The System Features L earn Routine dictates how the unit operates It is possible to
access a nd change most of the featu re settings us ing the Control button
1 Open a door
2 Tum the ignition on , then off
3. Select a Menu . Press and hold the Control button. The number of si ren chirps
ind icates the menu number. I chirp indicates menu 1, 2 ch irps - menu 2 and
3 chi rps for menu 3
4 W hen the desi red menu chi rps ore heard , release the Control button
5 . Select a Feature. Press and release the Control button the number of times
correspond ing to the feature you w ish to change. Then press and hold one
more time to select the features
6. Program the Feature. Whi le hold ing the Control button , you con program the
feature using the remote control.
For features with only two options;
~
=
option 1 whi le
$
= option 2
For features with more than two options;
Q
selects the options in ascend ing ord er,
whi le
$
selects them in descend ing order.
Note: Pressing {:) button resets the feature to the factory default.
Once
o
feature is programmed:
O ther features con
be
programmed w ith in the some menu
Another menu con
be
selected
The lea rn routine con
be
exited if programm ing is complete
To access another feature in the same menu :
1. Press and release the Control button the number of times necessary to advance
from the feature you just prog rammed to the next o ne you want to prog ram
Then press the Control button once more and hold it.
To select another menu:
1 Press and hold the Control button
2. Alter 3 seconds, the unit adva nces to the next menu a nd the siren chirps, indi-
cating which menu has been accessed
The learn routine exits
if
any of the following occurs:
The open door is dosed
The ign iti on is turned On
There is no activity lor
30
seconds
The Control button is pressed too many times
RitwriteL:Jlnly_Optinos_
H
If programming with the Bitwriter®, the learn rou tine can
be
locked or un·
locked. If the learn rou tine has previously been
l ~ ked,
it must
be
un locked
w 1th B1twriter® · this cannot
be
done ma nually w1th the Control button
The Bitwriter®
11!11
g ives you access to a wider range of system options. These
features and the ad justments that may be progra mmed are described in the table
below. Default settings a re in bold type
0 2011 Direded Electronics. All rights Re~d
Menu 2 -Convenience
feotur:e_M.enus
Default settings ore in bold type . New fea tures are bold w ith grey backg1 ound.
Menu l -Security
Menu 3 - Remote stort
Remote Pairing
Prepare the vehicle system to
be
Paired with o new remote
1 Open a door
2
Turn the key to the ON position
3. W ithi n 5 seconds press and release the Control button on the Control Center
one ti me.
4.
Within
5
seconds, press and hold the Control button on the Control Center.
The status LED wil l flash one time and the siren then chi rps to confirm the vehicle
is ready fo r remote pa iring.
Release the Control button and proceed below.
Note: If no remote pair ing results, the system will exit aher
60
seconds .
Prepare the new remote to be Paired with the system
Remote Pa ir matches your LE remo te to the system. Make sure the LE remote is set lor
the desi red Cor 1 (DefoultL or Cor
2
operation lo. r 1he system it w ill
be
pa ired with
1 Press and hold the
f
button for
8
seconds
Note: The LOCK LED ind icato r w ill turn on at
3
seconds. Please disregard and
con ti nue to hold
Wait lor the Transmit lED to lig ht solid and the remote to beep _ Release the
j
button
3.
Press the {:') for 1 second. The tra nsmit lED will bli nk
3
times and beep
3
times
4. Withi n 5 seconds, press the
Q
button .
5.
The veh icle siren w ill chirp and the lED ind icators on the remote w ill light in
seq uence with sound. You hove now successfully learned the remote to the
veh icle remote start and security system.
6. Press the
j
button two times to exit learn routine on the remote. The transm it
LED w il l turn off and exit tone w ill sound ..
Note:
Please see instal lation gu ide for pa iri ng with the 1-woy companion remo te .
