Caring For Your Lawnmower - Flymo Turbo Lite User Instructions

1. To remove the blade bolt, hold the fan firmly and with
the spanner provided loosen the blade bolt by turn-
ing it anti-clockwise (M).
2. Remove the blade bolt, blade, spacers and fan.
3. Inspect for damage and clean as necessary.
• Renew your metal blade after 50 hours mowing or 2
years whichever is the sooner - regardless of condi-
tion.
• If the blade is cracked or damaged replace it with a
new one.
• Never use a blade bolt if the insulated head is dam-
aged cracked or missing.
1. Ensure the fan is located correctly.
2. Place the spacers onto the fan ensuring the pegs
have located into the holes.
3. Place the blade onto the spacers ensuring the pegs
have located into the holes on the blade and ensur-
ing the blade is positioned as illustrated in Figure N.
4. Place the blade bolt through the centre hole of the
blade.(N)
5. Tighten down clockwise by hand.
6. Hold the fan firmly and tighten the blade bolt with the
spanner provided.
Cleaning (USE GLOVES) (P)
It is very important that you keep your lawnmower clean.
Grass clippings left in any of the air intakes or under the
hood could become a potential fire hazard.
1. Remove grass from under the hood with a piece of
wood or similar.
2. Using a soft brush - remove grass clippings from all
air intakes.
3. Remove the blade, see Figure M, to gain access to
the fan and clean with a soft brush.
4. Wipe over the surface of your lawnmower with a dry
cloth.
• IMPORTANT
Never use water for cleaning your lawnmower. Do
not clean with chemicals, including petrol, or sol-
vents - some can destroy critical plastic parts.
At the End of the Mowing Season
1. Replace blade, bolts, nuts or screws, if necessary.
2. Clean your lawnmower thoroughly.
3. Ask your local Service Centre to clean the air filter
thoroughly and carry out any service or repairs re-
quired.
4. Make sure that the electric cable is coiled properly.
Carrying your Lawnmower
Ensure the blade is facing away from you.
Storing your Lawnmower
Store in a dry place where your lawnmower is protected
from damage.
Removing the Blade and Fan
Fitting the Blade and Fan

Caring for your Lawnmower

M
N
Turbo Lite 330
P
Turbo Lite 350/400
