Summary of Contents for Boss Audio Systems 726CA

  • Page 2: Table Of Contents

    CONTENTS LIST PAGE CONTENTS BUTTONS LOCATION AND FUNCTIONS HANDLING COMPACT DISCS ACCESSORY INCLUDED INSTALLATION DETACHABLE CONTROL PANEL WIRING DIAGRAM BASIC OPERATIONS AUDIO OPERATIONS RADIO OPERATIONS CD OPERATIONS MP3/WMA OPERATIONS REMOTE CONTROL SPECIFICATIONS TROUBLE SHOOTING...
  • Page 3: Buttons Location And Functions

    1. BUTTONS LOCATION AND FUNCTIONS 1. Panel Release Button 1. Tecla para remover o painel frontal 2. Mute Button 2. Tecla Mute 3. CD Eject Button 3. Tecla para ejetar o disco 4. Audio Button 4. Tecla de ajuste de audio 5.
  • Page 4: Handling Compact Discs

    2. HANDLING COMPACT DISCS MOISTURE CONDENSATION On a rainy day or in a very damp area, moisture may condense on the lenses inside the unit. Should this occur, the unit will not operate properly. In such a case, remove the disc and wait for about an hour until the moisture has evaporated.
  • Page 5: Accessory Included

    3. ACCESSORY INCLUDED When first unpacking your new head unit, please check first that the package contains all of the items below. If something is missing, contact the store where you purchased the player. Owner’s Manual Warranty Card Remote control Lithium Battery Half Sheeve Insert Key...
  • Page 6: Installation

    4. INSTALLATION Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and system work properly. Use only the parts included with the unit to ensure proper installation. The use of unauthorized parts can cause malfunctions.
  • Page 7 Removing the unit a. Frame b. Insert fingers into the groove in the front of frame and pull out to remove the frame. (When re-attaching the frame, point the side with a groove down wards and attach it.) c. Insert the levers supplied with the unit into the grooves at both sides of the unit as shown in figure until they click.
  • Page 8: Detachable Control Panel

    5. DETACHABLE CONTROL PANEL (D.C.P .) Removing The Detachable Control Panel (D.C.P .). 1. Turn the power off 2. Press the D.C.P . release button 3. Remove the D.C.P . PANEL RELEASE BUTTON Attaching the DCP 1. Attach the panel at the right side first, with point B on the main unit touching point A on the D.C.P .
  • Page 9: Wiring Diagram

    6. WIRING DIAGRAM (20 PIN HARNESS PLUG) FUSE SICHERUNG FUSIBLE ANTENNA CABLE INPUT FUSíVEL FUSIBLE ANTENNENVERLÄNGERUNGSKABEL FUSIBILE CÂBLE D'EXTENSION D' ANTENNE ENTRADA PARA CABO DE ANTENA CABLE DE ANTENA CAVO ANTENNA ESTENDIBILE 20-PIN AUDIO/POWER HARNESS (See Figure 1) WHITE 20-PIN AUDIO/STROM- KABELGESCHIRR WEISS YELLOW PLAQUE 20 FICHES AUDIO/ALIMENTATION...
  • Page 10: Basic Operations

    7. BASIC OPERATIONS 1) PANEL RELEASE BUTTON (REL) Press this button to remove the control panel. 12) POWER ON/OFF BUTTON Press this button to turn on or off the power. 5) DISPLAY BUTTON (DISP) Press this button briefly, the LCD will display the clock for about 2 seconds, then return to previous display mode.
  • Page 11: Audio Operations

    8. AUDIO OPERATIONS 10) VOLUME KNOB Turn this knob to adjust desired volume level. 4) AUDIO BUTTON Press this button to select desired audio function. ORDER OF FUNCTION: VOLUME(VOL) -> BASS(BAS) -> TREBLE(TRE) ->BALANCE(BAL) ->FADER(FAD) While the selected function is displayed, turn Volume Knob to adjust the level within 5 seconds, otherwise the unit will return to volume adjustment mode.
  • Page 12: Radio Operations

    9. RADIO OPERATIONS 11) AUTO MEMORY STORE/PRESET SCAN BUTTON (AS/PS) 1. PRESET SCAN: Press AS/PS button briefly to enter Preset Scan mode, it will scan all the preset stations in the memories, you can hear that it will stay on each station for about 5 seconds. 2.
  • Page 13: Cd Operations

    10. CD OPERATIONS M1) PAUSE BUTTON (PAUSE) Press this button to pause CD play, press again to release pause. M2) SCAN BUTTON (SCAN) Press this button, the first 10 seconds of each track will be played sequentially until this button is pressed again, then normal play will resume at the current track.
  • Page 14: Mp3/Wma Operations

    11. MP3/WMA OPERATIONS Notes : - An MP3 directory is shown in this manual as “D irectory ”, and an MP3 file is shown as “Track”. - Maximum length of file name : 28 characters. - Maximum length of directory : 16 characters. - Supports Multi-Session recording.
  • Page 15 Press MP3 ENTER BUTTON and continue to search the directory or file name in the directory by TUNE UP / DOWN Button (TUNE DOWN First). The selected file can be played by pressing MP3 Enter Button The distribution of alphabetical characters are listed as follow : Button DISP MODE TUNE DN TUNE UP...
  • Page 16: Remote Control

    12. REMOTE CONTROL OPERATIONS: Radio Mode CD Player Mode MP3 Mode 1. Power Power On/Off Power On/Off Power On/Off Adjust Vol,Bas, 2. Volume Up/Down Adjust Vol,Bas, Adjust Vol,Bas, Tre,Fad,Bal Tre,Fad,Bal Tre,Fad,Bal Display Clock Display Clock 3. ID3/DISP ID3 tag information Display Clock, Numeric key 0* 4.Stereo/Mono...
  • Page 17: Specifications

    13. SPECIFICATIONS CD PLAYER CD Player Compact disc audio system Sistema: Sistema áudio CD System Compact disc Tipo de disco: Usable disc 44.1KHz Frequência de Amostragem: Sampling frequency 44.1KHz 1bit Conversor D/A: No of quantization bits 1bit 5-20,000Hz Resposta de frequencia 5-20,000Hz Frequency 2 stereo...
  • Page 18 10 R - 02 1397...
  • Page 19: Trouble Shooting

    14. TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom Cause Solution If the power supply is properly connected No power The car ignition is not on.
