DESCRIPTION

► ► ► ►
General construction
■ ■ ■ ■
The transmission case, Engine and Front Axle Support are bolted together to form a rigid unit.
Front Axle & Wheels
■ ■ ■ ■
The 4WD front axle is a center-pivot, reverse Eliot type. The front wheel drive mechanism is
incorporated as a part of the axle.
The front wheel drive power is taken off the rear transmission and transmitted to the differential in the
front axle where the power is divided into right and left and to the respective final cases.
In the final cases, the transmitted revolution is reduced by the level gears to drive the front wheel.
The 4WD mechanism with level gears provides wider steering and greater durability.
Engine
■ ■ ■ ■
The tractors are fitted with fuel efficient engine with 4 cylinders manufactured by Daedong
Transmission with HST (Hydrostatic Transmission)
■ ■ ■ ■
The Tractor is fitted HST with 3 Range and can be selected Speed range by HIGH-LOW selector lever.
The Tractor has Two pedals for forward/reverse control . Tractor with Independent Power Take Off
is fitted with electro-hydraulic Clutch Assy. The Rear PTO and Mid PTO can be operated both or
separately by a lever.
Brakes
■ ■ ■ ■
Mahindra tractors are provided with independent disc brakes operated by two road travel.
A foot brake lever is fitted for parking.
Rear axle & Wheels
■ ■ ■ ■
This is mounted on ball bearings and is enclosed in removable housing which are bolted to the
transmission case. The rim & Disc fitted with Rear tires are bolted to the outer flange of Rear Axle.
Hydraulic system & Linkages.
■ ■ ■ ■
Mahindra Tractors are fitted with Live (i.e. system is in operation) independent, very touch of hydraulic
System. Three point Linkages can be used for category 1 type of implements.
Steering
■ ■ ■ ■
It consists of Hydrostatic Power steering system, which has a hydraulic cylinder and single type
hydraulic pump
Electrical System
■ ■ ■ ■
A 12 Volt Battery is used to activate the Engine through the Starter Motor and the Electrical system
comprising Horn, Head Lamp, Turn signal lamp, Taco-meter, Hour meter, Brake lamp, Gauge lamp,
Hazard Lamp. General or Alternator, Fuse box also from part of the Electrical system.
