Technical Support
Thank you for selecting On Networks products.
After installing your device, locate the serial number on the label
of your product and use it to register your product at
www.on-networks.com/register.
Registration is required before
you can use our telephone support service.
Go to
support.on-networks.com
for product updates and web
support.
On Networks
September 2012
Easy, Reliable & Secure
N300 Wireless ADSL2+ Modem Router
N300RM Installation Guide
Package Contents
Installation Guide
The box should contain the following items. If any items are
incorrect, missing, or damaged, contact your On Networks
dealer.
Filter/splitter
Phone cable
N300 Modem Router
The filter or
splitter provided
depends on the
region.
Ethernet cable Power adapter
Advertisement
Table of Contents
Related Manuals for on networks N300
Summary of Contents for on networks N300
-
Page 1: Package Contents
Thank you for selecting On Networks products. The box should contain the following items. If any items are After installing your device, locate the serial number on the label incorrect, missing, or damaged, contact your On Networks N300 Wireless ADSL2+ Modem Router dealer. - Page 2 You can follow this diagram to connect your modem router, or follow the instructions in this booklet. Declarations of Conformity For complete DoC, visit the On Networks EU Declarations of Conformity website support.on-networks.com/doc This symbol is placed in accordance with the European Union Directive 2002/96 on the Waste Electrical and Electronic Equipment (the WEEE Directive).
-
Page 3: Table Of Contents
Contents Before You Begin 2 Install Your Modem Router 3 Preset Wireless Security 5 Wireless Network Settings 6 Add Wireless Devices to the Network 7 WPS Method 7 Manual Method 7 Access the Modem Router to Make Changes 8 Troubleshooting 9... -
Page 4: Before You Begin
Before You Begin Make sure that your DSL service is active before you install the modem router. You need the information that is listed here to install your DSL modem and connect to the Internet. Locate it and have it on hand before you start the installation procedure. -
Page 5: Install Your Modem Router
Install Your Modem Router A microfilter filters DSL interference out of standard phone equipment that shares the line with DSL service. Examples of devices are telephones, fax machines, answering machines, and caller ID displays. 1. Connect the ADSL. a. Install an ADSL filter/splitter between the phone line and the phone. - Page 6 2. Add power to the modem router. a. Connect the power adapter to the router, and plug the power adapter into an outlet. b. Wait for the WiFi LED on the front panel to turn on. If none of the LEDs on the front panel are on, press the Power On/ Off button on the rear panel of the modem router.
-
Page 7: Preset Wireless Security
This information is on the label on the bottom of the product. On Networks recommends that you do not change the preset WiFi network name (SSID) and network key (password). If you do for any reason change the settings, the security SSID and password on the bottom of the product no longer apply. -
Page 8: Wireless Network Settings
Wireless Network Settings Record the default preset wireless settings that are printed on the label in the spaces for easy reference. WiFi network name (SSID): Network key (password): If you change the default settings, record them here for easy reference, and then store this booklet in a safe place: WiFi network name (SSID): Network key (password): To retrieve or update your wireless password, type... -
Page 9: Add Wireless Devices To The Network
Add Wireless Devices to the Network Choose either the manual or Wi-Fi Protected Setup (WPS) method to add wireless computers and other devices to your wireless network. WPS Method When your wireless device supports WPS (Wi-Fi Protected Setup), you might be prompted to press the WPS button on the router instead of entering a password. -
Page 10: Access The Modem Router To Make Changes
Access the Modem Router to Make Changes After you set up the modem router, you can log in to the router to view its settings or change them. To log in to the modem router: 1. Launch a web browser from a computer or wireless device that is connected to the modem router. -
Page 11: Troubleshooting
To change the password for the modem router user name: 1. Log in to the modem router. 2. Select MANAGEMENT > Set Password to display the Set Password screen: 3. Type your old password, and type the new password twice. Troubleshooting When the browser does not display the web page: •... - Page 12 If the modem router is unable to access the Internet: 1. Check your cables. • Disconnect and reconnect each cable. There is usually an audible click when the cable is correctly connected. • See if the telephone cable connecting your DSL modem router to the wall jack is plugged into a filter.
