- Page 1 Connect the AC adapter with the amplifier BEFORE plugging the AC adapter into an outlet to avoid spark generation! User and Installation Guide microFIDELITY Digital Audio Amplifier Model 200...
-
Page 2: Table Of Contents
Contents Unpacking ................3 Connecting in Stereo configuration ........4 Connecting on Mono configuration ........6 Technical specifications ............8 Safety information ..............9 Your warranty ..............11... -
Page 3: Unpacking
User and Installation Guide Unpacking: Check that this package contains: - one digital audio amplifier - Model 200 - one large AC adapter (wallwart) Thank you for purchasing this high-quality digital audio amplifier product. This amplifier contains advanced audio amplification technology which provides the audio quality of analog amplifiers at a superior signal-to-noise ratio and low audio distortion while at the same time offering extremely small size and high power efficiency. -
Page 4: Connecting In Stereo Configuration
User and Installation Guide Connecting in Stereo configuration Set Mono/Stereo switch to Stereo Digit l Amplif Model 200 36 V M / S L / M Amplifier Outlet DC 36 V 1000 mA LINE Audio Source AC adapter Page 4... - Page 5 User and Installation Guide Observe the correct cable polarity when connecting the speakers. Amplifier Speakers Page 5...
-
Page 6: Connecting On Mono Configuration
User and Installation Guide Connecting in Mono configuration Set Mono/Stereo switch to Mono Digit l Amplif Model 200 36 V M / S L / M Amplifier Outlet DC 36 V 1000 mA LINE Audio Source AC adapter Page 6... - Page 7 User and Installation Guide ATTENTION! Never short circuit any amplifier speaker output since this may damage the amplifier! Amplifier Speaker Page 7...
-
Page 8: Technical Specifications
User and Installation Guide Technical Specifications Output power: Mono: 1 x 150 W (peak), 1 x 80 W (rms) Stereo: 2 x 40 W (rms) Dynamic range / signal-to-noise ratio: Mono: 115 dBA Stereo: 112 dBA Frequency response: 1 Hz - 70 kHz @ 8 Ohms Total harmonic distortion (THD+N): Mono: 0.04 % @ 50 W, 1 kHz Stereo: 0.04 % @ 20 W, 1 kHz... -
Page 9: Safety Information
User and Installation Guide READ THESE SAFETY INSTRUCTIONS CAREFULLY AND HEED ALL WARNINGS IN THIS MANUAL. POWER SOURCE To avoid product malfunction, and to protect against electric shock, fire or personal injury, please observe the following: • This product has been designed to work with 120-volt AC current using the supplied AC adapters. - Page 10 • Do not attempt to service the unit yourself. • Please refer any service to an authorized Amphony service center. Copyright (C) 2010 Amphony. All rights reserved. The information contained herein is subject to change without notice.
-
Page 11: Your Warranty
WHAT YOUR WARRANTY COVERS This warranty extends only to the original user of the equipment (“you”, ”your”) and is limited to the purchase price of each part. Amphony and its affiliated companies (”we”, ”our”, ”us”) warrant this Amplifier against defects in materials or workmanship as follows. - Page 12 LEGAL LIMITATIONS REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR EXCLUSIVE REMEDY. WE SHALL NOT BE HELD LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESSED OR IMPLIED WARRANTY ON THIS EQUIPMENT, NOR FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF, OR INABILITY TO USE, THIS EQUIPMENT.
