- Page 1 MUND CLIMA ® Cooling only Heat pump MUP-07 CE MUP-07 HE MUP-09 CE MUP-09 HE MUP-12 CE MUP-12 HE MUP-18 CE MUP-18 HE MUP-24 CE MUP-24 HE User's manual and Installation manual...
- Page 2 Thank you for you purchasing our air conditioner. Please pay attention to the following: • The installation should be carried out by specialists. • In order to use it safely, correctly and efficiently, please read the instructions carefully and keep the instructions for reference in the future. •...
-
Page 3: Table Of Contents
CONTENTS Specifications ..............4 User's manual Parts Description: Indoor Unit . - Page 4 MUND CLIMA ®...
- Page 5 MUND CLIMA ®...
-
Page 6: User's Manual
User's manual PARTS DESCRIPTION Indoor Unit • Indoor Unit Installation board Middle frame Indication light and signal receiver Front panel Horizontal airflow direction vane Vertical airflow direction vane (inner) Air filter Pipe protection ring Drain pipe Outdoor Unit • Outdoor unit Pipe and Drain pipe Cut-off valve Outlet cover... - Page 7 Indoor Unit ® MUND CLIMA Outdoor Unit MUP-18 and MUP-24 MUP-07, MUP-09 and MUP-12 MUND CLIMA ®...
-
Page 8: Usage
USAGE Working condition Maximum DB/WB 32°C / 23°C Indoor Minimum DB/WB 21°C / 15°C Cooling Maximum DB/WB 43°C / 26°C Outdoor Minimum DB/WB 21°C / 15°C Maximum DB/WB 27°C Indoor Minimum DB/WB 21°C Heating Maximum DB/WB 24°C / 18°C Outdoor Minimum DB/WB -5°C / -6°C Remote controller usage... -
Page 9: Items Of Attention
Wind direction adjusting: 1. Horizontal wind direction adjusting Use hands to move the vane and change the horizontal wind direction. Note: Adjust the horizontal wind direction before the air-conditioner starts. Don't reach your finger into air-out window when the air-conditioner is operating. 2. -
Page 10: Optimal Operation
Optimal operation Pay attention to the following items so as to ensure optimal operation of the system, detailed operation see the relevant content. • Please set the scheduled operation time with the remote controller. • Set the suitable temperature for a comfortable environment. Don't make the room too cold or too hot. -
Page 11: Maintenance
Danger: • • Don't put your hand or stick-shaped Don't touch the swinging wind vanes, objects into the air outlet of the in- or it may clamp your door and outdoor unit, finger and damage otherwise, the rotating the driving parts of Danger fan at high speed may the wind vanes. -
Page 12: Non-Air Conditioner Trouble
In case that following situations, please deal with it according to the following methods, if it does not work, please contact distributor and inform the detailed failure. Failure Causes Methods of resolution Wait for the recovery of power Power supply failure supply The power switch is released Switch on the power... - Page 13 2. White steam comes out from the indoor unit: During the cooling operation, un- der high relative humidity indoors, white steam may come out due to the high hu- midity and temperature difference of air inlet and outlet. The air-conditioner con- vert to heating operation after the frost dissolving, the moisture due to frost dis- solving is discharged in form of steam.
-
Page 14: Cleaning
Cleaning Warning: For the purpose of safely, please turn off the air-conditioner and cut off the power supply before cleaning. Cleaning the indoor unit 1. Wipe the indoor unit with dry cloth. 2. If the indoor unit is very dirty, please wipe with wet cloth dipped by cold water. 3. -
Page 15: Installation
INSTALLATION • The installation of air-conditioner should meet “Installation Instruction”. • The machine must be installed correctly by professional technicians according to the “Installation Instruction”. Guide of customer • The customer should have a qualified power supply coincident with the tag of the air conditioner, its voltage should be in the range of 90-110% of its rated voltage. -
Page 16: Installation Manual
Installation manual SELECTION OF THE INSTALLING POSITION MUND CLIMA ®... -
Page 17: Installation Of The Indoor Unit
INSTALLATION OF THE INDOOR UNIT MUND CLIMA ®... -
Page 18: Check The Water Discharge
CHECK THE WATER DISCHARGE INSTALLATION OF THE OUTDOOR UNIT MUND CLIMA ®... -
Page 19: Pipe Connection
PIPE CONNECTION THE FORM OF PIPE MUND CLIMA ®... -
Page 20: Expelling The Air In The Pipes And The Indoor Unit
EXPELLING THE AIR IN THE PIPES AND THE INDOOR UNIT MUND CLIMA ®... -
Page 21: Electrical Connection
ELECTRICAL CONNECTION Heat pump Type TEST RUNNING MUND CLIMA ®... -
Page 22: Names And Functions Of The Buttons
Instructions of remote controller NAMES AND FUNCTIONS OF THE BUTTONS MUND CLIMA ®... -
Page 23: The Closing State Of Remote Controller
The closing state of remote controller Sleeping button “ ” Which enables you to start the automatic operation in sleeping mode and stop by pressing on it again. Wind direction adjusting button “ ” Press the button, the horizontal airflow direction plate can adjust automatically. When you have the desired wind direction, please press it again, the airflow direc - tion plate will stop at the situation. -
Page 24: Display
Set button “ ” When press the set button, the function of adjusting clock time or affirming the timer time can be set. Time setting button “ ” or “ ” These two buttons can adjust clock time and timer time. Press it for 1 to 5 seconds, time display will change at the speed of three times per second (Unit: 10 minute). -
Page 25: Application Method
Mode display MODE Press the “ ” button, it shows the current operation mode. You can select “Feel”, “Cool”, “Dry”, “Fan”, “Heat”, operation mode. (Cold wind type has no hea- ting display). Temperature display Which displays the setting temperature. In the circulation operation mode, the temperature number don't display. -
Page 26: Cooling/Heating Operation Mode
Cooling/heating operation mode (Cold wind type has no heating function) MODE 1. Press the “ ” button, select the Cooling or Heating operation mode. °C °C 2. Press the “ ” or “ ” button, set the temperature, temperature can be set al 1°C —... -
Page 27: Timer Setting
Timer setting Set the “Timer ON” (It is effective only when the air conditioner is shut off). TIMER 1. Press the “ ” button, select the “Timer ON”, the remote controller displays ; “ON” displays intermittently. 2. Adjust time through pressing the “ ”... - Page 28 Fax 96 511 57 34 Fax 91 675 12 82 Fax 977 32 85 61 03008 Alicante 28830 S. Fernando Henares 43206 Reus (Tarragona) Solicíte listado de Servicios Técnicos de su província: Tel. 93 652 53 57 (S.A.T. Mundoclima)
