Summary of Contents for Sharkoon Shark Zone M20
- Page 1 Manual SHARK ZONE M20...
-
Page 2: Table Of Contents
7. The editor 7.1 Starting the editor 7.2 Master Control window 7.3 Additional commands 7.4 Basic commands 7.5 Media functions 7.6 Macros programming 7.7 Fine tuning 7.8 Advanced settings 7.9 Illumination settings 7.10 Multi-click SHARK ZONE M20 SHARK ZONE M20... -
Page 3: Features
Dear Customer, Congratulations and thank you for your purchase of this high-quality Sharkoon product. To ensure a long service life, and full functionality of the product, we recommend that you read this manual thoroughly. We hope you enjoy your time with our product! SHARKOON Technologies 1. -
Page 4: Specifications
3 mm Weight tuning system Yes (5x 4 g) 3. Packaging contents • Shark Zone M20 • CD with software and PDF manual Note: Should any of the above items be missing, please contact us immediately by E-mail or our customer service: support@sharkoon.com (Germany and Europe) -
Page 5: The Mouse At A Glance - Buttons And Factory Functions
4. The mouse at a glance – buttons and factory functions (A) Left mouse button (freely programmable) (B) 2-way scroll wheel and middle mouse button (freely programmable) (C) Right mouse button (freely programmable) (D) Additional third mouse button / multifunction click (E) Weight tuning system SHARK ZONE M20... - Page 6 (H) Thumb button 2 / Backwards (I) Thumb button 3 / Increase volume (J) Thumb button 4 / Decrease volume (K) Connection cable PS: The button functions are preset at the factory and can be adjusted within the software. SHARK ZONE M20...
-
Page 7: Connecting To The Pc
5. Once the installation is complete, confirm by clicking “Finish” and perform a restart of the PC. 6. Launch the software via the icon in the task bar and/or list of installed programs in the Windows Start menu. Icon Logo SHARK ZONE M20... -
Page 8: The Editor
In this section you can set the polling rate, available settings for selection are 125/500/1000 Hertz. (C) Profile In this section you can assign up to five different configurations for each profile. (D) DPI setting Here you can set the DPI rate. SHARK ZONE M20... -
Page 9: Additional Commands
(A) Here you have the option between Swap Windows, My Computer, Close Window, Show Desktop or select Run. 7.4 Basic commands (A) Select the desired function from the available specifications: New, Cut, Copy, Paste, Save, Print, Find, Redo, Undo or Select All. SHARK ZONE M20... -
Page 10: Media Functions
7.5 Media functions (A) Select the desired function from the available specifications: Media Payer, Pre Track, Next Track, Stop, Play/Pause, Mute, Volume Up, Volume Down. SHARK ZONE M20... -
Page 11: Macros Programming
Confirm the name and press “Start recording”. Enter the desired commands or shortcuts on your keyboard. Stop recording with “Stop recording”. Other functions, such as input delay as well as subsequent edits to the programming are available on the right side of the Macro Manager. SHARK ZONE M20... -
Page 12: Fine Tuning
7.7 Fine tuning (A) Here DPI settings of the mouse can be adjusted. Options are 400/800/1600/3200 DPI. (B) Polling rate options are 125Hz/500Hz/1000Hz. SHARK ZONE M20... -
Page 13: Advanced Settings
7.8 Advanced settings (A) In this field, the double-click, scroll speed, X-Y Master Sensitivity, Win Pointer Speed and Sensitivity can be adjusted. SHARK ZONE M20... -
Page 14: Illumination Settings
7.9 Illumination settings (A) Here the lighting of the mouse wheel can be turned on or off. Also, the speed of the pulsating lights (off, slow, medium, fast) can be adjusted and customized SHARK ZONE M20... -
Page 15: Multi-Click
7.9.1 Multi-click (A) When the function is selected, you can specify the number of clicks as well as the delay time in milliseconds. SHARK ZONE M20... - Page 16 All named products and descriptions are trademarks and/or registered trademarks of the respective manufac- turers and are accepted as protected. As a continuing policy of product improvement at SHARKOON, the design and specifications are subject to change without prior notice. National product specifications may vary.
