Casio 3318 Operation Manual

MA0312-EA
Getting Acquainted
Congratulations upon your selection of this CASIO watch. To get the most out of your
purchase, be sure to carefully read this manual and keep it on hand for later reference
when necessary.
Expose the watch to bright light to charge its battery before using it.
You can use this watch even as its battery is being charged by exposure to bright
light.
• Be sure to read "Battery" for important information you need to know when
exposing the watch to bright light.
After purchasing the watch, be sure to remove the spacer from the crown.
Spacer
Crown
Power Saving
indicator
Battery power
indicator (H/M/L)
Crown
About This Manual
General Guide
• Perform the operations described below to change between modes.
• In the Timekeeping Mode, press A to illuminate the face of the watch.
Timekeeping Mode
Pull out
the crown.
Push in
the crown.
Crown
Setting the Current Time
This watch features separate digital and analog timekeeping. The procedures for
setting the digital time and analog time are different.
Setting the Digital Time and Date
The digital display shows the current digital time and date. When setting the digital
time and date, you can also specify 12-hour or 24-hour format, the illumination
duration, and the day of the week language.
• Whenever you need to adjust both the digital and the analog time settings, make
sure you adjust the digital setting first.
To set the digital time and date
Crown
Seconds
Operation Guide 3318
A spacer is inserted under the crown at the factory to keep
the watch in a Power Saving Mode, which conserves
battery power. Remove the spacer as shown in the
illustration to the left before using the watch.
• Power Saving is turned on while the crown of the watch
is pulled out.
• Perform the following steps before using the watch for
the first time. If the battery power indicator shows
(Level 3) or if the digital display is totally blank (Level 4),
expose the watch to light until the battery power
indicator changes to (Level 2) or (Level 1) before
performing the following operations.
1. Press any button to exit the Power Saving Mode
and display the digital time setting screen.
2. Set the digital time.
3. Set the analog time.
• See "Power Saving" for more information about the
Power Saving feature and how to use it.
• Button operations are indicated using the letters shown
in the illustration.
• For the sake of simplicity, the sample displays in this
manual do not show the analog hands of the watch.
• Each section of this manual provides you with the
information you need to perform operations in each
mode. Further details and technical information can be
found in the "Reference" section.
Time Setting Mode Power Saving Mode
No operation
for two or three
minutes
Press any
button.
1. Pull out the crown so the seconds digits are flashing.
This is the Time Setting Mode.
• The analog hands stop moving when the setting
screen is displayed.
• If the watch is in the Power Saving Mode and the
crown is already pulled out, first press any button to
exit the Power Saving Mode. This will display the
setting screen.
2. Use B to move the flashing in the sequence shown
below to select other settings.
12/24-Hour
Hour Minutes
Format
Illumination
Language Day
Duration
3. When the setting you want to change is flashing, use A to change it as described
below.
Screen To do this:
:35 Reset the seconds to
P10:08 Change the hour or minutes
12 H
Toggle between 12-hour (
timekeeping
2004
Change the year
6-30
Change the month or day
Toggle the illumination duration setting between one
second (
EN6
Change the day of the week language setting
• See "Day of the Week Languages" for more information.
• Holding down A changes the setting at high speed.
4. Adjust the analog time.
5. After adjusting the digital and analog times, push in the crown to exit the Time
Setting Mode.
• For more information about illumination duration, see "Illumination".
• The default illumination duration setting is one second when you purchase the
watch and any time after battery power drops to Level 4.
• If you do not perform any button operation for two or three minutes while the setting
screen is on the display, the watch automatically enters the Power Saving Mode.
Day of the Week Languages
You can select one of six different languages (English, Spanish, French, German,
Italian, Russian) for display of the day of the week.
• The default day of the week language when you purchase the watch or after battery
power drops to level 4 is English.
• See the "Day of the Week List" for information about how days of the week are
displayed in each language.
To change the day of the week language setting
Language
Language Setting
Screen
Setting the Analog Time
Perform the procedure below when the time indicated by the analog hands does not
match the time of the digital display.
• When (Level 3) is indicated for the battery power level, the second hand moves at
2-second intervals. For details, see "Battery Power Indicator and Recover Indicator".
To adjust the analog time
Hour hand Minute hand
Second hand
Timekeeping
• In the Timekeeping Mode, pressing B cycles through available screen formats as
shown below.
Calender
Day of week
To check the current day of the week language setting and illumination duration
setting
In the Timekeeping Mode, hold down B. This will display a screen like the one shown
below, which shows indicators for the current day of the week language setting and
the illumination duration setting.
• See the "Day of the Week List" for the meaning of each indicator.
• The current illumination duration is indicated as
Year
Month
00
1 2H ) and 24-hour ( 24H )
x ) and three seconds ( )
1. Pull out the crown so the seconds digits are flashing.
This is the Time Setting Mode.
• The analog hands stop moving when the setting
screen is displayed.
2. Press B eight times to display the language setting
screen.
3. Press A to cycle through the language settings in the
following sequence.
Crown
(English) (Spanish)
(Russian) (Italian)
4. Adjust the analog time.
5. After adjusting the analog time, push in the crown to
exit the Time Setting Mode.
1. Pull out the crown so the seconds digits are flashing.
This is the Time Setting Mode.
• The analog hands stop moving when the setting
screen is displayed.
2. Rotate the crown to advance the minute hand to the
setting you want. Move the minute hand so it is four or
five minutes past the point where you will finally set it,
and then rotate the crown in the opposite direction to
move the minute hand back to the setting you want.
3. Press the crown back in when the seconds count on
the digital display matches the current location of the
analog second hand.
• This re-starts analog timekeeping and returns to the
Crown
Timekeeping Mode.
Current Time
Hour : Minutes
Press .
Day PM indicator
x (one second) or (three seconds).
Language
Illumination duration
Do this:
Press A.
Use A (+).
Press A.
Use A (+).
Press A.
(French)
(German)
Battery Power Indicator
and Seconds Count
Battery power indicator
Seconds
