Configuration modes

Allows the user to set the camera options.
Navigating in the menu:
-The M button to move among the choices
-The OK button to select an option
-The BACK button to return to the previous menu
Video mode
Allows the user to record video in the following resolutions:
Resolution Field of view
480p Wide angle
720p Ultra wide angle 1280 x 720
XCEL HD 1080p Wide angle
XCEL HD2 1080p Ultra wide angle
Photo mode (including the Multi-shot mode)
1. Allows the user to take photos in the following resolutions:
XCEL HD: 1mp, 3mp or 5 mp
XCEL HD2: 5mp, 8mp or 12mp
Changing this setting also affects photos taken in TIME LAPSE mode.
2. The Multi-shot mode allows the user to take 1 to 6 consecutive photos
with every shot with a delay of approximately 0,5 seconds between
each photo.
TIME LAPSE mode
Allows the user to take photos at regular predefined intervals:
0.5, 2, 5, 10, 30, 60 seconds.
Screen
Advantage
resolution
Greater length of
848 x 480
recording
Largest field of
view
1920 x 1080 The highest
1280 x 720 resolution
Date/Time
Allows the user to set the date (Year/Month/Day) and time (hour/minute).
Use the OK button to confirm the entry and use the M and BACK button
to adjust the digits.
Note: When the camera is not powered for approximately 48 hours, it is
possible that the date and time reset. So always verify the date and time
before using the camera when this occurs.
Remote control
Allows the user to remotely control the camera (Wireless mode).
Wireless actived. The reaction time between the camera and the
remote control can take a few seconds but gives a better battery
life. See note at page 13.
(XCEL HD2 only) Wireless activated in "Quick React" mode.
The reaction time between the camera and the remote control is
instantaneous. By cons, this option requires more energy con-
sumption and lifetime of the battery will be affected.
Wireless deactivated.
Sound signal
Enable or disable the sound of the camera when using the buttons.
DEL lights
Enable or disable the LEDs lights. When the Remote control and LED lights
options are activated, the 4 LEDs flash slowly to indicate that the camera
is waiting for the signal from the remote control and flash rapidly during
record videos/photos. See OPERATION OF THE LED LIGHTS AND SCREEN
DEPENDING ON SELECTED OPTIONS section for more details (12).
Erase
Allows the user to erase the last file or all files.
