Page 1: Installation And Operation Manual
Voice Amp SpeakEASY VA30 Series Installation and Operation Manual ARG’s Voice Amp SpeakEASY Port- able Amplifier with optional modular 900MHz digitally encrypted wireless microphone system. www.argaudio.com ◊ 440 Ramsland Ave ◊ Hannaford, ND 58448 ◊ 888.468.4552... - Page 2 Voice Amp SpeakEASY Owner’s Manual: ARG-OM1 © 2011 Audio Resource Group, Inc. All Rights Reserved.
- Page 3 SpeakEASY Portable Amplifier System. Each system has been designed and manufactured right here in the USA. Our products have been in use throughout the world for more than 50 years. All of ARG’s high quality products are designed to provide many years of reliable service; they are uncomplicated to use so anyone can operate them with ease and confi- dence.
-
Page 5: Table Of Contents
I ns i de S t o r y Headl i ne ARG PRODUCT MANUAL SERIES: Voice Amp SpeakEASY Page 5 CONTENTS CONTENTS CONTENTS CONTENTS Safety & Caution Information p. 6 System Contents p. 7-8 Front View Diagram p. 9 Rear View Diagram p. -
Page 6: Safety & Caution Information
Product Recycling Instructions DO NOT DISPOSE ELECTRONICS IN THE HOUSEHOLD TRASH! Help ARG protect our environment by locating an electronics recycling center OR return the product(s) to ARG for proper disposal. www.argaudio.com ◊ 440 Ramsland Ave ◊ Hannaford, ND 58448 ◊ 888.468.4552... -
Page 7: System Contents
(1) ARG-AC-PS4 - Switching Power Supply/Battery Charger (1) ARG-CC8 - Soft Sided Bag (1) ARG-SS1 - Shoulder Strap (1) ARG-MP10 – Wired Handheld Microphone with 10’ attached cable (1) ARG-OM1 - Operation Manual VoiceAmp SpeakEASY SINGLE WIRELESS System includes: (1) ARG-VA30S-SPK1 - Portable Amplifier with (1) 900MHz Wireless Module... - Page 8 Light Duty Speaker Stand ARG-TP2 - Heavy Duty Speaker Stand ARG-TP3 - 5/8” - 27 to 3/8” - 16 Speaker Stand Adapter for the ARG-TP2 ARG-TP4 - Wall or Ceiling Speaker Mount www.argaudio.com ◊ 440 Ramsland Ave ◊ Hannaford, ND 58448 ◊ 888.468.4552...
-
Page 9: Front View Diagram
I ns i de S t o r y Headl i ne ARG PRODUCT MANUAL SERIES: Voice Amp SpeakEASY Page 9 SYSTEM CONTROLS: FRONT VIEW 1 - Battery Charging Indicator 2 - IR Remote Sensor 3 - Low Battery Indicator... - Page 10 I ns i de S t o r y Headl i ne ARG PRODUCT MANUAL SERIES: Voice Amp SpeakEASY Page 10 SYSTEM CONTROLS: REAR VIEW see below * *#2 LCD Display Signal Strength Lock/Unlock Channel Number www.argaudio.com ◊ 440 Ramsland Ave ◊ Hannaford, ND 58448 ◊ 888.468.4552...
- Page 11 3. Antenna (A&B): The 900MHz Digital Receiver has an internal antenna attached which provides enough signal strength to provide up to 100’ of range. Note: If additional range is required attach the ARG-AN3 antenna for a maximum range of 300’. Note:...
- Page 12 25. Power Supply / Charging Jack: 25. Power Supply / Charging Jack: 25. Power Supply / Charging Jack: Plug the supplied 18V AC adapter (ARG-AC-PS4) to supply continuous power or to recharge the Lithium Battery Pack for portable use. **9 MP3/USB Player LCD Display Detail...
- Page 13 110-125 VAC outlet and push the Master Power ON button. When battery operation is needed, you will need to fully charge the installed lithium battery pack before using. To charge, plug the included ARG-AC-PS4 switching power supply/battery charger to the power supply/charging jack “DC 18V/3A” located on the back of the speaker, plug the other end into a 110-125 VAC outlet.
- Page 14 I ns i de S t o r y Headl i ne ARG PRODUCT MANUAL SERIES: Voice Amp SpeakEASY Page 14 Voice Amp SpeakEASY: QUICK USE GUIDE (continued) Correct System Setup Diagram Correct System Setup Diagram Correct System Setup Diagram...
- Page 15 6. Rotate the Master Volume Control clockwise to adjust overall volume level of all input options. Note: The volume level can also be adjusted with the optional remote control (ARG-RC1) 7. When finished push the “Power” button to turn off and rotate all of the input level controls counterclockwise to their minimum settings.
-
Page 16: Arg-Tx900Hh Product Detail
I ns i de S t o r y Headl i ne ARG PRODUCT MANUAL SERIES: Voice Amp SpeakEASY Page 16 900MHz DIGITAL HANDHELD TRANSMITTER Model Number ARG-TX900HH 1. ON/OFF: Main power control. 2. LCD Display: Displays basic information including: channel number, volume, battery level, low pass filter setting and the lock/unlock status. -
Page 17: Quick Use Guide
I ns i de S t o r y Headl i ne ARG PRODUCT MANUAL SERIES: Voice Amp SpeakEASY Page 17 ARG-TX900HH TRANSMITTER: QUICK USE GUIDE 1. Locate and unscrew the battery compartment cover (This is the bottom portion of the mi- crophone housing). -
Page 18: Arg-Tx900Bp Product Detail
Note: The “LOCK” (4) needs to be in the “UNLOCK” mode. 7. USB: Charging port for ARG-AC-PS1 battery charger. 8. Mic-In/Line-In: The mono 3.5mm jack accepts wired microphones or audio devices that have a line-level output, this includes MP3 players, IPODS and CD players. -
Page 19: Arg-Tx900Bp Quick Use Guide
ARG-TX900BP TRANSMITTER: QUICK USE GUIDE 1. The ARG-TX900BP has a lithium battery pack installed. Before initial use, you will need to charge the battery with the included ARG-AC-PS1 battery charger. When fully charged, the red charge LED indicator will shut off indicating the battery is charged and ready for use. -
Page 20: Trouble Shooting Guide
♦ The transmitter batteries are weak or dead and need to be replaced. ♦ Using the ARG-TX900BP transmitter, make sure the microphone is plugged into the microphone input jack located on the side of the transmitter. ♦ If the problem continues, cycle the transmitter power OFF and then ON again. - Page 21 The Master Power button is not in OFF position. ♦ AC power is not present at the AC outlet. ♦ The AC power supply has failed (call ARG for replacement). I. Shortened Battery Life: ♦ Batteries are not fully charged and need to be completely charged.
-
Page 22: Technical Specifications
ARG PRODUCT MANUAL SERIES: Voice Amp SpeakEASY Page 22 VA 30S Voice Amp SpeakEASY TECHNICAL SPECIFICATIONS Rated Power Output 30 Watts CLASS D Max SPL @ Rated Power 90dB @ 1 meter Frequency Response 60 Hz – 18 kHz Switch Power Supply/Battery Charger INPUT 100Vac-240Vac, 50/60Hz 1.5A-0.9A... -
Page 23: Compliance Information
Warranty does not apply to normal wear and tear of the products' useful lifetime. ARG, Inc. is not liable, without limitation to any person or entity, for any direct, incidental, conse- quential damages or medical expenses caused by any use, defect, failure or malfunction of the product. - Page 24 Operator’s Manual: ARG-OM1 ©2011 Audio Resource Group, Inc. All Rights Reserved www.argaudio.com ◊ 440 Ramsland Ave ◊ Hannaford, ND 58448 ◊ 888.468.4552...
