- Page 1 BC2003 / TR2002 848J5J93A2 (801) OWNER’S MANUAL BRUSHCUTTERS BC2003 TR2002 GB-1...
- Page 2 BC2003 / TR2002 EXPLANATION OF SYMBOLS AND SAFETY WARNINGS WARNING!!! RISK OF DAMAGING HEARING Wear head, eye and ear protection. MODEL SOUND LEVEL VIBRATION LEVEL ISO 22868 ISO 22867 ISO 10884 (guaranteed) ahv. eq A(8) pAav 4.9 m/s 21.7 cm...
-
Page 3: Table Of Contents
BC2003 / TR2002 Husqvarna Zenoah Co., Ltd. 80100001 and up 1st January 2008 Masahiko GOUDA SAFETY FIRST Contents Instructions contained in warnings within this manual marked with a symbol concern critical points which must be taken 1. Parts location ..........4... -
Page 4: Parts Location
Type ................Air-cooled 2-stroke gasoline Model ..................... Zenoah G20LS Displacement ................... 21.7 cm Fuel ................Mixture (Gasoline 50 : Oil 1) (when using ZENOAH genuine oil) Carburetor ..................Diaphragm type Ignition system ....................C.D.I Spark plug ..................NGK BPMR7A Fuel tank capacity ....................0.5 L Starter ...................... -
Page 5: Warning Labels On The Machine
BC2003 / TR2002 3. Warning labels on the machine (1) Read owner’s manual before operating this machine. (2) Wear head, eye and ear protection. (3) Wear foot protection. (4) Wear gloves. (5) Beware of thrown objects. (6) Warning / Attention (7) Keep all children, bystanders and helpers 15 meters away from the machine. -
Page 6: For Safe Operation
BC2003 / TR2002 5. For safe operation b. At night, at times of heavy fog, 1. Read this manual carefully until or at any other times when you completely understand and your field of vision might be follow all safety and operating limited and it would be diffi- instructions. - Page 7 BC2003 / TR2002 5. For safe operation BEFORE STARTING part nor the throttle come into THE ENGINE contact with any obstacle when 1. The area within a perimeter of the engine starts. 15 m of the person using the product should be considered a...
- Page 8 5. For safe operation • IF SOMEONE COMES HANDLING FUEL 1. Guard against hazardous situa- 1. The engine of the ZENOAH prod- tions at all times. Warn adults to uct is designed to run on a mixed keep pets and children away from fuel, which contains highly flam- the area.
-
Page 9: Set Up
BC2003 / TR2002 6. Set up HARNESS INSTALLING HANDLE WARNING ALWAYS WEAR THE PROVIDED HARNESS WHEN USING THE MACHINE! Always make sure the machine is hooked securely to the harness. If you don't, you will be unable to control the machine safely. -
Page 10: Fuel
2. Put fuel into the fuel tank to 80% of the full capacity. 3. Fasten the fuel cap securely and wipe up any fuel spillage around the unit. • The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. WARNING... -
Page 11: Operation
BC2003 / TR2002 8. Operation STARTING ENGINE WARNING WARNING The product is equipped with a centrifugal clutch mechanism, so the cutting attachment begins to ro- The cutting head will start rotating upon the engine tate as soon as the engine is started by putting the starts. - Page 12 BC2003 / TR2002 8. Operation ADJUSTING THROTTLE CABLE TRIMMING GRASS AND WEEDS • The normal play is 1 or 2 mm when measured at the • Always remember that the TIP of the line does cut- carburetor side end. Readjust with the cable adjuster ting.
-
Page 13: Maintenance
BC2003 / TR2002 9. Maintenance Every Every Every Before System/components Procedure Note hours hours hours after after after ✔ fuel leaks, fuel spillage wipe out ✔ ✔ fuel tank, air filter, fuel filter inspect/clean replace, if necessary see adjusting replace carburetor ✔... - Page 14 BC2003 / TR2002 9. Maintenance SPARK PLUG ANGLE TRANSMISSION • Starting failure and misfiring are often caused by a fouled spark plug. Clean the spark plug and check • The reduction gears are lubricated by multipurpose, that the plug gap is in the correct range. For a re- lithium-based grease in the angle transmission.
-
Page 15: Storage
BC2003 / TR2002 9. Maintenance PROCEDURES TO BE PERFORMED AFTER 3. Take out the spool and pull off the old line. Put one EVERY 100 HOURS OF USE end of new line through the spool holes and pull it until the length is equal between each part of the line. -
Page 16: Troubleshooting Guide
→ clogged with dust → clean cylinder fin, fan cover When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
