Page 1: Instruction Manual
KDC-DAB34U KDC-DAB361U CD-RECEIVER INSTRUCTION MANUAL AMPLI-TUNER LECTEUR DE CD MODE D’EMPLOI CD-RECEIVER BEDIENUNGSANLEITUNG CD RECEIVER GEBRUIKSAANWIJZING SINTOLETTORE STEREO COMPACT DISC ISTRUZIONI PER L’USO REPRODUCTOR DE DISCOS COMPACTOS RECEPTOR DE FM/AM MANUAL DE INSTRUCCIONES © 2013 JVC KENWOOD Corporation GET0976-001A (EN) - Page 2 Entsorgung von gebrauchten elektrischen und elektronischen Geräten und Batterien (anzuwenden in den Ländern der Europäischen Union und anderen europäischen Ländern mit einem separaten Sammelsystem für solche Geräte) Das Symbol (durchgestrichene Mülltonne) auf dem Produkt oder seiner Verpackung weist darauf hin, dass dieses Produkt nicht als normaler Haushaltsabfall behandelt werden darf, sondern an einer Annahmestelle für das Recycling von elektrischen und elektronischen Geräten und batterien abgegeben werden muss.
- Page 3 Informazioni sullo smaltimento delle vecchie apparecchiature elettriche ed For Israel elettroniche e delle batterie (valide per i Paesi Europei che hanno adottato sistemi di raccolta differenziata) I prodotti e le batterie recanti il simbolo di un cassonetto della spazzatura su ruote barrato non possono essere smaltiti insieme ai normali rifiuti di casa.
- Page 4 Conformiteitsverklaring met betrekking tot de RoHS richtlijn van de Europese Unie (2011/65/EU) Declaration of Conformity with regard to the EMC Directive 2004/108/EC Fabrikant: Declaration of Conformity with regard to the RoHS Directive 2011/65/EU JVC KENWOOD Corporation Manufacturer: 3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, Japan JVC KENWOOD Corporation EU-vertegenwoordiger: 3-12, Moriya-cho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, Japan JVCKENWOOD NEDERLAND B.V.
- Page 5 The marking of products using lasers The label is attached to the chassis/case and says that the component uses laser beams that have been classified as Class 1. It means that the unit is utilizing laser beams that are of a weaker class.
-
Page 6: Table Of Contents
CONTENTS BEFORE USE Warning BEFORE USE Do not operate any function that takes your attention away from safe driving. BASICS Caution Volume setting: GETTING STARTED • Adjust the volume so that you can hear sounds outside the car to prevent accidents. •... -
Page 7: Basics
BASICS Faceplate Attach How to reset Volume knob (turn/press) Loading slot Display window Your preset adjustments Detach will also be erased. Detach button Do this (on the faceplate) Press B SRC. Turn on the power • Press and hold to turn off the power. Adjust the volume Turn the volume knob. -
Page 8: Getting Started
GETTING STARTED While in clock display screen... Press and hold DISP SCRL to enter clock adjustment mode directly. Then, perform step to set the clock. Set the initial settings Press B SRC to enter STANDBY. Select the display language and cancel the demonstration Press the volume knob to enter [FUNCTION]. -
Page 9: Digital Radio (Dab)
Press and hold S / T to search for an ensemble. F/W UP Vxxx For details on how to update the firmware, see: www.kenwood.com/cs/ce/ Press S / T to select an ensemble, service or component to listen. ENGLISH |... - Page 10 DIGITAL RADIO (DAB) • To change the tuning method for S / T: Press K SEEK repeatedly. Default: XX Press S / T: Select an ensemble, service or component. AUTO1: TUNER SETTING Press and hold S / T: Automatically search for an AF SET ensemble.
-
Page 11: Analog Radio
ANALOG RADIO DIGITAL RADIO (DAB) CLOCK TIME SYNC ON: Synchronizes the unit’s time to the Digital Radio signal station time. ; OFF: Cancels. • Available Program Type: SPEECH: NEWS, AFFAIRS, INFO (information), SPORT, EDUCATE, DRAMA, CULTURE, SCIENCE, VARIED, WEATHER, FINANCE, CHILDREN, SOCIAL, RELIGION, PHONE IN, TRAVEL, LEISURE, DOCUMENT MUSIC: POP M (music), ROCK M (music), EASY M (music), LIGHT M (music), Search for a station... -
Page 12: Cd / Usb / Ipod
CD / USB / iPod ANALOG RADIO Default: XX Start playback TUNER SETTING The source changes automatically and playback starts. LOCAL SEEK ON: Searches only FM stations with good reception. ; OFF: Cancels. AUTO MEMORY YES: Automatically starts memorizing 6 stations with good reception. ; NO: Cancels. (Selectable only if [NORMAL] is selected for [PRESET TYPE].) ( 5) Eject disc Label side... - Page 13 • MP3/WMA/WAV file or iPod: FILE REPEAT, FOLDER REPEAT, • To cancel, press and hold REPEAT OFF • KENWOOD Music Editor Light (KME Light)/ KENWOOD Music If you have many files..Control (KMC) file ( 12): FILE REPEAT, REPEAT OFF You can search through them quickly (on step Random play * Press 3 ...
-
Page 14: Aux
CD / USB / iPod Preparation: Select a song by name Set the skip search ratio Select [ON] for [BUILT-IN AUX]. ( 5) While listening to iPod... While listening to iPod or KME Light/ KMC file... Start listening Press Press the volume knob to enter [FUNCTION]. Turn the volume knob to select a Turn the volume knob to select [USB], then Connect a portable audio player... -
Page 15: Audio Settings
AUDIO SETTINGS While listening to any source... PRESET EQ DRIVE EQ/ TOP40/ POWERFUL/ ROCK/ POPS/ EASY/ JAZZ/ Press the volume knob to enter [FUNCTION]. NATURAL/ USER: Selects a preset equalizer suitable to the music Turn the volume knob to select [AUDIO CONTROL], then press the genre. -
Page 16: Display Settings
• Discs with coloring on the recording surface or discs that the detailed color adjustment. • You cannot operate iPod if “KENWOOD” or “ ” is are dirty. 2 Press S / T to select the color (R/ G/ displayed on iPod. -
Page 17: Troubleshooting
TROUBLESHOOTING Symptom Remedy Symptom Remedy Sound cannot be heard. • Adjust the volume to the optimum level. “READ ERROR” appears. Copy the files and folders onto the USB device again. If this • Check the cords and connections. does not solve the problem, reset the USB device or use another USB device. - Page 18 Warning Installing the unit (in-dash mounting) • The unit can only be used with a 12 V DC power supply, negative ground. • Disconnect the battery’s negative terminal before wiring and mounting. • Do not connect Battery wire (yellow) and Ignition wire (red) to the car chassis or Ground wire (black) to prevent a short circuit.
-
Page 19: Installation
: Ignition (ACC) Brown or during conversation. (To A8 Black : Earth (ground) connection (Mute control wire) MUTE connect the Kenwood navigation B1 Purple ] : Rear speaker (right) system, consult your navigation B2 Purple/black [ manual.) B3 Gray ]... - Page 20 Determine the antenna installation position KDC-DAB34U : Connect the supplied DAB antenna. • The direction of the film antenna (F) changes depending on whether the film antenna (F) is installed on the KDC-DAB361U : Connect CX-DAB1 (optional accessory). right side or left side. Caution •...
- Page 21 Installation overview – Wait until the glass surface is completely Caution dry before proceeding. The antenna should be installed on the passenger side for When installing the antenna cable inside – Warm the surface of the windscreen with safety. the front pillar with the air bag installed defroster if it is cold (during winter).
- Page 22 Remove the application film (tag III). • When installing the antenna on the left side Application film (tag III) Do not touch the lead terminal of film Earth sheet antenna (F). Set the position of the protrusion Set the postion of the protrusion of the with J mark amplifier unit (G) with the K on the film antenna (F) and paste.
