Agatec CL250 User Manual page 2

Table of contents
1. General information
1.1 Description
1.2 Safety
1.3 Technical specifications
1.4 Laser and Keypad overview
2. How to use your CL250 laser
2.1 Horizontal set-up and operation
2.2 H.I. Alert
2.3 Rotation speed
2.4 Manual slope.
3. Power
3.1 Installing alkaline batteries
3.2 Using rechargeable batteries
3.3 Later recharges
4. Checking and adjusting your CL250
4.1 Calibration overview
4.2 Horizontal checking and calibration
4.3 Cone error checking
5. Care and Handling
CAUTION
6. Warranty
7. Accessories
7.1 Detector
7.2 Tripods
7.3 Other accessories
2
Congratulations!
You have just purchased the CL250 Cone electronic level.
Although it is very simple to use, we recommend that you read this
3
manual before operating the laser.
1.1 Description
5
The CL250 laser has these advanced features
• Automatic self-leveling in horizontal.
• Visible laser beam
• Easy electronic calibration
• Match slope in X and Y axes
7
1.2 Safety
The CL250 is a Class 3R laser, manufactured to comply with the
8
international rules of safety IEC 60825-1, 2001. Although the
power of the emission of the beam is less than 5mW in Class 3R,
the following cautions are recommended:
• Do not stare directly at the beam
• Do not set up the laser at eye level
12
A. CDRH warning label for USA
13
13
1. General information
CLASS 3R LASER PRODUCT
WAVE LENGTH 630-680 nm
MAX. OUTPUT POWER: 5mW
LASER LIGHT: AVOID DIRECT EYE EXPOSURE
CONFORMS TO IEC 60825-1; 2001
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR DEVIATIONS
PURSUANT TO LASER NOTICE NO. 50
DATED JULY 26, 2001
AGATEC, 2202 Redmond Road
Jacksonville, AR 72076
3
