is Button Switch normally? Replace Button Switch Is Keypad board normally? Replace Keypad Board Check main board...
Dell 1707FPc 10. White balance, Luminance adjustment Approximately 2 hours should be allowed for warm up before proceeding White-Balance adjustment. Before started adjust white balance, please setting the Chroma-7120 MEM. Channel 3 to 6500 K colors, MEM. Channel 4 to 9300 K colors, MEM.
Page 60
Dell 1707FPc 18. Adjust the RED on OSD window until chroma 7120 indicator reached the value R=100 19. Adjust the GREEN on OSD, until chroma 7120 indicator reached G=100 20. Adjust the BLUE on OSD, until chroma 7120 indicator reached B=100 21.
Dell 1707FPc 12. ISP Instruction 12.1 Software requirement and connection Operating system requirement (1) Microsoft windows OS. (2) 100M free hard-drive space. (3) 1 free parallel port for DDC2BI communication. The hardware Connection 12V Input Link to Dell DVI connector...
Page 63
Dell 1707FPc 12.2 Install the software (Gprobe 5.0) for ISP Writer A. Double-click the Install software Select the folder where you would like Genesis Gprobe 5 to be installed Completing the Genesis Gprobe 5 setup wizard Note: After finishing the installation, you must restart the PC.
Page 64
Dell 1707FPc B. Next, install the Update software Completing the update 1 for Genesis Gprobe 5.0 setup wizard C. Copy the to C: program files → GProbe5.0.0.15 → Genesis Microchip → GProbe 5 → ChipDB folder, Installation Finished.
Dell 1707FPc 12.3 Running program After the installation, a short-cut icon will appear on your desktop, double click it will run the program. (1). Select the IC type (NOTE: If there is not this selection, please check the “ChipDB”): Note: Firstly, you can check the I²C normal or not by inputting the “test” in the position where to load MCU software.
Page 66
Dell 1707FPc Set the Connection Settings → Connection → Device to Parallel, click OK! (3). Select Commands → Batch:...
Page 67
(.txt) Click open. (4). Unplug the Dell AC power, until the LED indicator is off, press Enter or Execute button, when the .txt of MCU is in gray, for example , re-plug Dell AC power, Writer is in progress.
Dell 1707FPc 13. Check List 1) After replacing LCD Main board and panel, Check if white-balance is within the specs, then re-writing DDC is necessary. The white-balance value for each common color temperature: 9300 parameter is x=283±28, y=297±28, Y = 180 ±10 cd/m 6500 parameter is x =313±28, y=329±28, Y = 180 ±10 cd/m...
Page 69
Dell 1707FPc 7. Select Exit to the upper menu after completing the adjustment. Then press POWER OFF to exit and save it. 3) Steps for writing DDC: 1. Employ PC, and connect the DDC-writing instrument and the instrument that is ready for writing into DDC to the power of 12V.
Page 70
Dell 1707FPc Notes: 1. Make sure the system time of PC is in accordance with the real time before writing. 2. The schematic picture is just as an example for description; the exact content of the DDC is dependent on the serial number of the BARCORD of this model.
Dell 1707FPc 14. BOM List Different key parts List Part NO. Description Quantity Unit Remark 750GLG70E1T 3 LPL 17" TLB3 PANEL T780KGCHKRDMUP 750GLG70E1T41Z D LPL 17" TLB4 ZBD PANEL T780KGCHKRDEUP 750GLS70U2112Z SEC 17" ZBD PANEL T780KSCDKRDMUP 750GLS70U2122Z SEC 17" EU-L21 CLA ZBD...
Page 72
Dell 1707FPc 045G 88609 27 EPE BAG FOR MONITOR 052G 1186 SMALL TAPE 052G6020 2DEA FILM PROTET 052G6022 1500 SMALL TAPE 052G6025 11936 MYLAR 085G 720 1 SHIELD USB 089G 175 9 USB CABLE E089B 089G 728GAA 2D SIGNAL CABLE...
Page 73
Dell 1707FPc 033G4947 VH L RISER ARM COVER 033G4948 SN L HINGE LUCK BUUTON 033G5011 VH B HINGE-COVER-F 033G5012 SN B TILP COVER 034G1742 SN B VESA COVER 034G1745 VH B HINGE-COVER-B 034G1746 SN B STAND-F 034G1747 SN B STNAD-B...
Page 83
Dell 1707FPc D211 093G 64 33 DIO SIG SM BAV99 (PHSE)R D208 093G 64 33 DIO SIG SM BAV99 (PHSE)R D207 093G 64 33 DIO SIG SM BAV99 (PHSE)R D202 093G 64 33 DIO SIG SM BAV99 (PHSE)R D203 093G 64 33...
Page 84
Dell 1707FPc ZD209 093G 39S 34 T UDZS5.6B ZD210 093G 39S 34 T UDZS5.6B ZD211 093G 39S 34 T UDZS5.6B ZD212 093G 39S 34 T UDZS5.6B ZD301 093G 39S 34 T UDZS5.6B 715G1667 1 MAIN BOARD PCB 065G0603104 12 CER2 0603 X7R 16V 100N P...
Page 91
Dell 1707FPc ZD705 093G 64 49 SU DIODE ESD EGA 10603V05A1-B INPAQ ZD704 093G 64 49 SU DIODE ESD EGA 10603V05A1-B INPAQ ZD703 093G 64 49 SU DIODE ESD EGA 10603V05A1-B INPAQ ZD702 093G 64 49 SU DIODE ESD EGA 10603V05A1-B INPAQ...
Page 92
Dell 1707FPc 715G1775 2 POWER BOARD PCB 034FPE19P03 CASE EEL19 034FPE19P03 CASE EEL19 T780KSCHBRDEQP Location Part No. for TPV Description CBPC780KSCDRP CONVERSION BOARD KEPC780KE2P KEY BOARD PWPC1742SED3P POWER BOARD USB780A2P USB BOARD USB780A3P USB BOARD 11G6070 1 TIE MOUNTS 11G6092 1...
Page 93
Dell 1707FPc 45G 88609 26 EPE BAG FOR BASE 45G 88609 27 EPE BAG FOR MONITOR 1186 SMALL TAPE 52G6020 2DEA FILM PROTECT 52G6022 1500 SMALL TAPE 52G6025 11936 MYLAR 52G6025 11938 MYLAR 70G1700700 4C CD MANUAL 85G 720 1...
