Interface
Ethernet Port
*
Power Plug
Pair Button
* The provided power plug may differ from the picture due to different regional power specifications. Here
we take the EU version as an example.
Note:
1. If you press the pair button for more than 10 seconds, the powerline adapter will leave the network
which it has joined and its new network name assumes a random value. The Power LED turns off
when it disconnects from the powerline network.
2. For detailed information about the pair button, please refer to
Use the Pair buttons.
A 10/100/1000 Mbps Ethernet port for connecting the adapter to the
PC or the broadband device with a network cable.
A Power Plug for connecting the adapter to a 100V ~ 240V
(50~60Hz) AC power socket.
Pair buttons are used to secure a powerline network. To secure
your network, please follow the steps below. Firstly, plug in a new
adapter, and press its pair button for one second; then plug in
another adapter and press its pair button for one second as well.
The two buttons should be pressed within 2 minutes of each other.
After that, wait about 60 seconds so that the two adapters can finish
connecting.
5
TL-PA511 AV500 Mini Powerline Adapter
Description
