Summary of Contents for Amphony 300 BlueFIDELITY
Page 1
Connect the AC adapter with the amplifier BEFORE plugging the AC adapter into an outlet to avoid spark generation! User and Installation Guide BlueFIDELITY Bluetooth Audio Amplifier Model 300...
Page 2
Contents Unpacking ................3 Connecting in Stereo configuration ........4 Connecting on Mono configuration ........6 Technical specifications ............8 Safety information ..............9 Your warranty ..............11...
Page 3
User and Installation Guide Unpacking: Check that this package contains: - one Bluetooth audio amplifier - one large AC adapter (wallwart) - one antenna Thank you for purchasing this high-quality Bluetooth audio amplifier product. This amplifier allows you to wirelessly stream audio from any Bluetooth enabled device to your speakers.
Page 4
User and Installation Guide Attaching the antenna Antenna The antenna can swivel to other angles. Turn the cap clockwise to fasten the antenna Page 4...
Page 5
User and Installation Guide Observe the correct cable polarity when connecting the speakers. Amplifier Speakers Page 5...
Page 6
User and Installation Guide Connecting the AC adapter Bluetooth Amplifier 36 V Status Outlet ATTENTION ! Connect the AC adapter with the amplifier DC 36 V BEFORE plugging the AC adapter into an outlet to avoid spark generation! AC adapter Page 6...
Page 7
User and Installation Guide Pairing and Connecting The Bluetooth amplifier must be paired with your Bluetooth-enabled device in order to be able to stream audio. To pair the amplifier, power up the amplifier. Then go to the wireless settings of your Bluetooth device and select "Scan for Bluetooth devices".
User and Installation Guide Technical Specifications Output power: 2 x 40 W (rms) Wireless range: max. 100 ft line of sight (the actual range depends on the Bluetooth-enabled device) Frequency response: 20 Hz - 20 kHz Dynamic range: typ. 95 dBA Total harmonic distortion (THD+N): 0.04 % @ 20 W, 1 kHz Supported Bluetooth Profiles: A2DP, AVRCP...
User and Installation Guide READ THESE SAFETY INSTRUCTIONS CAREFULLY AND HEED ALL WARNINGS IN THIS MANUAL. POWER SOURCE To avoid product malfunction, and to protect against electric shock, fire or personal injury, please observe the following: • This product has been designed to work with 120-volt AC current using the supplied AC adapters.
• Do not attempt to service the unit yourself. • Please refer any service to an authorized Amphony service center. Copyright (C) 2014 Amphony. All rights reserved. The information contained herein is subject to change without notice.
WHAT YOUR WARRANTY COVERS This warranty extends only to the original user of the equipment (“you”, ”your”) and is limited to the purchase price of each part. Amphony and its affiliated companies (”we”, ”our”, ”us”) warrant this Amplifier against defects in materials or workmanship as follows.
LEGAL LIMITATIONS REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY. WE SHALL NOT BE HELD LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESSED OR IMPLIED WARRANTY ON THIS EQUIPMENT, NOR FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF, OR INABILITY TO USE, THIS EQUIPMENT.
