Amp lifier
MODE L
HCCA10002
HCCA10004
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCCA10002 and is the answer not in the manual?

Questions and answers

Related Manuals for Orion HCCA10002

Summary of Contents for Orion HCCA10002

  • Page 1 Amp lifier MODE L HCCA10002 HCCA10004 OWNER'S MANUAL...

  • Page 2: End Panel Layouts

    END PANEL LAYOUTS Speakers (Left channel) -Connect the speakers to these terminals. (HCCA10002 only, refer to the Speaker Connections section of this guide.) HCCA10002 Figure 1 Input - Accepts RCA input from a head unit, preamplifier, or Figura 1 equalizer (HCCA10002 only).
  • Page 3 ground terminal or any other factory ground points. Top cover lock - Use the key provided or the 3mm hex key to unlock and remove the top cover. NOTE: Make all connections to power, ground, speakers, and remote terminals before final positioning and installation of the amplifier in the vehicle.

  • Page 4: Removing The Top Cover

    REMOVING THE TOP COVER HIGH PASS - Adjusts the lower crossover frequency of the ampli- fier. CROSSOVER SELECTION - ALL is the full range setting, LOW is the Figure 5 Top Cover low pass setting and HIGH is the high pass setting. Figura 5 Abbildung 5 SLOPE - Selects the crossover roll off between 12db and 24db...

  • Page 5: Cea Specifications

    CEA SPECIFICATIONS SPECIFICATIONS HCCA10002 Amplifier Section HCCA10002 HCCA10004 Power Output: 250 Watts RMS x 2 at 4 ohms and Power Output 4Ω (Watts 250 x 2 125 x 4 < 1% THD+N rms) * Signal to Noise Ratio: >70 dBA (reference 1 Watt Power Output 2Ω...

  • Page 6: Amplifier Settings

    Ground 4 AWG )NPUT'AIN Speaker 8 - 12 AWG Speaker 8 - 12 AWG These Orion amplifiers have level adjustments to allow for easy inte- Input Impedance, 20 kΩ 20 kΩ gration with any source unit. The input sensitivity is a push button...
  • Page 7 High attenuates low frequencies and is used for mid-range speak- ers and tweeters. The line outputs on Orion amplifiers offer easy system expansion and Low attenuates high frequencies and is used for subwoofer can be used to route signal from the RCA line outputs to the next speakers.
  • Page 8 (IGH-0ASS#ROSSOVER When the switch is in the middle (ALL position), the high-pass cross- over is bypassed. When the switch is to the right (HIGH position), the high-pass crossover is active. The high-pass crossover is continuously variable from 50Hz to 2kHz. 2EMOTE'AIN/PERATION(OPTIONAL) The remote gain port provides easy remote access to the internal gain structure of the HCCA power amplifier.
  • Page 9 3EALED%XAMPLE(IGH-0ASS3ETAT20(Z 3EALED%XAMPLE(IGH-0ASS3ETAT30(Z This sealed example is the same 12-inch woofer in the recommended In this example, the frequency has been increased to 30 Hz. Up to sealed enclosure. Up to 6 dB of boost is capable if 20 Hz was used. 6 dB of boost is capable at this frequency.

  • Page 10: Amplifier Wiring

    30 Hz. With +10dB of boost, the woofer has more output down to 22 Hz. The excursion Orion HCCA10002 Fuse Size: 100 Amp. below the tuning frequency has been greatly reduced.

  • Page 11: Bridge Configuration

    Three Channel (L Channel, R Channel, Bridged) 3PEAKER#ONNECTIONS(##!10002 Left and Right are configured for two-channel stereo operation. The Orion HCCA10002 amplifier offer one positive and one negative output terminal for ease of connecting channel 1(L CH) and/or 2(R CH) Lowest recommended impedance is 2Ω stereo.
  • Page 12 Three Channel Configuration 3PEAKER#ONNECTIONS(##!10004 The Orion HCCA10004 amplifier offers four positive and four negative Channels 1/2 are configured for 2-channel stereo operation. output terminals for ease of connecting channel 1(LF), 2(RF), 3(RR), and 4(LR) outputs to the speakers. The amplifier is stable to 2Ω per Channel 1/2 lowest recommended impedance is 2Ω...
  • Page 13 Five Channel Configuration Tri-Mode Six Channel Configuration Channels 1/2 are configured for 2-channel stereo operation. Lowest recommended impedance is 2Ω stereo and 4Ω bridged mono. Channel 1/2 lowest recommended impedance is 2Ω stereo. Lowest Front and rear outputs must be set for full range operation. recommended impedance is 2Ω...

  • Page 14: Amplifier Installation

    The location of your amplifier will depend on several important issues. WARNING! Be careful not to cut or drill into gas tanks, fuel lines, Due to the low profile size of the Orion amplifiers, there are many brake lines, hydraulic lines, vacuum lines, or electrical wiring when possible installation locations that will yield satisfactory amplifier working on your vehicle.
  • Page 15 Electric drill with assorted drill bits Grommets Orion amplifiers generate a certain amount of heat as part of normal operation. Be sure the area around the amplifier is unobstructed to Heat shrink tubing allow adequate air circulation.
  • Page 16 This will deter- NOTE: Connect all input, power and speaker connections to amplifier mine the ultimate performance of your Orion amplifier. Refer before mounting the amplifier in its final location. to the Signal Input and Output Configurations and Speaker Determine the location for the amplifier.

  • Page 17: Setup And Troubleshooting

    If the output is clear and undistorted, continue to the Adjusting system. This will help ensure years of trouble-free operation. Please the Sound of the System section of this manual. refer to the listed steps below when testing the sound of your Orion system. !DJUSTINGTHE3OUNDOFTHE3YSTEM Check all the wiring connections to be sure they are correct and Once you have checked the system’s operation, adjust the sound of...
  • Page 18 !MPLIFIER6ISUAL4ROUBLESHOOTING happen if the amplifier has an internal problem. The amplifier Your new Orion HCCA amplifier has three indicator lights (LED’s) on will flash 4 short pulses, followed by a long pause, then repeat. the top cover of the amplifier as seen in the next figure. These lights...
  • Page 19 LED (power) closest to the Orion logo in the air to circulate and keep it cool. Amplifiers will get hot because diagram will be the furthest from the logo with the cover reversed.
  • Page 20 4ROUBLESHOOTING4IPS Symptom Probable Cause Action To Take No output Low or no remote turn-on Check remote turn-on voltage at voltage amplifier and repair as needed. Fuse blown Check power wire's integrity and check for speaker shorts. Fix as needed and replace fuse. Power wires not connected Check power wire and ground connections and repair or replace as needed.
  • Page 21 Symptom Probable Cause Action To Take Speaker not connected to amplifier properly. Check speaker wires and repair or replace as needed. Refer to the Speaker Connections section of this manual for detailed instructions Internal crossover not set properly for speakers Readjust crossovers.

  • Page 22: Appendix-Programmable Features

    APPENDIX—PROGRAMMABLE FEATURES Input Gain Range (Volts) - The position of the gain switch determines the gain range available. If the gain switch is in the high mode, the ranges are Default (0.2 - 4V), 0.2-1V, 1-1.5V,1.5 - 3.5V, 3.5-4V. If the The following listing are ESP -2 features that can be programmed or ®...
  • Page 23 30 seconds. The major and minor revision levels of the ESP2 software should be referenced should it be necessary to contact MD Audio Engineering or Orion. Car Amplifiers Orion Car Audio...
