Python 513 Owner's Manual

Remote start alarm system
Hide thumbs Also See for 513:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
Model 513
Owner's Guide

Advertisement

Table of Contents
loading

Related Manuals for Python 513

Summary of Contents for Python 513

  • Page 1 Model 513 Owner’s Guide...

  • Page 3: Table Of Contents

    Contents Warning! Safety first ..................iii What is included ....................1 Important information ..................1 System maintenance ..................1 Your warranty...................2 Fcc/id notice ....................2 Caution ....................2 Replacement remote controls ..............2 Standard transmitter configuration ...............3 Transmitter functions ..................4 Standard configuration ................4 Using your system ....................6 Active arming ...................6 Passive arming ..................6 Multi-level security arming ................7...
  • Page 4 Programming options ..................22 Security & convenience expansions ..............24 Glossary of terms ....................25 Quick reference guide ..................27 Limited lifetime consumer warranty ..............29 Notes ......................31 reserved. ©2009 Directed Electronics. All rights...

  • Page 5: Warning! Safety First

    Warning! Safety first The following safety warnings must be observed at all times: Due to the complexity of this system, installation of this product must only be performed by an authorized Directed dealer. When properly installed, this system can start the vehicle via a command signal from the remote control.
  • Page 6 properly reinstall the remote start system so that the vehicle does not start in gear. All installations must be performed by an authorized Directed dealer. OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS IN GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION. OPERAT- ING THE REMOTE START SYSTEM UNDER THESE CONDITIONS MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY.

  • Page 7: What Is Included

    What is included • A control module • An HX transceiver/antenna • Two four-button transmitters • A Stinger™ DoubleGuard two-stage shock sensor ® • A Revenger™ Soft Chirp™ six-tone pro gram ma ble siren • A status LED indicator light •...

  • Page 8: Your Warranty

    ➢ Your warranty Your warranty registration must be completely filled out and returned within 10 days of purchase. Your product warranty will not be validated if your warranty registration is not completed. Make sure you receive the warranty registration from your dealer. It is also necessary to keep your proof of purchase, which reflects that the product was installed by an au tho rized dealer.

  • Page 9: Standard Transmitter Configuration

    Standard transmitter configuration controls Arm and Panic On/Off function controls Disarm and Panic Off function controls Silent Mode™ and Auxiliary trunk output controls Remote start function pressed together control Timer Mode pressed together control remote start Timer mode. pressed together control Temperature �������...

  • Page 10: Transmitter Functions

    Transmitter functions The receiver uses a computer-based Learn Routine to learn the trans mit ter but- tons. The transmitter is initially programmed with Standard Configuration. The buttons in all of the instructions in this manual correspond to a Standard Con- figuration transmitter.
  • Page 11 Buttons An optional auxiliary convenience or expansion function that you have added to your system is activated by pressing these buttons simultaneously. The auxiliary output controls __________________________. Buttons Short-run turbo mode is activated (if connected) when these buttons are pressed simultaneously.

  • Page 12: Using Your System

    Using your system ➢ Active arming You can arm the system by pressing on your trans mit ter for one second. When the system arms, you will hear a short siren and see the parking lights flash once. If the power door locks are con trolled by the system, the doors will also lock.

  • Page 13: Multi-Level Security Arming

    • If a door is opened, the system will immediately start chirping the siren and flashing the parking lights. Three seconds later, the siren out put changes to a continuous blast. This pro gres sive re sponse gives you time to disarm the sys tem with your trans mit ter if you inadvertently open the door while the system is armed, while still providing instant re sponse (even if the door is immediately closed).

  • Page 14: Arming While Driving

    ➢ Arming while driving Your security system can be armed while driving the vehicle. Press on the transmitter for two seconds while the vehicle is running. The siren will chirp once to indicate that the security system is armed, and then once more to indicate that the ig ni tion is on.

  • Page 15: Disarming Without A Transmitter

    ➢ Disarming without a transmitter If your transmitter is lost or damaged, you can manually disarm your vehicle security system. To disarm the system without a transmitter, you must have the vehicle’s ignition key and know where the Valet switch is located. Be sure to ®...

  • Page 16: Panic Mode

    ➢ Panic mode If you are threatened in or near your vehicle, you can attract attention by trigger- ing the system with your transmitter. Press for two seconds, and you will enter Panic Mode. The siren sounds and the parking lights flash for the programmed siren duration. To stop Panic Mode at any time, press on the remote transmitter again.

  • Page 17: Remote Start

    Remote start You can remotely start and run your vehicle for a pro gram ma ble period of time. This makes it possible to warm up the engine, and adjust the interior tem per a- ture of the vehicle with the climate control system. If interior heating or cooling is desired, the climate controls must be preset, and the fan blower must be set to the desired level prior to remote starting the vehicle.

  • Page 18: Rear Defogger

    When you are ready to drive the vehicle: Insert the ignition key and turn it to the On position. Press the brake pedal. Important: If the brake pedal is pressed before the key is in the ON position, the engine will shut down.

  • Page 19: Valet Take-Over

    To turn the rear defogger output ON: Simultaneously press & release the buttons on the re- mote control. The lights will flash 3 times. The rear defogger output will once again activate when the vehicle is remote started. ������� If the remote start is on, the lights turn off then flash 3-times before returning to normal output.

  • Page 20: Timer Mode

    ➢ Timer mode When you activate timer mode the system automatically starts the vehicle every three hours for a maximum of 6 starts. The pre-programmed engine runtime is 12 minutes. • Press to activate timer mode. The parking lights flash four times, and after a 1 second delay, the engine starts.

  • Page 21: Safety Features

    Safety features This system has several important safety features to ensure proper operation of the motor and prevent accidental damage to the engine or its components. ➢ Starter anti-grind circuitry Whenever the vehicle is remote started, advanced anti-grind circuitry prevents the starter from engaging, even if the key is turned to the start position.

  • Page 22: Nuisance Prevention Circuitry

    Nuisance prevention circuitry ® Your system has Directed’s Nuisance Prevention Circuitry (NPC). It pre vents ® annoying repetitive trigger sequences due to faulty door pin switches or en vi ron- men tal con di tions such as thunder, jack ham mers, airport noise, etc. Example If the alarm triggers three times within a 60-minute period and each time the same sensor or switch triggers the alarm, NPC will interpret those triggers as...

  • Page 23: Diagnostics

    Diagnostics The microprocessor at the heart of your system is constantly mon i tor ing all of the switches and sensors connected to it. It is designed to detect any faulty switches and sensors and prevents them from disabling the entire system. The microprocessor will also record and report any triggers that occurred during your absence.

  • Page 24: System Status Chirps

    ➢ System status chirps The siren will chirp when arming/disarming the system. The pattern of chirps will audibly report the system’s status as described below. Action Number of Chirps Description System armed 1 (3-second delay), 1 System armed with Bypass Notification Disarm System disarmed Disarm...

  • Page 25: Table Of Zones

    Table of zones A zone is represented by the number of LED flashes used by the system to identify a particular type of input. Standard input assignments are listed in the following table, along with spaces to write in any optional sensors or switches that have been installed.

  • Page 26: Code Hopping

    Code hopping The receiver and transmitters use a math e mat i cal formula called an algorithm to change their code each time the transmitter is used. This tech nol o gy has been de vel oped to increase the security of the unit. The control unit knows what the next codes should be.

  • Page 27: Rapid Resume Logic

    Rapid resume logic This Directed system will store its current state to non-volatile memory. If power is lost and then reconnected the system will recall the stored state from memory. This means if the unit is in Valet Mode and the battery is dis con nect ed for any reason, such as servicing the car, when the battery is re con nect ed the unit will still be in Valet Mode.

  • Page 28: Programming Options

    Programming options Programming options control your system’s normal, operational set-up. Most op- tions do not require additional parts, but some may require installation labor. The following is a list of the programmable options, with the factory settings in Bold. • Active arming (transmitter only) or passive arming (automatic arming 30 seconds after the last door has been closed).
  • Page 29 • Full trigger response 30 or 60 seconds: This determines how long the full triggered sequence lasts. Some states have laws regulating how long a security system can sound before it is considered a nuisance. If your installer is programming the security system with the Directed Bitwriter , the ®...

  • Page 30: Security & Convenience Expansions

    Security & convenience expansions Listed below are expansion options avail able to you. Please consult your dealer for a complete explanation of all the options avail able to you. Audio Sensor: Metal glass, glass cracking, breaking glass produce dis tinc tive acoustic signatures. The 506T audio sen sor uses a mi cro phone to pick up sounds, then analyzes them with pro pri etary acoustic software to determine if the glass has been struck.

  • Page 31: Glossary Of Terms

    Glossary of terms Control Unit: The “brain” of your system. Usually hidden underneath the dash area of the vehicle. The control unit houses the microprocessor which monitors your vehicle and controls all system functions. Input: A physical connection to the system. An input can be provided by a sen- sor, pinswitch or by existing systems in the vehicle, such as ignition or courtesy lights.

  • Page 33: Quick Reference Guide

    Quick reference guide • Arming To arm, press . When the system arms, you will hear a short chirp, and the parking lights will flash once. • Arming while driving ������� To arm the system while driving, press on your transmitter while the ve- hicle is running.
  • Page 34 • To remote start the vehicle Press for 1 second. The parking lights will turn on (if connected) and the vehicle will start and run for the programmed period of time. • To disable the remote start system Move the shutdown toggle switch to the OFF position. Location of Shutdown switch ______________________________ •...

  • Page 35: Limited Lifetime Consumer Warranty

    Limited lifetime consumer warranty Directed Electronics. (“Directed”) promises to the original purchaser to repair or replace (at Directed’s election) with a comparable reconditioned model any Directed unit (hereafter the “unit”), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reason- able use during the lifetime of the vehicle provided the following conditions are met: the unit was purchased from an authorized Directed dealer, the unit was professionally installed...
  • Page 36 WARRANTY DOES NOT COVER LABOR COSTS FOR MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE.

  • Page 37: Notes

    Notes © 2009 Directed Electronics. All rights reserved.
  • Page 38 Notes reserved. ©2009 Directed Electronics. All rights...
  • Page 40 The company behind this system is Directed Elec tron ics Since its inception, Directed Electronics has had one purpose, to provide consumers with the finest vehicle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, Directed is ISO 9001 registered.
