- Page 1 Installation Manual Model #: DVD-024-04-x Digital Video Disc Player Document #540184 7300 Industry Drive, North Little Rock, AR 72117 USA Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com...
- Page 2 Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used or disclosed to anyone without the written authorization of Audio International, Inc. Document #540184, Rev. IR, 3/2000...
-
Page 3: Table Of Contents
Audio International, Inc. DVD-024-04-x Installation Table of Contents Section Description Page General Information ……………………………………………. Introduction ……………………………………………………….. Purpose of the Equipment ………………………………………. Operational Features……………………………………………... Optional Equipment ……………………………………………… Application ……………………………………………………….. Introduction ……………………………………………………….. Block Diagram – Typical Application……………………………. Data Bus Control …………………………………………………. Installation ……………………………………………………….. -
Page 4: General Information
Introduction This manual contains information for the proper application and installation of the Audio International, Inc. (AI) Digital Video Disc Player, Model # DVD-024-04-x. The “-x” suffix designates the type of connector utilized for installation. Also included are relative physical and electrical characteristics of the unit. -
Page 5: Optional Equipment
(AI-RC1-17xxxx) via an infrared receiver, IFR-9A or IFR-485. This hand-held remote control operates functions such as visual search, pause, play, stop, fast-forward, and rewind. Contact Audio International for further details. Application Introduction The DVD-024-04-x operates between +18 VDC and +32 VDC with a power consumption of less than 1A at +28 VDC. -
Page 6: Block Diagram - Typical Application
Audio International, Inc. DVD-024-04-x Installation Block Diagram – Typical Application This system is fully compatible with Audio International’s proprietary RS485 digital data bus system. It can be configured for IR remote control utilizing AI’s remote control unit AI-RC1-17xxxx and IFR-485. -
Page 7: Data Bus Control
Audio International, Inc. DVD-024-04-x Installation The fiber optic cable allows for configuration to AI’s surround sound processor, ASP-101-0x-x. The ASP-101-0x-x takes digital audio from the DVD-024-04-x and decodes the signal sound into a Dolby Digital 5.1 (AC3), Prologic, Hall or theater surround sound effects. -
Page 8: Installation
Audio International, Inc. DVD-024-04-x Installation Installation Prior to Installation Prior to installation, the following items should be considered: 3.1.1 During the design and layout of the aircraft cabin, careful consideration of the location of this and all other source equipment is necessary. -
Page 9: Unpacking And Inspection
AI within 24 hours and a “Return Request Authorization Number” must be obtained from AI. Refer to the front cover of this manual for address and telephone number of Audio International. Repackage the unit in its original packaging materials and return it to AI following instructions given by the AI representative. -
Page 10: Wiring Requirements
Audio International, Inc. DVD-024-04-x Installation Wiring Requirements 3.4.1 Power Wires All power and ground wires shall be 22 AWG minimum. All audio lines require twisted, shielded cable with the cable shields properly grounded at the source. Power ground wires shall be grounded within twelve (12) inches of the unit. -
Page 11: Physical Characteristics
Audio International, Inc. DVD-024-04-x Installation Physical Characteristics 3.5.1 The DVD-024-04-x should be located away from excessive heat, excessive moisture, splashing liquids, direct sunlight, and areas with excessive dust. 3.5.2 Allow at least 1-inch air space around the unit for heat dissipation. -
Page 12: Pinout Assignment Descriptions
Audio International, Inc. DVD-024-04-x Installation Pinout Assignment Descriptions Connector pinouts and descriptions are as follows: Pin # Description + 28 VDC Ground Reserved Reserved Reserved Reserved Data Bus (A) Data Bus (B) Infrared Input + Infrared Input - IR Strap 2... -
Page 13: Troubleshooting
Audio International, Inc. DVD-024-04-x Installation Troubleshooting General Troubleshooting Procedures Many problems can be isolated with the following general techniques: • To verify power to the unit, recheck +28 VDC power is applied to the proper pins (refer to Section 3.8) on the unit. Use a voltmeter to verify correct level. -
Page 14: Specifications
Audio International, Inc. DVD-024-04-x Installation Specifications Unit Specifications Physical Specifications Housing Black Anodized Brushed Aluminum Dimensions (D x W x H) 10.90” x 8.65” x 4.02” 27.69cm x 21.97cm x 10.21cm Weight 4.45 lbs / 2.02 kg Electrical Specifications Power... -
Page 15: Reference Drawings
Audio International, Inc. DVD-024-04-x Installation Reference Drawings The following diagrams show the unit dimensions and connector locations for the DVD-024-04-x. All dimensions are shown in inches. Document #540184, Rev. IR, 3/2000 Page 15 of 15...
