TP-Link TD-W8951ND Quick Installation Manual page 2

Plug the provided Power Adapter
into the Power jack on the back of
the Router and the other end to a
standard electrical wall socket.
Power on all your network devices and then check to see if the LEDs of the
Router display normally as the diagram below describes.
Power: Solid light
ADSL: Solid light or flashing
WLAN: Solid light or flashing
LAN: Solid light if the corresponding
port is connected
If the LEDs display abnormally, please check to see if all the cable
Note
connectors (power adapter, phone line and Ethernet cable) are well
connected to your device. With the phone line well connected, if the ADSL
LED turns off after flashing, please contact your ISP to ensure that you r
internet connection is active.
2
