Positron G-320 Quick Start

G-320 Gateway Quickstart
Features
• Single E1/T1 PRI for connection to the telephone network
• Dual Foreign Exchange Station (FXS) port for connecting a phone or fax machine
• Hardware based G.168 echo cancellation chip up to 128 ms tail length
• Four port Ethernet Switch 10/100Mbps auto MDIX Ethernet port
• Dual USB ports
• Audio Input (mono) jack
• Audio Output (mono) jack
• Single Compact Flash port
• Real Time Clock (battery)

Installation Steps

1. Insert the external power supply cable to provide power to the
device
2. Connect the RJ-45 Ethernet cable provided (orange) to one of the
four available Ethernet ports on the G-320
- The default IP address of G-320 is 192.168.1.2
3. Connect the other end of the RJ-45 to your laptop / PC
- The IP address of the laptop / PC must be on the same
subnet of the G-320 (192.168.1.X)
4. Connect to the browser based configurator by opening the
browser to the IP address. The following is the default
connection credentials:
Username: admin
Password: password
Contents of Box
• G-320 Gateway
• External Power Supply
• Two RJ-45 Cat5e Ethernet Cable (orange)
Support
To ensure your PBX is working, try the following:
• Check the LED on the front panel, the LED with the circle mark
should be solid RED
• Plug an analog telephone into the FXS port – is there a dial tone?
• At the dial tone, press 6000 and you will hear the operator's voice
These steps do not require user configuration. If you are unable to
complete them, please contact Positron Telecommunication Systems.
Compact Flash
Sandisk Compact Flash is recommended supported media brand
