  • Page 1 BC2310DL 848J9893A1 (708) OWNER’S MANUAL BRUSHCUTTERS BC2310DL GB-1...
  • Page 2 BC2310DL EXPLANATION OF SYMBOLS AND SAFETY WARNINGS WARNING!!! RISK OF DAMAGING HEARING Wear head, eye and ear protection. MODEL SOUND LEVEL VIBRATION LEVEL ISO 22868 : 2005 ISO 22867 : 2004 EN27917 idling racing measured guaranteed 107.9 dB(A) 110 dB(A) 3.5 m/s...

  • Page 3: Table Of Contents

    This mark indicates instructions, which must be followed, or it leads to mechanical failure, breakdown, or damage. NOTE This mark indicates hints or directions useful in the use of the product. ZENOAH CO., LTD. 1-9, Minamidai, Kawagoe, Saitama, Japan EN ISO 11806 : 1997 : BRUSHCUTTER : BC2310DL...

  • Page 4: Parts Location

    Spark plug ... NGK BPMR7A Fuel tank capacity ... 0.6 L Starter ... Recoil starter Clutch ... Centrifugal type Reduction ratio ... 1.462 Cutting head rotating direction ... Counter-clockwise (Operator view) Specifications are subject to change without notice. GB-4 (when using ZENOAH genuine oil)

  • Page 5: Warning Labels On The Machine

    Position: AIR CLEANER COVER The direction to open the choke Position: AIR CLEANER COVER Never modify your machine. We won’t warrant the machine, if you use the remodeled brushcutter or if you don’t observe the proper usage written in the manual. BC2310DL GB-5...

  • Page 6: For Safe Operation

    BC2310DL 5. For safe operation 1. Read this manual carefully until you completely understand and follow all safety and operating instructions. 2. Keep this manual handy so that you may refer to it later when- ever any questions arise. Also...
  • Page 7 If it continues to rotate even after the throttle has been moved fully back, turn off the engine and take the unit to your authorized ZENOAH servic- ing dealer for repair. USING THE PRODUCT IMPORTANT Cut only materials recommended by the manufacturer.
  • Page 8 GB-8 HANDLING FUEL 1. The engine of the ZENOAH prod- uct is designed to run on a mixed fuel, which contains highly flam- mable gasoline. Never store cans of fuel or refill the tank of the unit...

  • Page 9: Set Up

    1. Remove the plastic tube that is attached to the gear shaft. 2. Firmly screw the line head assembly onto the gear shaft by hand while locking the gear shaft by insert- ing the tool into the upper holder on the gear box. BC2310DL GB-9...

  • Page 10: Fuel

    3 m (10 ft) away from the fueling point before starting the engine. • The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant...

  • Page 11: Operation

    1. Release the throttle lever and run the engine for half a minute. 2. Shift the ignition switch to the STOP position. IMPORTANT • Except for an emergency, avoid stopping the engine while pulling the throttle lever. BC2310DL Stop Start GB-11...
  • Page 12 BC2310DL 8. Operation ADJUSTING THROTTLE CABLE • The normal play is 1 or 2 mm when measured at the carburetor side end. Readjust with the cable adjuster as required. .04 in (1 ~ 2 mm) (1) Cable adjuster ADJUSTING IDLING SPEED (1) Idle adjusting screw 1.

  • Page 13: Maintenance

    ✔ tighten/replace ✔ make sure to attach FUEL FILTER • When the engine runs short of fuel supply, check the fuel cap and the fuel filter for blockage. BC2310DL Note after after replace, if necessary replace carburetor if necessary GAP: .025 in (0.6 ~ 0.7 mm) ✔...
  • Page 14 BC2310DL 9. Maintenance SPARK PLUG • Starting failure and misfiring are often caused by a fouled spark plug. Clean the spark plug and check that the plug gap is in the correct range. For a re- placement plug, use the correct type specified by ZENOAH.

  • Page 15: Storage

    Store the unit indoor taking necessary measures for rust prevention. 11. Disposal When disposing your machine, fuel or oil for the machine, be sure to allow your local regulations. BC2310DL GB-15...

  • Page 16: Troubleshooting Guide

    (exhaust port) → carbon is built-up air cleaner cylinder fin, fan cover When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
