- Page 1 SPLIT-TYPE AIR CONDITIONERS INDOOR UNIT MSZ-A09NA-1 MSZ-A12NA-1 MSZ-A15NA-1 MSZ-A17NA-1 For user OPERATING INSTRUCTIONS English • To use this unit correctly and safely, be sure to read this operating in- structions before use.
-
Page 2: Safety Precautions
● OPERATING INSTRUCTIONS ● SAFETY PRECAUTIONS NAME OF EACH PART PREPARATION BEFORE OPERATION SELECTING OPERATION MODES FAN SPEED AND AIRFLOW DIRECTION ADJUSTMENT ECONO COOL OPERATION POWERFUL COOL OPERATION TIMER OPERATION (ON/OFF TIMER) CLEANING WHEN YOU THINK THAT TROUBLE HAS OCCURRED WHEN THE AIR CONDITIONER IS NOT GOING TO BE USED FOR A LONG TIME INSTALLATION PLACE AND ELECTRICAL WORK SPECIFICATIONS... - Page 3 AFETY PRECAUTIONS Do not operate switches with wet hands. CAUTION • This may cause electric shock. Do not step on an unstable bench to operate or clean Do not clean the air conditioner with water or place an the unit. object that contains water, such as a flower vase, on it.
-
Page 4: Indoor Unit
● OPERATING INSTRUCTIONS ● AME OF EACH PART Indoor unit Indoor unit Remote controller Signal transmitting section Air cleaning filter (Anti-Allergy Enzyme Filter) Distance of signal : About 20ft (6 m) Heat exchanger Beep(s) is (are) heard from the indoor unit Air inlet when the signal is received. -
Page 5: Preparation Before Operation
REPARATION BEFORE OPERATION Before operation: Insert the power supply plug into the power outlet and/or turn the breaker on. Installing the remote controller batteries Remove the front lid Insert AAA alkaline batteries Install the front lid • Make sure the polarity of the batteries is correct. •... -
Page 6: Emergency Operation
● OPERATING INSTRUCTIONS ● ELECTING OPERATION MODES AUTO mode (Auto changeover) The unit selects the operation mode according to the difference between the room temperature and the set temperature. During AUTO mode, the unit changes mode (COOL↔HEAT) when the room temperature is 4°F (2°C) away from the set temperature for more than 15 minutes. -
Page 7: Econo Cool Operation
AN SPEED AND CONO COOL OPERATION AIRFLOW DIRECTION ADJUSTMENT Press to select fan speed. Each press changes Press during COOL mode page 5 to start fan speed in the following order: ECONO COOL operation. The unit performs swing operation vertically in various cycle according to the temperature of the unit. - Page 8 ● OPERATING INSTRUCTIONS ● IMER OPERATION (ON/OFF TIMER) Press during operation to set the timer. (ON timer) : The unit will turn ON at the set time. (OFF timer) : The unit will turn OFF at the set time. blinks. * Make sure that the current time is set correctly.
-
Page 9: Front Panel
LEANING Instructions: • Switch off the power supply or turn off the breaker before cleaning. • Use only diluted mild detergents. • Be careful not to touch the metal parts with your hands. • Do not expose parts to direct sunlight, heat, or flames to dry. •... -
Page 10: When You Think That Trouble Has Occurred
● OPERATING INSTRUCTIONS ● HEN YOU THINK THAT TROUBLE HAS OCCURRED Symptom Explanation & Check points Even if these items are checked, when the unit does not recover from the trouble, stop using the air conditioner and consult your dealer. Remote controller The display on the remote •... -
Page 11: Electrical Work
HEN THE AIR CONDITIONER IS NOT NSTALLATION PLACE AND GOING TO BE USED FOR A LONG TIME ELECTRICAL WORK Installation place Set to the highest temperature in manual COOL mode, Avoid installing the air conditioner in the following places. and operate for 3 to 4 hours. Page 5 •... - Page 12 4299 14th Avenue Markham, Ontario L3R 0J2 Canada SG79Y960H01...
