- Page 1 CD-RECEIVER KDC-3047 KDC-3047GY KDC-3047M KDC-3247 KDC-3347 KDC-314 INSTRUCTION MANUAL © B64-4591-00/00 (EW/E2W/E0/E20/M20/M20)
-
Page 2: Table Of Contents
Direct Music Search Tuner Operation PTY (Program Type) Program Type preset Changing Language for PTY Function Basic Operations of Remote Control 14 Appendix Accessories/Installation Procedure 16 Connecting Wires to Terminals Installation/Removing the Unit Troubleshooting Guide Specifications KDC-3047/ KDC-3047GY/ KDC-3047M/ KDC-3247/ KDC-3347/ KDC-314... -
Page 3: Before Use
• When you purchase optional accessories, check with When using this unit for the first time, cancel your Kenwood dealer to make sure that they work the Demonstration mode. Refer to <Exit of the with your model and in your area. -
Page 4: Basic Operations
⁄ Auxiliary input • You can do this adjustment when “TIME SYNC” in <Function Portable audio device can be connected with the Setting> (page 8) is set to “OFF”. stereo mini-plug (3.5 mm ø). KDC-3047/ KDC-3047GY/ KDC-3047M/ KDC-3247/ KDC-3347/ KDC-314... -
Page 5: Playing Music
Playing Music Listening Radio Playing Disc Select Tuner source Insert a disc into the disc slot. Pressing the [SRC] button several times switches When inserted, the source is switched the source to “TUNER”. automatically and a song starts playing. Band select Folder select Pressing the [BAND] button switches the Pressing the [BAND] button switches a folder. -
Page 6: General
• Keep the faceplate in its faceplate case while detached. • Do not place the faceplate (and the faceplate case) in areas exposed to direct sunlight, excessive heat or humidity. Also avoid places with too much dust or the possibility of water splashing. KDC-3047/ KDC-3047GY/ KDC-3047M/ KDC-3247/ KDC-3347/ KDC-314... -
Page 7: Display Indicator
Display Indicator Text Display Selection Changes displayed information on each source following; In Tuner source Information Display Program Service name (FM) “FREQ/PS” 1 “ST“ indicator: Lights when a stereo broadcast is Radio text (FM) “RADIO TEXT” received. Frequency (MW, LW) “FREQUENCY”... -
Page 8: Function Setting
Traffic Information. adjusting. Å Alternative Frequency: “AF SET” ➤ “ON”*,”OFF” ⁄ When the reception is poor, automatically • You can do this adjustment when “TIME SYNC” is set to alternate to another frequency broadcasting the KDC-3047/ KDC-3047GY/ KDC-3047M/ KDC-3247/ KDC-3347/ KDC-314... -
Page 9: Initial Set
20M: Turns the power OFF after 20 minutes. 40M: Turns the power OFF after 40 minutes. • For how to update the firmware, access our web site. 60M: Turns the power OFF after 60 minutes. http://www.kenwood.com/cs/ce/ Ò Built in AUX: “BUILTIN AUX” ➤ “ON1”*,”ON2”,”OFF” <DEMO MODE>... -
Page 10: Audio Control
The effect is negligible with music that is encoded “TEXT SCROLL” [ at high bit rate, variable bit rate or has minimal “DEMO MODE” ß high frequency range. Can be set while Audio file source of CD. KDC-3047/ KDC-3047GY/ KDC-3047M/ KDC-3247/ KDC-3347/ KDC-314... - Page 11 Function items appearing when the CD & audio file source is selected “SUB-W SET” ∂ “AUDIO CTRL” “BASS BOOST” ƒ “SYSTEM Q” © “BASS LEVEL” ˙ “MID LEVEL” Δ “TRE LEVEL” ˚ “BALANCE” ¬ “FADER” … “SUB-W LEVEL” ' “LPF SUB-W” æ “DETAIL SET”...
-
Page 12: Music Disc/Audio File Operation
Return to previous folder Press the [ ] button. Return to root folder Press the [BAND] button. “<” or “>” beside the displayed folder name indicates that this folder is preceded or followed by another folder. KDC-3047/ KDC-3047GY/ KDC-3047M/ KDC-3247/ KDC-3347/ KDC-314... -
Page 13: Tuner Operation
Tuner Operation PTY (Program Type) Program Type preset Selecting the Program Type below and searching Putting the Program Type in the Preset button for a station; memory and quick recall. Program Type Display Program Type Display Presetting the Program Type Speech “SPEECH”... -
Page 14: Basic Operations Of Remote Control
• Keep battery out of reach of children and in original package until ready to use. Dispose of used batteries promptly. If swallowed contact physician immediately. KDC-3047/ KDC-3047GY/ KDC-3047M/ KDC-3247/ KDC-3347/ KDC-314... -
Page 15: Appendix
An online manual about audio files is put on the site, The marking of products using lasers www.kenwood.com/cs/ce/audiofile/. On this online (Except for some areas) manual, detailed information and notes which are not written in this manual are provided. Make sure to read through the online manual as well. -
Page 16: Accessories/Installation Procedure
(i.e., it will not turn on and off along with the ignition). If you want to link the unit’s power KDC-3047/ KDC-3047GY/ KDC-3047M/ KDC-3247/ KDC-3347/ KDC-314... -
Page 17: Connecting Wires To Terminals
Connect to the terminal that is grounded when MUTE either the telephone rings or during conversation. ⁄ To connect the Kenwood navigation system, consult your navigation manual. If no connections are made, do not let the wire come out from the tab. - Page 18 2 The A-7 pin (red) of the vehicle’s ISO connector is connected to the constant power supply, and the A-4 pin (yellow) is linked to the ignition. Ignition cable A-7 Pin (Red) (Red) Unit Vehicle Battery cable A-4 Pin (Yellow) (Yellow) KDC-3047/ KDC-3047GY/ KDC-3047M/ KDC-3247/ KDC-3347/ KDC-314...
-
Page 19: Installation/Removing The Unit
Installation/Removing the Unit Installation Removing the Hard Rubber Frame Engage the catch pins on the removal tool and remove the two locks on the upper level. Upper the frame and pull it forward as shown in the figure. Lock Catch Bend the tabs of the mounting sleeve with a screwdriver or similar utensil and attach it in place. -
Page 20: Troubleshooting Guide
✔ The media is scratched or dirty. ☞ Clean the media, referring to the CD cleaning of the section on <Handling CDs> (page 3). ✔ The recording condition is bad. ☞ Record the media again or use another media. KDC-3047/ KDC-3047GY/ KDC-3047M/ KDC-3247/ KDC-3347/ KDC-314... - Page 21 The messages shown below display your systems condition. TOC ERROR: The CD is quite dirty. The CD is upside-down. The CD is scratched a lot. ERROR 05: The disc is unreadable. ERROR 99: The unit is malfunctioning for some reason. ➪...
-
Page 22: Specifications
