Shiro SX User Manual

Mp3 digital audio player (usb 2.0)
Hide thumbs Also See for SX:
Table of Contents

Advertisement

Quick Links

Download this manual
SX MP3 Digital Audio
Player (USB 2.0)
User Guide
Version 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shiro SX

Summary of Contents for Shiro SX

  • Page 1 SX MP3 Digital Audio Player (USB 2.0) User Guide Version 1.1...

  • Page 2: Table Of Contents

    Table of Contents Notice Operation Buttons Package Includes LCD Information Power On & Off Playing Music Menu Functions Recording Operation Playing Recorded File Recording Setting FM Function Deleting File Setting Equalizer Setting Repeat Mode Setting Auto Shut Down Setting Different Language (Optional) Setting A-B Clipping Viewing Player Information Connecting Player to Computer...

  • Page 3: Notice

    Notice If the player is not used for a long duration, please remove the battery to avoid battery leakage. Do not use the player in extreme hot, cold, dusty or wet environment. Unlock the lock switch before using the player. Do not drop the player from great heights.

  • Page 4: Package Includes

    A – B/Rec Button Package Includes • Installation CD • USB Cable • Earphone • User Guide • AAA Battery For desktop PC or laptop using USB 1.1 interface, data transfer rate would be up to a maximum of 12Mbps in accordance with the standard. Equalizer Button Insert the SD/MMC Card according to the orientation shown Connect the USB cable from here to the Computer USB port...

  • Page 5: Lcd Information

    LCD Information Current Mode Current Music/Total Music Playing Time Singer Detail The loop mode includes Repeat Track, Repeat All, Shuffle, Shuffle Repeat, Normal mode. Loop Mode Equalizer Volume File Name Hold/Locked Battery A-B Clipping...

  • Page 6: Power On & Off

    Power On & Off To power on the player, please press the Play/Pause button. After 2 seconds, you will see the word Power On appearing. To power off the player, please press and hold the Play/Pause button until all the indication on the LCD disappears.

  • Page 7: Menu Functions

    When you press Play/Pause button again, the player will either play or pause the song. It will show you the current number song played/total number of songs and playing time. If you would like to choose to the next or previous song, press the Left/Right (FF/REW) button.
  • Page 8 Choose Music will go to Music mode. This is the mode where you can enjoy your MP3/WMA/WAV songs. Choose Voice will go to voice mode, this is the mode where you can record voice (press and hold the A-B button) or listen to your recorded audio file in WAV format. Choose FM Tuner to enter radio mode.
  • Page 9 Choose Delete File to enter delete mode. You can delete music or audio files. 10. Click Information to enter the player information interface. You can know the available and total memory storage available. The firmware version will also be displayed.

  • Page 10: Recording Operation

    Recording Operation Check that you have set the Source to Voice under Setting > Record Setting. There are 2 ways to begin recording. Recording by pressing and holding the A-B/Rec button for about 2 seconds. The player LCD will show the current recorded time and the present file name. You can press Play/Pause button to stop recording.

  • Page 11: Playing Recorded File

    Playing Recorded File Turn on the player. Press Menu button and navigate to Voice (WAV) / Music (MP3) mode using Left/Right button. Press Menu button again to enter. To play or stop the audio file, press Play/Pause button. You can navigate if there is more than 1 audio file using Left/Right button.
  • Page 12 Press Left/Right button to navigate to Setting mode. Press Menu button to enter. Press Left/Right button to navigate to Rec Setting mode. Press Menu button to enter Rec Setting Menu as shown below. You can set Source, Encoding Format, Quality of Recording, Storage or Exit Menu. Press Left/Right button to navigate across these items.

  • Page 13: Fm Function

    FM Function To adjust station frequency. Press Play/Pause button to power up the player. Press the Menu button to enter Main Menu. Navigate to FM mode using Left/Right button and press Menu button to enter. You will enter Preset mode. This mode has 20 fixed channel. When you first enter FM mode, the player will automatically search for the channel that is available for listening.

  • Page 14: Deleting File

    To record current channel you are listening to, press and hold A-B button. You will see the following screen. The FM channel will be recorded into the player. Press Play/Pause button to stop recording. 10. Press Menu button to quit FM mode and return to Voice (WAV) / Music (MP3) Mode. Deleting File You can also delete the files stored in the player.

  • Page 15: Setting Equalizer

    If you do not want to delete the current file, you can choose No by using the Left/Right button. Press Menu button. If you want to delete the file, choose Yes option follow by Menu button. After file deletion is successful, the player will go back to the Delete mode automatically, you can continue to delete the remaining files.

  • Page 16: Setting Repeat Mode

    If you do not want to change the current settings, choose Return to quit the menu. After finish setting up Equalizer, the EQ mode name will be shown on the playing interface. To exit Setting mode, press and hold Menu button to go to Music mode. Note: While listening, you can also press the EQ mode on the player to change the equalizer directly.

  • Page 17: Setting Auto Shut Down

    You can choose Normal, Repeat Track, Repeat All, Shuffle, Shuffle Repeat or Exit. Repeat Single Track: The current played music will loop continuously. Repeat All: All music files will play sequentially and continuously. Shuffle: Play music files randomly once. Normal: All music files will play sequentially once. Shuffle Repeat: All music files will play randomly and continuously.

  • Page 18: Setting Different Language (Optional)

    You can choose Disable, 1 Min, 2 Mins, 5 Mins or 10 Mins. Navigate using the Left/Right button. Press Menu button to select the item. Under Disable mode, the player will not auto shut down even if idling. Otherwise it will shutdown when under Stop or Pause mode.

  • Page 19: Setting A-B Clipping

    Setting A-B Clipping A-B clipping is useful if you need to listen to a portion of the music files continuously. It is useful for learning a song. While the music or audio file is playing, press A-B button once to set the start point A. When you are ready to select the end point, press A-B button again to start repeating the repeated portion continuously.

  • Page 20: Connecting Player To Computer

    Connecting Player to Computer You will need to connect the Player to Computer to transfer music files via USB. Locate the USB port on your computer. Refer to your computer manufacturer if you are unsure. Connect the USB port of the player to the computer using the USB cable provided. After the USB port is connected, you will see the following on the player.

  • Page 21: Minimum System Requirements

    Minimum System Requirements • Windows® 98/98SE • Windows® ME/2000/XP • Macintosh™ OS 10.x • 20MB of free disk space • 4x CD-ROM or higher • USB port Troubleshooting Guide My Windows® 98 Second Edition cannot detect the player? What should I do? Answer: Please install the driver provided on the Installation CD first.
  • Page 22 Answer: This is possible if you delete the Setting.dat file or format the player. You will need to reset again. What is the maximum SD/MMC Card size I can use for this MP3 Player? Answer: The maximum SD/MMC Card tested is 1GB.

  • Page 23: Technical Specifications

    Technical Specifications Built-In Memory Battery LCD Resolution Signal/Noise Earphone output Music Format Record Format Up to 512MB (Support SD/MMC Card) 1xAAA Alkaline or Ni-MH 128x64 pixels, OLED Blue and Yellow. >75dB 5mW+5mW MP3, WMA, WAV MP3, PCM WAV 2.0 (Up to 480Mbps)
  • Page 24 LIMITATION OF LIABILITY AND DAMAGES. IN NO EVENT WILL MANUFACTURER AND MANUFACTURER’S RESELLERS (COLLECTIVELY REFERRED TO AS “THE SELLERS”) BE LIABLE FOR DAMAGES OR LOSS, INCLUDING BUT NOT LIMITED TO DIRECT, INDIRECT, SPECIAL WILLFUL, PUNITIVE, INCIDENTAL, EXEMPLARY, OR CONSEQUENTIAL, DAMAGES, DAMAGES FOR LOSS OF BUSINESS PROFITS, OR DAMAGES FOR LOSS OF BUSINESS OF ANY CUSTOMER OR ANY THIRD PARTY ARISING OUT OF THE USE OR THE INABILITY TO USE THE PRODUCT OR THE SOFTWARES, INCLUDING BUT NOT LIMITED TO THOSE RESULTING FROM DEFECTS IN THE PRODUCT OR SOFTWARE OR DOCUMENTATION, OR LOSS OR INACCURACY OF DATA OF ANY KIND, WHETHER BASED ON CONTRACT, TORT...
