Sharkoon LIGHT 2 S Manual

Lightweight gaming mouse
Hide thumbs Also See for LIGHT 2 S:
Table of Contents

Advertisement

Quick Links

Download this manual
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LIGHT 2 S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sharkoon LIGHT 2 S

Summary of Contents for Sharkoon LIGHT 2 S

  • Page 1 Manual...

  • Page 2: Table Of Contents

    Contents Specifications ....... . . 3 1.1 General ....... . . 3 1.2 Button Properties .

  • Page 3: Specifications

    2. Xxxxxxxxxxxx 1. Specifications 1.1 General Max. DPI/CPI 6,200 Min. DPI/CPI Sensor Optical Chip PixArt PAW 3327 Illumination Max. Polling Rate 1,000 Hz Frames Per Second 6,200 Inches Per Second Max. Acceleration 30 g Mouse Feet 4, 100 % PTFE Weight without Cable 78 g Dimensions (L x W x H)

  • Page 4: Dpi Properties

    2. Xxxxxxxxxxxx 1. Specifications 1.3 DPI Properties DPI Steps 5 (Fully Customizable) DPI Switch   DPI Indicator 1.4 Software Properties Gaming Software   Onboard Memory for Game Profiles   Capacity of Onboard Memory 16 kB Number of Profiles 1.5 Cable and Connector Connector Gold-Plated USB Plug...

  • Page 5: Connecting

    2. Connecting 3. Overview Left Mouse Button Scroll Wheel Right Mouse Button DPI Switch Thumb Button 1 Thumb Button 2 Thumb Button 3 Thumb Button 4...

  • Page 6: Software Installation

    4. Software Installation Download the gaming software for the Light² S from the Sharkoon website at www.sharkoon.com. Unzip the ZIP file in a folder of your choice and then double click the file "Light2_S.exe" to launch the installation. Follow the instructions of the setup wizard and then click on "Finish" to complete the installation. The Light² S symbol will then appear in the taskbar.

  • Page 7: Software Overview

    5. Software Overview Game Profiles: At the top of the gaming software, one of five game profiles can be selected at any time. Game Profiles contain all the settings of the menus in "Button/Speed", "DPI Settings" and "Illumination". Macros are stored independently of game profiles.

  • Page 8: Button/Speed

    6. Button/Speed In the Button/Speed settings, buttons for the currently selected game profile can be reassigned or provided with functions. In addition, the acceleration, mouse pointer speed, scroll speed, double-click speed as well as the polling rate can be adjusted.

  • Page 9: Changing Button Assignments

    6. Button/Speed 6.1 Changing Button Assignments Each of the eight buttons on the Light² S has a factory default setting that can be changed via the software. To change an assignment, select the button you want to change from the list to the right of the Light² S picture. If you are unsure which button is the one you want, you can use the picture as an aid.

  • Page 10: Dpi Settings

    7. DPI Settings All five preset DPI levels can be changed in the DPI Settings menu. You have the option of setting each DPI level to a desired DPI number from 200 to 6,200 DPI. It is also possible to disable any chosen DPI level. To help with orientation, the currently selected DPI level is always displayed directly above the DPI slide controls.

  • Page 11: Illumination

    8. Illumination In this menu, the illumination for the Light² S can be selected and adjusted. There are four lighting effects to choose from, as well as the deactivation of the lighting. Please note: The lighting may briefly flicker while changing. The four lighting effects available are: "Pulsating Spectrum", "Permanent", "Pulsating"...

  • Page 12: Macro Manager

    9. Macro Manager In the Macro Manager, macros with up to 62 key commands can be recorded, edited and deleted. Macros are independent of game profiles but can be used for any of these profiles after they have been recorded. Before a macro can be used, it must be assigned to a mouse button in the Button/ Speed menu.

  • Page 13: Profile Options

    10. Profile Options At the bottom of the Light² S software are the profile options, which can be accessed, at any time, independently of the menus. Here, you can save or load profiles on the PC for later use. There are also options for resetting one or all profiles to factory settings as well as the option "Apply".
  • Page 14 All named products and descriptions are trademarks and/or registered trademarks of the respective manufacturers and are accepted as protected. As a continuing policy of product improvement at Sharkoon, the design and specifications are subject to change without prior notice. National product specifications may vary.
