- Page 1 DC MP3 Digital Audio Player (USB 2.0) User Guide Version 1.1...
- Page 2 Table of Contents Notice Operation Buttons, Package Includes, Power On & Off, Minimum System Requirements LCD Information, Menu Functions Music Operation, Voice Operation FM Operation System Settings, Setting Equalizer Setting Repeat Mode, Setting Different Folder, Setting A-B Clipping Firmware Upgrade, Disk Protection Connecting Player to Computer, Troubleshooting Guide Technical Specifications Notice...
- Page 3 Operation Buttons Hold Volume + Menu Left/Prev/REW Play/Pause/ Volume - Right/ Next/FF Power On/Off Package Includes Installation CD, USB Cable, Earphone, User Guide, AAA Battery Power On & Off To power on/off the player, press and hold Play/Pause. Minimum System Requirements •...
-
Page 4: Lcd Information
LCD Information Playback Equalizer Playback Duration Music Battery Level Format ID3 Tag (Song Information) LRC file indicator Current Total Track Track Number Number Menu Functions 1. Press Menu to navigate different mode. Press and hold Menu to go back Main Menu. 2. -
Page 5: Music Operation
8. Choose Setting to enter player configuration menu. You can set Record Time, Backlight, Light Color, Language, Power Off, Replay Mode, Contrast, Online Mode, Memory Info, Firmware Version, Firmware Upgrade or Return to Main Menu. 9. On the player, there’s a HOLD switch. Once you have set it, all the buttons on the player will be inactive. - Page 6 a. Full Directory - Current folder has 99 recording files. Use another folder for recording. b. Full Space - Player memory is full. Please delete other files to free some space. Icon ” ” indicates the current recording format and recording bit rate. “00:00:00”...
- Page 7 Playing Recorded File 1. From Main Menu, navigate to Voice mode. 2. Press Play/Pause to play or stop the audio file. 3. If there is no recorded audio files you will see No files! 4. While the recorded file is paused, you can change the current active folder for recording or you can also delete the recorded audio.
-
Page 8: Setting Equalizer
Delete FM Channel Press Menu, navigate to Delete or Delete All. Note: By default, the FM tuning frequency is Normal Band from 87MHz – 108Mhz. Japan Band will be from 76MHz – 90MHz. System Settings 1. From Main Menu, navigate to Setting mode. 2. -
Page 9: Setting A-B Clipping
3. Choose Natural, Rock, Pop, Classic, Soft, Jazz or DBB equalizer by pressing Menu. Setting Repeat Mode 1. While playing music, press Menu. 2. Navigate to Repeat mode using Left/Right. Below are the descriptions. Normal: All music files will play sequentially once. Repeat One: Repeat current file continuously. -
Page 10: Firmware Upgrade
3. While repeating, if you would like to record your voice and see if it matches with the A-B segment, press Right again. You will notice a microphone will appear replacing A-B icon. Once you have recorded your voice, press Right to listen to A-B segment and your recorded voice. 4. - Page 11 2. Do not lose the username and password you have input, otherwise you to merge disks, repeat Disk Protection procedures again but set to 0MB for Setting Encrypted Disk Capacity. Connecting Player to Computer 1. Connect the USB port of the player to the computer using the USB cable provided. 2.
- Page 12 Technical Specifications Built-In Memory Up to 2GB Battery 1xAAA Alkaline or Ni-MH LCD Resolution 128x32 pixels Signal Noise Ratio >90dB Earphone output 10mW+10mW Music Format MP3, WMA, WAV Record Format 2.0 Full-Speed (Up to 12Mbps) Created on 10 March 2006. DC MP3 Digital Audio Player. Please visit us at www.shirocorp.com.
- Page 13 LIMITATION OF LIABILITY AND DAMAGES. IN NO EVENT WILL MANUFACTURER AND MANUFACTURER’S RESELLERS (COLLECTIVELY REFERRED TO AS “THE SELLERS”) BE LIABLE FOR DAMAGES OR LOSS, INCLUDING BUT NOT LIMITED TO DIRECT, INDIRECT, SPECIAL WILLFUL, PUNITIVE, INCIDENTAL, EXEMPLARY, OR CONSEQUENTIAL, DAMAGES, DAMAGES FOR LOSS OF BUSINESS PROFITS, OR DAMAGES FOR LOSS OF BUSINESS OF ANY CUSTOMER OR ANY THIRD PARTY ARISING OUT OF THE USE OR THE INABILITY TO USE THE PRODUCT OR THE SOFTWARES, INCLUDING BUT NOT LIMITED TO THOSE RESULTING FROM DEFECTS IN THE PRODUCT OR SOFTWARE OR DOCUMENTATION, OR LOSS OR INACCURACY OF DATA OF ANY KIND, WHETHER BASED ON CONTRACT, TORT...
