- Page 1 Pedelec Operating Instructions Pedelec handleiding Pédélec manuel...
-
Page 2: Introduction
Legal provisions Your Pedelec has a maximum rated continuous power of 250 W and therefore qualifies as a bicycle according to European Standard. In Germany and most other EU countries, Pedelecs are approved for use without minimum age requirement, safety helmet or insurance registration. -
Page 3: Table Of Contents
Introduction Table of contents General diagram Charging the battery Operation and control Assistance mode / range Technical data Care and maintenance Troubleshooting Guarantee / general notes Contents 5 - 6 9 - 12... -
Page 4: General Diagram
Pedelec General Diagram Pedelec General Diagram 1. Operating unit 2. Motor unit with power sensor on bottom bracket 3. Battery 4. Battery lock 5. Charging unit... -
Page 5: Charging The Battery
Charging the Battery Charging the Battery Before using it for the first time, the battery must be charged for at least four hours. When deli- vered, the battery is in the uncharged state and is in sleeping mode. The battery can be charged in any state i.e. at any charge level. Removing the battery To charge the battery, it first has to be removed from the cycle. - Page 6 Charging the Battery Note: 1. The length of the charging process depends on the capacity and the level of the charge. 2. Charge the battery at room temperature only. As soon as the ambient temperature of the battery is less than 0° or more than 40° the battery cannot be charged and the charging unit remains in standby mode.
-
Page 7: Operation And Control
you have pressed the Power button, ensure that the battery is correctly mounted and charged. Cycling When force is applied to the pedals the system becomes active and motor assistance is available. The magnetic torque sensor measures your force and automatically controls the level of motor assistance according to your prior assistance setting. The amount of pedalling force you require is reduced by between 60 and 30% depending on the mode selected. -
Page 8: Assistance Mode, Range
Assistance Mode, Range Selecting degree of assistance With the Mode button on the operating unit you can select one of three different assistance modes at any time. Press the Mode button until you arrive at the mode you require. Maximum assistance Standard Minimum assistance The best amount of assistance and the consequent range of the battery depend on a number of factors which are best determined by trial and... -
Page 9: Technical Data
Motor Bottom-bracket motor Brushless DC motor Power output: 250 W Weight: approx. 3.5 kg Control by means of frictionless magnetic torque sensor Overload When the motor is overloaded, the LEDs on the operating unit flash in the following pattern Flashing LEDs Flash interval: one space equals 0.5 sec One mode diode Overheating... - Page 10 Technical Data Battery Battery power: 260 Wh, 26 V 10 Ah, removable and rechargeable Type: Panasonic lithium, ions, manganese Model: Li-ion battery Ni-Li NKY224B01 10 Ah Charging time: approx. 3 h., initial charge 4 h. Weight: 2.4 kg Accumulator status At the side of the battery there is a display which indicates the charge status and the capacity of the battery.
- Page 11 Battery Sleeping Mode In its original state and at the first start-up the battery is in sleeping mode. For this reason the battery has to be fully charged before it is used for the first time. If the charge level drops below 50% and it is not charged for more than two weeks, it goes into sleeping mode automatically. The sleeping mode prevents total discharge.
-
Page 12: Technical Data
Technical Data Charging Unit The charging unit type NKJ38 is supplied with the cycle. Weight of charging unit: 530 g Power supply: 220 V (50 Hz) AC Power: 62 W A charging unit is supplied with the cycle. To charge it, take the unit out of the box and remove the plastic foil. Failure to remove the foil may cause damage to the unit through overheating. -
Page 13: Care And Maintenance
Care and Maintenance Inspection Follow the instructions in the enclosed KETTLER Instructions for Assembly and Operation Tyre Pressure The tyre pressure has an important influence on the performance of the Pedelec. To ensure that the range of the battery is not affected, ensure that the tyre pressure is always between 3 and 4 bar. -
Page 14: Troubleshooting
Do not attempt to repair the electric drive system, control system or battery. For any necessary service or repair work, always contact your KETTLER dealer who has the necessary information and expertise to carry out repairs. Reset: Errors in the sensor torque measurement... -
Page 15: Guarantee / General Notes
Batteries are subject to wear and tear. It is therefore normal for the capacity of the battery to decline with increasing age, use, and frequency of charging. For other guarantee provisions, please refer to the KETTLER Instructions for Assembly and Operation. Ground clearance Because of the position of the motor unit, the clearance between the lowest point of the frame and the ground in the area of the bottom bracket is about 5 cm less than for a standard cycle.
