- Page 1 Outdoor Antenna Kit Model Number: HE21404 INSTRUCTION MANUAL After Sales Support - Help Desk Telephone: 1300 663 907 Internet: www.winplus.com.au...
-
Page 2: Warranty
Description goes here Outdoor Antenna Kit Warranty Details The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion. The benefits conferred by this warranty are in addition to all rights and remedies in respect of the product that the consumer has under the Competition and Consumer Act 2010 and similar state and territory laws. -
Page 3: Table Of Contents
Contents Warranty Contents Welcome / Warnings Product Features Parts List / Technical Specifications / Installation Tips Instructions FAQ’S Repair and Refurbished Goods or Parts Notice After Sales Support - Help Desk Telephone: 1300 663 907 Internet: www.winplus.com.au... -
Page 4: Welcome / Warnings
Welcome Congratulations on choosing to buy a BAUHN® product. By doing so you now have the assurance and peace of mind that comes with purchasing a product made by one of the leading manufacturers. All products brought to you by BAUHN® are manufactured to the highest standards of performance and safety and, as part of our philosophy of customer service and satisfaction, are backed by our comprehensive 1 Year Warranty. -
Page 5: Product Features
Product Features Antenna Connection Antenna Elements Mounting Pole Mount Faceplate • Effective signal reception up to 95kms away from transmission tower, suitable for almost all metropolitan installations in Australia • Robust construction for peace of mind in bad weather. Durable elements are rustproof and waterproof •... -
Page 6: Parts List / Technical Specifications / Installation Tips
~480mm height allowed by the Bauhn Outdoor Antenna kit is sufficient. The Bauhn Outdoor Antenna Kit comes with a 12m coax cable with a F-Type connector. This is a standard antenna cable. If you require additional cable length, you should contact your local electrical supplier. -
Page 7: Instructions
Instructions Connect Antenna Elements The Bauhn Outdoor Antenna comes pre-installed with 26 antenna elements. There are an additional 6 elements that should be installed first for optimal reception. Attach the antenna elements to the main body by inserting each element, then securing with the small screws supplied in the pack. - Page 8 Mounting Antenna The Bauhn Outdoor Antenna Kit includes everything you need to mount your antenna on your home or other outdoor location. Included with the kit are masonry anchors and timber screws. Refer to the installation tips on p.6 for antenna installation advice. Consult a professional if you are unsure or unclear on any steps.
- Page 9 Masonry Mounting: Included with the kit are 4 x 54mm x Ø7.5mm masonry anchors. Hold the faceplate against the masonary then mark the area with a pencil to note the location of the mounting holes. You will need to drill a hole into the masonry using a masonry drill bit, no deeper than 36mm.
- Page 10 Tip: Confirm the correct mounting angle of the mount before tightening the mounting screws. Loosen the screws to adjust the angle of installation. The antenna should be mounted horizontally to achieve the best reception. Check the mount is attached securely to your home before proceeding to attach the antenna.
- Page 11 Plugging in the Antenna Cable The Bauhn Outdoor Antenna Kit includes a 12m F-Type Coaxial Cable. This is a common antenna cable and is suitable for most houses and installation scenarios.
-
Page 12: Faq's
Frequently Asked Questions Question Answer I’m not receiving good reception - When installing, take note of the direction of your nearby antennas. You can get a good idea of the best direction to face your antenna by looking at those around you. - If you are replacing an already mounted antenna, take note of the height and direction of the old antenna to get a good idea of... - Page 13 Frequently Asked Questions Question Answer Can I install this antenna inside my - This is not recommended. You would roof? receive very bad reception as a result of interference. Which direction should the antenna - You should face your antenna towards the face? nearest broadcast location.
- Page 14 Notes: After Sales Support - Help Desk Telephone: 1300 663 907 Internet: www.winplus.com.au...
-
Page 15: Repair And Refurbished Goods Or Parts Notice
Description goes here Outdoor Antenna Kit The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion. The benefits conferred by this warranty are in addition to all rights and remedies in respect of the product that the consumer has under the Competition and Consumer Act 2010 and similar state and territory laws.
