- Page 1 Installation Manual Model #: DVD-024-01/03-x Digital Video Disc Player Document #540149 7300 Industry Drive, North Little Rock, AR 72117 USA Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com...
- Page 2 Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used or disclosed to anyone without the written authorization of Audio International, Inc. Document #540149, Rev. IR, 1/2000...
-
Page 3: Table Of Contents
Audio International, Inc. DVD-024-01/03-x Installation Manual Table of Contents Section Description Page General Information ……………………………………………. Introduction ……………………………………………………….. Purpose of the Equipment ………………………………………. Operational Features……………………………………………... Optional Equipment ……………………………………………… Application ……………………………………………………….. Introduction ……………………………………………………….. Block Diagram – Typical Application……………………………. Data Bus Control …………………………………………………. -
Page 4: General Information
Introduction This manual contains information for the proper application and installation of the Audio International, Inc. (AI) Digital Video Disc Player, Model # DVD-024-01/03-x. The “-x” suffix designates the type of connector utilized for installation. All included are relative physical and electrical characteristics of the unit. -
Page 5: Optional Equipment
Application Introduction The DVD-024-01/03-x operates between +18 and +32VDC with a power consumption of less than 1A at +28VDC. In addition the DVD-024-01/03-x is capable of withstanding power interruptions in duration of 200 msec or less. The DVD-024-01-x is capable of playing only Region 1 encoded DVD discs. -
Page 6: Block Diagram - Typical Application
Audio International, Inc. DVD-024-01/03-x Installation Manual Block Diagram – Typical Application This system is fully compatible with Audio International’s proprietary RS485 digital data bus system. It can be configured for IR remote control utilizing AI’s remote control unit AI-RC1-17xxxx and IFR-485. -
Page 7: Data Bus Control
• Length of cable runs • Environmental conditions (temperature, humidity, etc.) • Accessibility for service 3.1.2 The DVD-024-01/03-x shall be installed to conform to the standards designated by the customer, installing agency, or other specified requirements. 3.1.3 Long low-level runs may introduce noise into the audio signal. -
Page 8: Unpacking And Inspection
3.3.4 DO NOT remove any factory-installed screws. Damage to the unit may result and void any warranties. 3.3.5 The DVD-024-01/03-x shall be mounted in a horizontal position, not on the side or back. Avoid angled/inclined installations. 3.3.6 ESD (Electro Static Discharge) guidelines shall be followed. -
Page 9: Wiring Requirements
(6) inches between lines. Physical Characteristics 3.5.3 The DVD-024-01/03-x should be located away from excessive heat, excessive moisture, splashing liquids, direct sunlight, and areas with excessive dust. 3.5.4 Allow at least 1-inch air space around the unit for heat dissipation. -
Page 10: Electrical Characteristics
Audio International, Inc. DVD-024-01/03-x Installation Manual Electrical Characteristics 3.6.3 The DVD utilizes one 15-pin connector for electrical connections. This connector provides +28 VDC, left and right audio output, data bus control, and infrared input. Refer to Section 3.7 for mating connector information. -
Page 11: Post-Installation Test
Audio International, Inc. DVD-024-01/03-x Installation Manual Post-Installation Test 3.9.1 Verify that all audio and video outputs are available to the appropriate distribution system(s). 3.9.2 Load a DVD disc into the video player. Use the DVD front-panel controls or the hand-held remote control unit to select PLAY. -
Page 12: Specifications
Audio International, Inc. DVD-024-01/03-x Installation Manual Problem Possible Cause Solution No sound Unit is improperly installed Verify +28 VDC power Audio system not powered or active Verify audio system is in active mode Contact AI for assistance No picture Unit is improperly installed... - Page 13 Audio International, Inc. DVD-024-01/03-x Installation Manual The following diagrams show the unit dimensions and connector locations for the DVD-024-01/03-x. All dimensions are shown in inches. Document #540149, Rev. IR, 1/2000 Page 13 of 13...
