- Page 1 WIRED WIRED For: PC For: PS3 I Xbox 360 I PC ™ ® I Mobile Gaming* I Mobile ® ® 7.1- CHANNEL PC GAMING HEADSET User Guide...
- Page 2 EAR FORCE® Z60 7.1-Channel PC Gaming Headset Congratulations on your purchase of the Ear Force Z60 headset from Turtle Beach. Designed for PC gaming, the Z60 also supports music, movies, chat and Skype® communication. Turtle Beach brings over 35 years of...
- Page 3 In the Box turtlebeach.com/support For our Knowledgebase and Technical Support please visit: Ear Force Z60 Headset Ear Force Z60 Surround Sound Control Unit Removable Mic Boom Turtle Beach Sticker Go to Table of Contents...
-
Page 4: Table Of Contents
Table of Contents About the Z60 Parts and Controls Connections Windows PC Setup Mac OSX Setup Skype Setup Connecting Mobile Devices Adjusting Sound Specifications Troubleshooting Tips Important Safety Information... -
Page 5: About The Z60
• Mobile Versatility. Pop out the mic boom, disconnect from the Surround Sound Control Unit and use the Z60 on the go with your mobile devices. • Turtle Beach Audio Advantage. With more than 35 years of audio experience, Turtle Beach delivers innovative technology to provide a competitive advantage and the most realistic and immersive audio experience built into a high quality, comfortable headset. -
Page 6: Parts And Controls P6
Parts and Controls Mic Mute Button · Short Press = Microphone On/Off · Long Press = Mic Monitor On/Off Game Volume Control Mic Mute indicator Off = Mic is turned on. On = Mic is turned off. Surround Sound Button Chat Volume Control Press to cycle through surround sound modes: Game >... -
Page 7: Connections P7
Connections 1. Insert the plug of the Removable Mic Boom into the jack on the left earcup of the Headset. 2. Insert the Headset cable into the Headset Connection on the Surround Sound Control Unit. 3. Plug the USB cable of the Surround Sound Control Unit into an available USB port on the computer. -
Page 8: Windows Pc Setup P8
Windows PC Setup The Ear Force Z60 headset is designed for use with Windows 7 and Windows 8® PCs. 1. Right click the Speaker icon in your task bar and select Playback Devices. 2. Right click on Turtle Beach Z60 Game Audio and select Set as Default Device. - Page 9 Windows PC Setup 3. Right click on Turtle Beach Z60 Chat Audio and select Set as Default Communication Device. 4. Left click Turtle Beach Z60 Game Audio and then click the Configure button. Go to Table of Contents...
- Page 10 Windows PC Setup 5. In the Audio Channels list, make sure 7.1 Surround is selected. 6. Click on Next two times to ensure that Front Left and Right and Surround Speakers are set to full range. Then click on Next again to confirm setting. 7.
-
Page 11: Mac Osx Setup P11
Depending on your OS version, the screens may differ, but the steps remain the same. 2. In the System Preferences folder, click on Sound. 3. In the Sound dialog box, click on the Output tab and select Turtle Beach Z60 Game Audio. Go to Table of Contents... - Page 12 Mac OX Setup 4. Click on the Input tab and select Turtle Beach Z60 Chat Audio. Close the Sound dialog box and close the System Preferences folder. 5. In Finder, click into the Spotlight line and type Audio MIDI Setup.
- Page 13 6. In the list of search results, click on the Audio MIDI Setup application. 7. In the Audio MIDI Setup application, select Turtle Beach Z60 Game Audio, select the Output tab, select 8ch-16bit Integer from the drop-down menu and click on Configure Speakers.
-
Page 14: Skype Setup P14
2. In the Audio Settings dialog box, select Turtle Beach Z60 Chat Audio in the Microphone drop down box. 3. Select Turtle Beach Z60 Chat Audio in the Speakers drop down box. 4. To test the microphone, first confirm that the Z60... -
Page 15: Connecting Mobile Devices P15
Connecting Mobile Devices You can plug the Z60 headset directly into mobile phones, tablets and other devices that provide a 3.5 mm headphone output jack. Go to Table of Contents... -
Page 16: Adjusting Sound P16
Adjusting Sound If you want to… Then... Adjust game/media volume. Use the Game Volume Control on the Surround Sound Control Unit. A single raised bump in the Surround Sound Control Unit housing helps you identify the control without looking so you can keep your eyes on the game. If you want to…... - Page 17 Specifications · Speakers: 60mm Diameter with neodymium magnets · Headset frequency response: 20 Hz – 20 kHz · Microphone Design: Removable Omni-Directional · Headset input: 3.5 mm 4-pole · Surround Sound Control Unit interfaces: USB-A, 3.5 mm 4-pole mini-jack · Headset weight: 10oz (285 g) headset only Go to Table of Contents...
- Page 18 Troubleshooting Tips No sound: Possible Cause Solution Game Volume Control turned down Check that the Game Volume Control on the Surround Sound Control Unit is turned up. Additionally, check that your PC Volume is turned up as well. Loose connection Confirm that the Headset is plugged firmly into the Surround Sound Control Unit and that the USB plug of the Surround Sound Control Unit is firmly inserted into the computer USB port.
-
Page 19: Important Safety Information P19
Important Safety Information To avoid potential damage to the device, always disconnect all cables before transporting it. WARNING: Permanent hearing damage can occur if a headset is used at high volumes for extended periods of time, so it is important to keep the volume at a safe level. Over time, your ears adapt to loud volume levels, so a level that may not cause initial discomfort can still damage your hearing. - Page 20 Regulatory Compliance Statements for EAR FORCE Z60 Model Federal Communications Commission (FCC) Compliance Notices Class B Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15, Subpart B of the FCC Rules.
-
Page 21: Declaration Of Conformity
Declaration of Conformity Heading Marking by this symbol: indicates compliance with the Essential Requirements of the EMC Directive of the European Union (2004/108/EC). This equipment meets the following conformance standards: Safety: EN 60950-1: 2006 + A11 + A1 + A12 (T-Mark License) Also Licensed for Standards: EC 60950-1: 2005 + A1: 2009, (CB Scheme Report/Certificate), UL60950-1 (NRTL License), CSA22.2, 60950-1 (SCC License) - Page 22 WARRANTY SERVICE: In the USA and CANADA Warranty Service is provided by our Turtle Beach USA offices and in all other Countries it is provided by our local International Distributors when available. Refurbished/Recertified products are sold on an AS IS basis with a 90-day Warranty or less in accordance with each ven- dor’s policy.
- Page 23 EXCLUSIONS FROM LIMITED WARRANTY: This Limited Warranty shall not apply and VTB has no liability under this Limited Warranty if the Turtle Beach Product: - is used for commercial purposes such as “LAN, Call Centers” (including rental or lease); - is modified or tampered with;...
- Page 24 © 2014 Voyetra Turtle Beach, Inc. (VTB, Inc.) All rights reserved. Turtle Beach, the Turtle Beach Logo, Voyetra, and Ear Force are either trademarks or registered trademarks of VTB, Inc. AUDIO ADVANTAGE is a trademark of Turtle Beach Inc. For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited.
