Installation and Operation Manual DVD-224-01-x Digital Video Disc Player Document # 540232 a DeCrane Aircraft Company 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com... - Page 2 Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc. Document # 540232, Rev B, 05/2002...
-
Page 3: Table Of Contents
Audio International, Inc. DVD-224-01-x Installation & Operation Manual Table of Contents Section Description Page General Information……………………………………………… Introduction…………………………………………………………. Purpose of the Equipment………………………………………… Operational Features……………………………………………… Optional Equipment……………………………………………….. Technical Specifications………………………………………….. Application………………………………………………………….. Video/Audio Disc Care……………………………………………. Installation……..………………………………………………… Prior to Installation…………………………………………………. Unpacking and Inspection………………………………………… Cautions & Warnings………………………………………………... -
Page 4: General Information
Purpose of the Equipment Audio International’s DVD-224-01-x is a high-quality video disc player specifically designed to meet the special requirements of aircraft use. This video disc player represents a digital medium with the capacity to incorporate an entire feature film –... -
Page 5: Operational Features
Audio International, Inc. DVD-224-01-x Installation & Operation Manual Operational Features Operates directly from +28 VDC Plays Multi-Regional CDs NTSC output Front panel controls Optional infrared remote controllable High fidelity, digital stereo audio output Audio output level +2 V into not less than 600 Ω, factory preset... -
Page 6: Application
2 V (factory preset) for each output channel. Typical Application 6.2.1 This system is fully compatible with Audio International’s proprietary RS-485 digital data bus system. It can be configured for IR remote control utilizing AI’s remote control unit AI-RCx-17xxxx and IFR-485. -
Page 7: Video/Audio Disc Care
Audio International, Inc. DVD-224-01-x Installation & Operation Manual 6.2.3 The unit can also be configured for Touch Screen or remote panel control (i.e. entertainment control panels). The panels are on AI’s proprietary RS-485 digital data bus system and configured to control the operational features of the DVD-224-01-x. -
Page 8: Installation
Audio International, Inc. DVD-224-01-x Installation & Operation Manual SECTION II - INSTALLATION Prior to Installation During the design and layout of the aircraft cabin, careful consideration of the location of this and all other audio/visual modules is necessary. Some of the items to be considered include:... -
Page 9: Cautions & Warnings
International WITHIN 24 hours and a Return Request Authorization Number shall be obtained from AI. Refer to the front cover of this manual for address and telephone number of Audio International, Inc. Repackage the unit in its original packaging materials and return it to AI following instructions given by the AI representative. -
Page 10: Wiring Requirements
Audio International, Inc. DVD-224-01-x Installation & Operation Manual 3.13 ESD (Electro Static Discharge) guidelines shall be followed. Wiring Requirements Introduction The installing agency shall supply and fabricate all external cables. The length and routing of external cables shall be carefully studied and planned before attempting installation of the equipment. -
Page 11: Physical Characteristics
Audio International, Inc. DVD-224-01-x Installation & Operation Manual AI’s Proprietary RS-485 Data Bus 4.4.1 The DVD-224-01-x is designed to interface with other Audio International equipment via AI’s proprietary RS-485 serial data bus. The data bus shall be implemented using a twisted shielded pair cable in accordance with the standard military specification of MIL-DTL-27500 or equivalent. -
Page 12: Electrical Characteristics
Audio International, Inc. DVD-224-01-x Installation & Operation Manual Electrical Characteristics Electrical Specifications: Electrical Power 750 mA @ +28 VDC Operating Voltage +18 to +32 VDC Range Data Bus Type AI Proprietary RS-485 Audio Frequency 4 Hz to 20 kHz Response... -
Page 13: Post-Installation Test
Audio International, Inc. DVD-224-01-x Installation & Operation Manual Mating Connector Information Model # Connector Designator Mating Connector DVD-224-01-1 RD15F10JVL0 DAMA-15S DVD-224-01-2 D20418-2 Female Screwlock BNC1 Video AMPHENOL 31-71013 BNC1 Input or equivalent ST Series optical Optical Digital connector 501380-6 Audio Output... -
Page 14: Troubleshooting Guide
Audio International, Inc. DVD-224-01-x Installation & Operation Manual Troubleshooting General Troubleshooting Procedures To verify power to the unit, confirm that +28 VDC power is applied to the proper pins on the unit. Use a voltmeter to verify correct level. Reset by removing power from the unit for at least one (1) minute and then reapply power. -
Page 15: Reference Drawings
Audio International, Inc. DVD-224-01-x Installation & Operation Manual Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the DVD-224-01-x. Document # 540232, Rev B, 05/2002 Page 14 of 23... -
Page 16: Operation
Audio International, Inc. DVD-224-01-x Installation & Operation Manual SECTION III – OPERATION General Information The DVD-224-01-x can be operated via front panel ‘buttons’ or optionally controlled by infrared remote or AI’s touch screen panel. Digital codes allow the unit to interface with an infrared handheld remote via an infrared receiver (IFR-9A or IFR-485). -
Page 17: Front Panel Controls
Audio International, Inc. DVD-224-01-x Installation & Operation Manual FRONT PANEL CONTROLS ILLUSTRATION OF DVD-224-01-x FRONT PANEL The names and functions of the DVD-224-01-x are as follows: Open / Close button – Press to eject a disc from the disc tray or to load a disc onto the disc tray. -
Page 18: Basic Playback
Audio International, Inc. DVD-224-01-x Installation & Operation Manual Basic Playback To open the disc tray, press the OPEN / CLOSE button. The disc tray will slide forward. To play a DVD or CD disc, place the desired disc on the disc tray with the playback side down. - Page 19 Audio International, Inc. DVD-224-01-x Installation & Operation Manual 4.1.3 Program codes are not lost when batteries are removed or replaced. However, codes may be lost if power is not restored to the remote control within an hour (CAUTION: FACTORY CODES ARE NOT LOST IF BATTERIES ARE REPLACED WITHIN THE ONE (1) HOUR TIME FRAME.
- Page 20 Audio International, Inc. DVD-224-01-x Installation & Operation Manual Ø To advance a DVD frame by frame, press PAUSE / STEP during still mode. Each time the button is pressed, the picture advances one (1) frame. To resume normal playback, press PLAY.
- Page 21 Audio International, Inc. DVD-224-01-x Installation & Operation Manual Ø To select a subtitle language, press SUBTITLE CHANGE during playback and the current subtitle language appears. Continue to press SUBTITLE CHANGE until the desired language is displayed. It is also possible to change subtitles by selecting the SUBTITLE CHANGE option from the main menu and using the arrow keys to select the desired language.
- Page 22 Audio International, Inc. DVD-224-01-x Installation & Operation Manual 4.2.5 Function Setup-Customizing the Function Settings 4.2.5.1 Displaying the SET UP MENU screen: Ø The SET UP MENU may be used to select DVD menu default selections regardless of DVD configuration. Press SETUP during the stop mode.
- Page 23 Audio International, Inc. DVD-224-01-x Installation & Operation Manual Ø When DISC MENU is selected, choose a preferred language by pressing one (1) of the arrow buttons and then press ENTER . To change the language while a disc is inserted, press the MENU button to display the disc menu.
- Page 24 Audio International, Inc. DVD-224-01-x Installation & Operation Manual Ø The Background may be changed from Blue to Black. Use the arrow keys to choose the desired background and press ENTER to select. Ø The Parental Control option may be used to lock out disks from certain countries or those of certain rating levels (“PG-13”...
