- Page 1 VivoPC Barebone User Manual...
- Page 2 ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or infringement under this Warranty Statement. This limit also applies to ASUS’ suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and your reseller are collectively responsible.
-
Page 3: Table Of Contents
Installing system components Installing memory modules .................22 Installing storage devices ................27 Installing 2.5-inch HDDs/SSDs ..............27 Installing a 3.5-inch HDD ................34 Appendix Safety information ...................40 Setting up your system.................40 Care during use ....................40 Regulatory notices ...................42 ASUS contact information ................48 VivoPC Barebone... -
Page 4: About This Manual
This chapter provides you with information on using your VivoPC. Chapter 3: Installing system components This chapter provides you with information on how to install new components to your VivoPC barebone. Appendices This section includes notices and safety statements your VivoPC. Conventions used in this manual... -
Page 5: Package Contents
• The availability and quantity of these items vary with your VivoPC package. • If the device or any of its components fail or malfunction during normal or proper use and it is still within the warranty period, bring the device and the warranty card to you nearest ASUS Service Center. VivoPC Barebone... - Page 6 VivoPC Barebone...
-
Page 7: Getting To Know Your Vivopc
Getting to know your VivoPC... -
Page 8: Features
VivoPC and disconnect the power cable and other peripherals. Audio speakers Your VivoPC uses SonicMaster technology to provide hi-fi sound quality, with richer bass sounds, straight from the built-in audio speakers. Drive activity indicator This indicator lights up when your VivoPC is accessing the internal storage drive. VivoPC Barebone... -
Page 9: Left Side
Left side Air vents The air vents on the left side allow cooler air to enter your VivoPC chassis. IMPORTANT! For optimum heat dissipation and air ventilation, ensure that the air vents are free from obstructions. VivoPC Barebone... -
Page 10: Rear Panel
The Kensington security slot allows you to secure your VivoPC using Kensington® security products. USB 3.0 ports These Universal Serial Bus 3.0 (USB 3.0) ports provide a transfer rate of up to 5 Gbit/s and are backward compatible with USB 2.0. VivoPC Barebone... -
Page 11: Lan Port
HDMI port The HDMI (High Definition Multimedia Interface) port supports a Full-HD device such as an LCD TV or monitor to allow viewing on a larger external display. VivoPC Barebone... - Page 12 VivoPC. To prevent damage to the VivoPC, always use the bundled power adapter. WARNING! The power adapter may become warm to hot when in use. Do not cover the adapter and keep it away from your body. VivoPC Barebone...
-
Page 13: Using Your Vivopc
Using your VivoPC... -
Page 14: Getting Started
Plug the AC power cord into a 100 V~240 V power source. Connect the DC power connector into your VivoPC’s power (DC) input port. NOTE: The power adapter may vary in appearance depending on the model or region. VivoPC Barebone... - Page 15 VivoPC. • We strongly recommend that you use a grounded wall socket while using your VivoPC. • The socket outlet must be easily accessible and near your VivoPC. • To disconnect your VivoPC from its main power supply, unplug your VivoPC from the power socket. NOTE: Power adapter information: • Input voltage: 100 Vac - 240 Vac • Input frequency: 50 Hz - 60 Hz • Rating output current: 3.42 A (65 W) or 4.74 A (90 W) (varies per model) • Rating output voltage: 19 V VivoPC Barebone...
-
Page 16: Connecting A Display Panel
NOTE: The HDMI to DVI adapter, DisplayPort to VGA adapter, or HDMI to VGA adapter are each sold separately. To connect a display panel to your VivoPC: Connect a display cable either to the HDMI or DisplayPort port. Connecting display via HDMI port Connecting display via DisplayPort port VivoPC Barebone... -
Page 17: Connecting Usb Keyboard Or Mouse
To connect a keyboard and mouse to your VivoPC: Connect the USB cable from your keyboard and mouse to any of the USB 2.0 ports of your VivoPC. Connecting keyboard or mouse via USB 2.0 port VivoPC Barebone... -
Page 18: Turning On Your Vivopc
Turning on your VivoPC Press the power button to turn on your VivoPC. VivoPC Barebone... -
Page 19: Turning Off Your Vivopc
Turning off your VivoPC If your VivoPC is unresponsive, press and hold the power button for at least four (4) seconds until your VivoPC turns off. Putting your VivoPC to sleep To put your VivoPC on Sleep mode, press the Power button once. Entering the BIOS Setup BIOS (Basic Input and Output System) stores system hardware settings that are needed for system startup in the VivoPC. -
Page 20: Quickly Enter The Bios
Quickly enter the BIOS To quickly enter the BIOS: • Press the power button for at least four (4) seconds to shut down your VivoPC, then press the power button again to turn your VivoPC back on, then press <F2> or <Del> during POST. • When your VivoPC is off, disconnect the power cord from your VivoPC’s power connector. Reconnect the power cable and press the power button to turn on your VivoPC. Press <F2> or <Del> during POST. -
Page 21: Installing System Components
Installing system components... -
Page 22: Installing Memory Modules
Installing memory modules Your VivoPC Barebone comes with two SO-DIMM memory slots that allow you to install two 2 GB, 4 GB, or 8 GB unbuffered with non-ECC 1.35V DDR3 204-pin SO-DIMMs for a maximum of 16 GB memory. IMPORTANT! You can only install 1.35V DDR3 SO-DIMM to the VivoPC’s DIMM slots. - Page 23 7. Carefully slide the DualBay adapter from the SATA connector then remove it from the drive bay. NOTE: The VivoPC barebone is shipped with an empty DualBay adapter by default. If you wish to replace the DualBay adapter with a 3.5-inch HDD, refer to the section Installing a 3.5-inch HDD for more information.
- Page 24 10. Align and insert the memory module into the slot (A) and press it down (B) until it is securely seated in place. Repeat the same steps to install the other memory module. IMPORTANT! Always install into the lower slot first. VivoPC Barebone...
- Page 25 11. Replace the SO-DIMM slot cover (A) and secure it with the screw (B) you removed earlier. 12. Replace the Vivo DualBay adapter into the drive bay then slide it towards the SATA connector. SATA connector VivoPC Barebone...
- Page 26 13. Replace the top cover then slide it towards the front of VivoPC to re-attach. 14. Lock the latch to securely fasten the top cover to the chassis. VivoPC Barebone...
-
Page 27: Installing Storage Devices
Place the VivoPC on a flat and stable surface. Press down the latch at the rear panel to release the top cover of the VivoPC. Slide the top cover towards the rear of the VivoPC until it is detached from the chassis. VivoPC Barebone... - Page 28 Remove the cover and set aside. Carefully slide the Vivo DualBay adapter away from the SATA connector then remove it from the drive bay. Vivo DualBay adapter VivoPC 6. Place the Vivo DualBay adapter on a flat and stable surface. 7. Remove the screws at the rear of the Vivo DualBay adapter and set aside. VivoPC Barebone...
- Page 29 SATA connector on the lower part of the Vivo DualBay adapter then slide the 2.5-inch HDD or SSD into the adapter’s SATA connector as shown. SATA connector (HDD/SSD) SATA connector (lower port on Vivo DualBay adapter) 2.5-inch HDD/SSD Vivo DualBay adapter VivoPC Barebone...
- Page 30 Vivo DualBay cover matching the screw holes on the drive with the screw holes on the top cover. second 2.5-inch HDD/SSD screw holes (2.5-inch HDD/SSD) top cover screw holes ( top cover) front of top cover VivoPC Barebone...
- Page 31 SATA connector top cover and 2.5-inch HDD/SSD assembly Vivo DualBay adapter and 2.5-inch HDD/SSD assembly screw holes (top cover) screw holes (Vivo DualBay adapter) VivoPC Barebone...
- Page 32 16. Secure the top cover and 2.5-inch HDD or SSD assembly to the Vivo DualBay adapter using the screws that you removed earlier in step 7. 17. Place the Vivo DualBay adapter assembly into the VivoPC’s drive bay then slide it towards the SATA connector to secure it in place. VivoPC Barebone...
- Page 33 18. Replace the top cover then slide it towards the front of VivoPC to re-attach. 19. Lock the latch to securely fasten the top cover to the chassis. 20. Reconnect all cables and peripherals. 21. Turn on your VivoPC. VivoPC Barebone...
-
Page 34: Installing A 3.5-Inch Hdd
Press down the latch at the rear panel to release the top cover of the VivoPC. Slide the top cover towards the rear of VivoPC until it is detached from the chassis. Remove the cover and set aside. VivoPC Barebone... - Page 35 Vivo DualBay adapter VivoPC 6. Remove the four black screws with rubber heads from the Vivo DualBay adapter then set aside. NOTE: Use an appropriate tool such as a screw driver when performing this step. rubber head black screw 7. Prepare the 3.5-inch HDD. VivoPC Barebone...
- Page 36 10. Match the rubber heads with the four screw slots on the drive bay. 11. Carefully, place the Serial ATA HDD into the drive bay, then slide the drive towards the SATA connector. SATA connector rubber head screw slot VivoPC Barebone...
- Page 37 12. Ensure that the Serial ATA HDD is securely seated in place and the SATA connectors are connected properly. 13. Replace the top cover then slide it towards the front of VivoPC to re-attach. VivoPC Barebone...
- Page 38 15. Lock the latch to securely fasten the top cover to the chassis. VivoPC Barebone...
-
Page 39: Appendix
Appendix... -
Page 40: Safety Information
The power cord or plug is damaged. – Liquid has been spilled into the system. – The system does not function properly even if you follow the operating instructions. – The system was dropped or the cabinet is damaged. – The system performance changes. VivoPC Barebone... - Page 41 This symbol of the crossed out wheeled bin indicates that the product (electrical, electronic equipment, and mercury-containing button cell battery) should not be placed in municipal waste. Check local technical support services for product recycling. VivoPC Barebone...
-
Page 42: Regulatory Notices
REACH Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulatory framework, we publish the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. -
Page 43: Rf Exposure Warning
RF exposure compliance. Declaration of Conformity (R&TTE directive 1999/5/EC) The following items were completed and are considered relevant and sufficient: • Essential requirements as in [Article 3] • Protection requirements for health and safety as in [Article 3.1a] • Testing for electric safety according to [EN 60950] • Protection requirements for electromagnetic compatibility in [Article 3.1b] • Testing for electromagnetic compatibility according to [EN 301 489-1] & [EN 301 489-17] • Effective use of the radio spectrum as in [Article 3.2] • Radio test suites according to [EN 300 328-2] VivoPC Barebone... - Page 44 Indre et Loire Loir et Cher Loiret Manche Meuse Nièvre Nord Oise Orne Puy du Dôme Pyrénées Atlantique Pyrénées Bas Rhin Orientales Haute Saône Saône et Loire 75 Paris Tarn et Garonne Vaucluse Vosges Yonne Territoire de Val de Marne Belfort VivoPC Barebone...
- Page 45 End users must follow the specific operating instructions for satisfying RF exposure compliance. Operation is subject to the following two conditions: • This device may not cause interference and • This device must accept any interference, including interference that may cause undesired operation of the device. VivoPC Barebone...
- Page 46 EEC directives 2004/108/EC “Electromagnetic compatibility” and 2006/95/EC “Low voltage directive”. CE marking for devices with wireless LAN/ Bluetooth This equipment complies with the requirements of Directive 1999/5/ EC of the European Parliament and Commission from 9 March, 1999 governing Radio and Telecommunications Equipment and mutual recognition of conformity. Wireless Operation Channel for Different Domains N. America 2.412-2.462 GHz Ch01 through CH11 Japan 2.412-2.484 GHz Ch01 through Ch14 Europe ETSI 2.412-2.472 GHz Ch01 through Ch13 VivoPC Barebone...
- Page 47 Department of Energy helping us all save money and protect the environment through energy efficient products and practices. All ASUS products with the ENERGY STAR logo comply with the ENERGY STAR standard, and the power management feature is enabled by default. The monitor and computer are automatically set to sleep after 10 and 30 minutes of user inactivity.
-
Page 48: Asus Contact Information
Fax +1-510-608-4555 Web site http://usa.asus.com Technical Support Support fax +1-812-284-0883 General support +1-812-282-2787 Online support https://support.asus.com/techserv/techserv.aspx ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, D-40880 Ratingen, Germany Fax +49-2102-959931 Web site http://www.asus.com/de Online contact http://eu-rma.asus.com/sales Technical Support Telephone +49-2102-5789555... - Page 49 VivoPC Barebone...
- Page 50 VivoPC Barebone...
